Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HBD-E370/E470/E570/E870/T57
9797
R21 1-216-864-11 SHORT CHIP 0
R22 1-216-837-11 METAL CHIP 22K 5% 1/10W
R23 1-216-809-11 METAL CHIP 100 5% 1/10W
R24 1-216-809-11 METAL CHIP 100 5% 1/10W
R25 1-216-864-11 SHORT CHIP 0
R26 1-216-809-11 METAL CHIP 100 5% 1/10W
R27 1-216-864-11 SHORT CHIP 0
R28 1-216-821-11 METAL CHIP 1K 5% 1/10W
R29 1-216-837-11 METAL CHIP 22K 5% 1/10W
R30 1-216-833-11 METAL CHIP 10K 5% 1/10W
R32 1-216-833-11 METAL CHIP 10K 5% 1/10W
R34 1-216-835-11 METAL CHIP 15K 5% 1/10W
R35 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R36 1-216-864-11 SHORT CHIP 0
R37 1-216-857-11 METAL CHIP 1M 5% 1/10W
R42 1-216-864-11 SHORT CHIP 0
R43 1-216-864-11 SHORT CHIP 0
R44 1-216-837-11 METAL CHIP 22K 5% 1/10W
R45 1-216-837-11 METAL CHIP 22K 5% 1/10W
R46 1-216-841-11 METAL CHIP 47K 5% 1/10W
R47 1-216-841-11 METAL CHIP 47K 5% 1/10W
R48 1-216-837-11 METAL CHIP 22K 5% 1/10W
R49 1-216-837-11 METAL CHIP 22K 5% 1/10W
R50 1-216-841-11 METAL CHIP 47K 5% 1/10W
R51 1-216-841-11 METAL CHIP 47K 5% 1/10W
R52 1-216-864-11 SHORT CHIP 0
R53 1-216-821-11 METAL CHIP 1K 5% 1/10W
R54 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R55 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R56 1-216-864-11 SHORT CHIP 0
R57 1-216-864-11 SHORT CHIP 0
R58 1-216-845-11 METAL CHIP 100K 5% 1/10W
R60 1-216-826-11 METAL CHIP 2.7K 5% 1/10W
R61 1-216-821-11 METAL CHIP 1K 5% 1/10W
R62 1-216-845-11 METAL CHIP 100K 5% 1/10W
R65 1-216-864-11 SHORT CHIP 0
R71 1-216-833-11 METAL CHIP 10K 5% 1/10W
R72 1-216-833-11 METAL CHIP 10K 5% 1/10W
R73 1-216-833-11 METAL CHIP 10K 5% 1/10W
R74 1-216-821-11 METAL CHIP 1K 5% 1/10W
R75 1-216-821-11 METAL CHIP 1K 5% 1/10W
R76 1-216-821-11 METAL CHIP 1K 5% 1/10W
R77 1-216-864-11 SHORT CHIP 0
R85 1-216-834-11 METAL CHIP 12K 5% 1/10W
R86 1-216-835-11 METAL CHIP 15K 5% 1/10W
R87 1-216-821-11 METAL CHIP 1K 5% 1/10W
R88 1-216-864-11 SHORT CHIP 0
0 R89 1-215-865-51 METAL OXIDE 220 5% 1W F
R93 1-216-864-11 SHORT CHIP 0
R99 1-216-821-11 METAL CHIP 1K 5% 1/10W
*************************************************************
CONNECT BOARD
**************
< CONNECTOR >
CN300 1-779-552-21 CONNECTOR, FFC (LIF (NON-ZIF)) 15P
CN301 1-564-722-11 PIN, CONNECTOR (SMALL TYPE) 6P
CN303 1-821-745-11 CONNECTOR, CARD EDGE 30P (L) (EZW-T100)
< TRANSISTOR >
Q300 8-729-029-14 TRANSISTOR DTC144EUA-T106
Q301 6-550-363-01 TRANSISTOR 2SB1690KT146
< RESISTOR >
R300 1-216-817-11 METAL CHIP 470 5% 1/10W
R301 1-216-817-11 METAL CHIP 470 5% 1/10W
R302 1-216-817-11 METAL CHIP 470 5% 1/10W
R303 1-216-841-11 METAL CHIP 47K 5% 1/10W
R307 1-216-833-11 METAL CHIP 10K 5% 1/10W
R308 1-216-833-11 METAL CHIP 10K 5% 1/10W
R309 1-216-833-11 METAL CHIP 10K 5% 1/10W
R311 1-216-833-11 METAL CHIP 10K 5% 1/10W
R320 1-216-864-11 SHORT CHIP 0
*************************************************************
A-1746-097-A FL BOARD, COMPLETE
******************
< CAPACITOR >
C803 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C804 1-126-786-11 ELECT 47uF 20% 16V
C807 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C808 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C810 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C811 1-126-382-11 ELECT 100uF 20% 16V
C812 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C816 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C817 1-163-037-11 CERAMIC CHIP 0.022uF 10% 50V
C818 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C819 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C820 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C821 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C822 1-119-943-91 ELECT 47uF 20% 50V
C823 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C824 1-137-710-91 CERAMIC CHIP 10uF 20% 6.3V
C825 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C826 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C833 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C834 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C837 1-112-746-11 CERAMIC CHIP 4.7uF 10% 6.3V
< CONNECTOR >
CN801 1-779-283-11 CONNECTOR, FFC (LIF (NON-ZIF)) 15P
< DIODE >
D800 6-503-085-01 LED SLD430WBD2PT31XN (ILLUMINATION)
D803 6-500-848-01 DIODE MC2840-T112-1
D804 6-500-848-01 DIODE MC2840-T112-1
D805 6-501-729-01 DIODE MAZ8051GLLS0
D807 6-501-817-01 DIODE MA2J1110GLS0
< IC >
IC801 6-702-302-01 IC TK11133CSCL-G
IC802 6-713-497-01 IC HT16515
IC803 6-600-767-01 IC PNA4823M02S0
< COIL >
L801 1-410-671-31 INDUCTOR 47uH
L802 1-410-671-31 INDUCTOR 47uH
