HBD-E370/E470/E570/E870/T57
25
Screen 6: *S-Curve Check Menu (Not Used)
(Screen 6)
S - Curve Check Menu
[1] Disc: Eject
[2] Media Type: BD - ROM SL
[3] Layer: L0
[4] SLD move to Home
[5] SLD move: FWD 00 step
[6] FCS Search start
Not used for the servicing.
Press the [RETURN] button if having entered this mode
Screen 7: *Readability Check Menu (Not Used)
(Screen 7)
Readability Check Menu
[1] Disc: Eject
[2] Address: 00000000
[3] Length: 0000
[4] Execute
Jitter P: 0000
Jitter PR: 0000
Jitter DC: 0000
SER: 0000 0000
Not used for the servicing.
Press the [RETURN] button if having entered this mode.
Screen 8: *OP Position Check Menu (Not Used)
(Screen 8)
OP Position Check Menu
[1] Disc: Eject
[2] OP Position Check
Not used for the servicing.
Press the [RETURN] button if having entered this mode.
Screen 9: *OP Check Menu
Purpose: Verify OP related such as delta IOP and LD time
[
M
]/[
m
] Move the cursor up and down
[
3] Start the selected cursor item
[RETURN] Returns to the top menu of the service mode
(Screen 9)
OP Check Menu
Remove DISC and Close tray
[1] Disc Eject
[2] OP Serial: xxxxxxxxxxxxxx
[3] dIOP
BD: x[xx]
DVD: x[xx]
CD: x[xx]
TEMP: xx.x deg
[4] LD ON Time
BD: xxxxh xxm
DVD: xxxxh xxm
CD: xxxxh xxm
Screen 10: *Load Eject Aging (Not Used)
(Screen 10)
Load Eject Aging
[1] Disc: Eject
[2] Repeat set: 00000
[3] Mecha type: Tray mecha
[4] Aging type: Normal
[5] Start
Not used for the servicing.
Press the [RETURN] button if having entered this mode.
Screen 11: *Spindle Control Check Menu (Not Used)
(Screen 11)
Spindle Control Check Menu
[1] Disc : Eject
[2] rpm: 0000 rpm
[3] Spindle: OFF
Not used for the servicing.
Press the [RETURN] button if having entered this mode.
