Sony HCD-BX5BT - OPTICAL PICK-UP BASE ASSEMBLY REMOVAL

Sony HCD-BX5BT
76 pages
Save Page as PDF
Print Icon
To Next Page IconTo Next Page
To Next Page IconTo Next Page
To Previous Page IconTo Previous Page
To Previous Page IconTo Previous Page
Loading...
HCD-BX5BT/CBX1/CBX3
17
2
Remove four solders.
1
flexible flat cable (16 core)
(CN301)
3
CD board
4
op base assy
(KSM-213D)
3-13. OP BASE ASSY (KSM-213D)
