HBD-E370/E470/E570/E870/T57
81
Pin No. Pin Name I/O Description
W23 VCCK - Power supply terminal (+1.1V)
W25 VCCK - Power supply terminal (+1.1V)
W27 VCCK_PWM - Power supply terminal (+1.1V)
W29 VCCK - Power supply terminal (+1.1V)
W31 VCCK - Power supply terminal (+1.1V)
W35 VCC2IO - Power supply terminal (+1.8V)
W37 B_RDQ18 I/O Two-way data bus with the SD-RAM
W39 B_RDQ21 I/O Two-way data bus with the SD-RAM
W41 B_RDQS2 O Data strobe signal (positive) output to the SD-RAM
W43 B_RDQS2B O Data strobe signal (negative) output to the SD-RAM
Y2 FE_RFIP I BD RF signal (positive) input from the BD drive
Y4 FE_RFIN I BD RF signal (negative) input from the BD drive
Y6 FE_LVDS_1N - Not used
Y8 FE_AGND - Ground terminal
Y10 FE_DVDD12I - Power supply terminal (+1.2V)
Y14 DVSS - Ground terminal
Y20 VCCK - Power supply terminal (+1.1V)
Y22 DVSS - Ground terminal
Y24 DVSS - Ground terminal
Y26 DVSS - Ground terminal
Y28 DVSS - Ground terminal
Y30 DVSS - Ground terminal
Y32 VCCK - Power supply terminal (+1.1V)
Y36 B_RDQ23 I/O Two-way data bus with the SD-RAM
Y38 B_RDQ16 I/O Two-way data bus with the SD-RAM
Y40 B_RDQ20 I/O Two-way data bus with the SD-RAM
Y42 B_RDQ22 I/O Two-way data bus with the SD-RAM
AA1 FE_LVDS_2P - Not used
AA3 FE_LVDS_2N - Not used
AA5 FE_LVDS_1P - Not used
AA7 FE_AGND - Ground terminal
AA9 FE_AVDD33_LVDS - Power supply terminal (+3.3V)
AA21 DVSS - Ground terminal
AA23 VCCK - Power supply terminal (+1.1V)
AA25 VCCK - Power supply terminal (+1.1V)
AA27 VCCK - Power supply terminal (+1.1V)
AA29 VCCK - Power supply terminal (+1.1V)
AA31 DVSS - Ground terminal
AA35 DVSS - Ground terminal
AA37 DVSS - Ground terminal
AA39 DVSS - Ground terminal
AA41 B_RDQ17 I/O Two-way data bus with the SD-RAM
AA43 B_RDQ19 I/O Two-way data bus with the SD-RAM
AB2 FE_LVDS_4N - Not used
AB4 FE_LVDS_3N - Not used
AB6 FE_LVDS_5N - Not used
AB8 FE_AVDD12_3 - Power supply terminal (+1.2V)
AB10 FE_DVDD33O - Power supply terminal (+3.3V)
AB12 FE_DVDD33O - Power supply terminal (+3.3V)
AB20 VCCK - Power supply terminal (+1.1V)
AB22 VCCK - Power supply terminal (+1.1V)
AB24 DVSS - Ground terminal
AB26 DVSS - Ground terminal
AB28 DVSS - Ground terminal
AB30 VCCK - Power supply terminal (+1.1V)
AB32 VCCK - Power supply terminal (+1.1V)
AB36 B_RVREF I Reference voltage (+0.9V) input terminal for the SD-RAM
AB40 VCC2IO - Power supply terminal (+1.8V)
AB42 VCC2IO - Power supply terminal (+1.8V)
AC1 FE_LVDS_4P - Not used
