HBD-E370/E470/E570/E870/T57
14
2-6. FRONT PANEL BLOCK
Note: Please prepare the thin wire (clip etc.).
2-7. CONNECT BOARD
5 three screws
(BV3)
7 three screws
(BV3)
6 three ground plates (front)
2
9
3 three claws
4 loading panel assy
(10EZ)
8 three claws
8 two claws
8 three claws
q; connector
(CN700)
qa front panel block
7 three screws
(BV3)
3 claw
clip etc.
1
3 four screws
(BV3)
4
1 connector (CN301)
5 CONNECT board
2 wire (flat type) (15 core)
(CN300)
four claws
