HBD-E370/E470/E570/E870/T57
78
Pin No. Pin Name I/O Description
F18 VIND7 - Not used
F20 MCIN I Digital audio data input from the A/D converter
F22 AOSDATA3 O Digital audio data output to the S-AIR section
F24 AVSS12_DMPLL - Ground terminal
F26 TN_PLLG - Not used
F28 AVSS33_HDMI - Ground terminal
F30 AVDD12_HDMI - Power supply terminal (+1.2V)
F32 AVSS33_VDACBG - Ground terminal
F34 OPWRSB O Power on/off control signal output to the system controller
F36 ETMDC O Serial data transfer clock signal output to the ethernet interface
F38 ETRXDV I Receive data valid signal input from the ethernet interface
F40 HDMISCK I/O Two-way clock bus with the HDMI ARC OUT connector
F42 SFDO O Serial data output to the serial fl ash
G1 FE_VRDC0 O Voltage output terminal for automatic power control circuit
G3 FE_FG I Motor hole sensor signal input from the motor driver IC
G5 FE_GIO7 O Laser diode on/off control signal output to the BD drive
G7 FE_JTCLK - Not used
G9 FE_GIO6 O MODE C signal output to the BD drive
G11 VOUTVSYNC - Not used
G13 VOUTD18 - Not used
G15 VIND8 O Video format selection signal output to the video amplifi er
G17 VIND10 - Not used
G19 VIND18 I PCM audio data input from the digital audio interface receiver
G21 SPDATA I Digital audio data input from the digital audio interface receiver
G23 AOSDATA1 O Digital audio data output to the power amp and S-AIR section
G25 AVSS33_XTAL - Ground terminal
G27 AVSS33_HDMI - Ground terminal
G29 AVDD12_HDMI - Power supply terminal (+1.2V)
G31 AVDD33_VDACY - Power supply terminal (+3.3V)
G33 LCDRD O Serial data output to the system controller
G35 VCC3IO_STB - Power supply terminal (+3.3V)
G37 DVSS - Ground terminal
G39 HTPLG I Hot plug detection signal input from the HDMI ARC OUT connector
G41 SFCK O Serial data transfer clock signal output to the serial fl ash
G43 NFWEN O Write enable signal output to the NAND fl ash
H2 FE_JTDO - Not used
H4 NS_RFIN I SACD audio data (negative) input terminal
H6 FE_JTRST# - Not used
H8 FE_GIO10 - Not used
H10 VCC3IO_3 - Power supply terminal (+3.3V)
H12 VCC3IO_3 - Power supply terminal (+3.3V)
H14 VIND6 O Video muting on/off control signal output to the video amplifi er
H16 DVSS - Ground terminal
H18 VCC3IO_3 - Power supply terminal (+3.3V)
H20 AMUTE O Muting on/off control signal output terminal Not used
H22 AOSDATA2 O Digital audio data output to the power amp
H24 AVSS12_APLL - Ground terminal
H26 AVDD33_HDMI - Power supply terminal (+3.3V)
H28 AVSS12_HDMI - Ground terminal
H30 AVSS33_VDACY - Ground terminal
H32 AVSS33_VDACR - Ground terminal
H34 ETCRS I Carrier sense signal input from the ethernet interface
H36 DVSS - Ground terminal
H38 AVDD10_LDO - Power supply terminal (+1.0V)
H40 SFDI I Serial data input from the serial fl ash
H42 NFD0 I/O Two-way data bus with the NAND fl ash
J1 FE_HAVC O Reference voltage output to the BD drive
J3 FE_MPXOUT3 - Not used
J5 FE_GIO5 O MODE B signal output to the BD drive
J7 FE_GIO4 O MODE A signal output to the BD drive
