33
(1) TOP CABINET SECTION
SECTION 5
EXPLODED VIEWS
Les composants identifiés par une
marque 0 sont critiquens pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
• Items marked “*” are not stocked since they
are seldom required for routine service. Some
delay should be anticipated when ordering
these items.
• The mechanical parts with no reference num-
ber in the exploded views are not supplied.
• Hardware (# mark) list and accessories and
packing materials are given in the last of the
electrical parts list.
NOTE:
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• Color Indication of Appearance Parts
Example:
KNOB, BALANCE (WHITE) . . . (RED)
↑↑
Parts Color Cabinet's Color
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
1 3-703-136-21 SCREW (M3X12)
2 4-229-459-01 EMBLEM
3 4-230-489-01 DOOR, CD
4 4-230-501-01 HOLDER (R), MAIN PC BOARD
5 4-229-451-01 HOLDER (A), EJECT
6 4-229-473-01 PLATE, CD DOOR
7 4-230-502-01 HOLDER (L), MAIN PC BOARD
8 4-229-452-01 CABINET, TOP
9 A-4475-116-A MAIN BOARD, COMPLETE (US, CND)
Front panel section
#1
#1
#2
#18
#5
#5
#6
#6
#6
5
4
7
9
5
1
8
1
2
6
3
• Abbreviation
CND : Canadian model
