93
HCD-C700/C900
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
IC901 6-800-464-01 IC uPD703033AYGF-M27-3BA
IC902 8-759-828-32 IC PT8300
IC903 8-759-427-92 IC PST9126NL
IC904 8-759-326-78 IC PST9140NL
< JUMPER RESISTOR >
JW900 1-218-941-11 RES-CHIP 100 5% 1/16W
JW901 1-218-941-11 RES-CHIP 100 5% 1/16W
JW902 1-218-941-11 RES-CHIP 100 5% 1/16W
JW903 1-218-990-11 SHORT 0
< COIL >
L600 1-414-754-11 INDUCTOR 10uH
L601 1-414-754-11 INDUCTOR 10uH
< TRANSISTOR >
Q001 8-729-901-00 TRANSISTOR DTC124EKA-T146
Q002 8-729-101-07 TRANSISTOR 2SA1213Y-TE12L
Q900 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q901 8-729-230-63 TRANSISTOR 2SD1819A-QRS-TX
Q902 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q903 8-729-024-91 TRANSISTOR 2SC2712-GL-TE85L
Q906 8-729-024-91 TRANSISTOR 2SC2712-GL-TE85L
Q907 8-729-024-91 TRANSISTOR 2SC2712-GL-TE85L
Q908 8-729-901-00 TRANSISTOR DTC124EKA-T146
Q909 8-729-901-00 TRANSISTOR DTC124EKA-T146
Q910 8-729-901-00 TRANSISTOR DTC124EKA-T146
< RESISTOR >
R001 1-218-990-11 SHORT 0
R002 1-218-990-11 SHORT 0
R003 1-218-990-11 SHORT 0
R004 1-218-990-11 SHORT 0
R005 1-218-990-11 SHORT 0
R006 1-218-990-11 SHORT 0
R007 1-218-990-11 SHORT 0
R008 1-218-990-11 SHORT 0
R009 1-218-953-11 RES-CHIP 1K 5% 1/16W
R010 1-218-990-11 SHORT 0
R011 1-218-953-11 RES-CHIP 1K 5% 1/16W
R012 1-218-990-11 SHORT 0
R013 1-218-990-11 SHORT 0
R014 1-218-990-11 SHORT 0
R015 1-218-990-11 SHORT 0
R016 1-218-990-11 SHORT 0
R017 1-218-990-11 SHORT 0
R018 1-218-990-11 SHORT 0
R019 1-218-990-11 SHORT 0
R020 1-218-990-11 SHORT 0
R021 1-218-990-11 SHORT 0
R022 1-218-990-11 SHORT 0 (AEP, UK)
R023 1-218-990-11 SHORT 0
R024 1-218-990-11 SHORT 0 (AEP, UK)
R025 1-218-990-11 SHORT 0
R026 1-218-990-11 SHORT 0
R027 1-218-990-11 SHORT 0
R028 1-218-990-11 SHORT 0
R029 1-218-990-11 SHORT 0
R030 1-218-990-11 SHORT 0
R031 1-218-990-11 SHORT 0
R032 1-218-990-11 SHORT 0
R033 1-218-990-11 SHORT 0
R034 1-218-990-11 SHORT 0
R035 1-218-990-11 SHORT 0
R036 1-218-990-11 SHORT 0
R037 1-218-990-11 SHORT 0
R038 1-218-990-11 SHORT 0
R039 1-218-990-11 SHORT 0
R040 1-218-990-11 SHORT 0
R041 1-218-990-11 SHORT 0
R042 1-218-990-11 SHORT 0
R043 1-218-990-11 SHORT 0
R044 1-218-990-11 SHORT 0
R045 1-218-990-11 SHORT 0
R046 1-218-990-11 SHORT 0
R047 1-218-990-11 SHORT 0
R048 1-218-990-11 SHORT 0
R049 1-218-990-11 SHORT 0
R050 1-218-990-11 SHORT 0
R051 1-218-990-11 SHORT 0
R052 1-218-990-11 SHORT 0
R053 1-218-990-11 SHORT 0
R055 1-218-990-11 SHORT 0
R056 1-218-990-11 SHORT 0
R057 1-218-990-11 SHORT 0
R058 1-218-990-11 SHORT 0
R063 1-218-990-11 SHORT 0
R065 1-218-990-11 SHORT 0
R068 1-218-990-11 SHORT 0
R069 1-218-990-11 SHORT 0
R070 1-218-990-11 SHORT 0
R075 1-218-990-11 SHORT 0
R076 1-218-969-11 RES-CHIP 22K 5% 1/16W
R077 1-218-947-11 RES-CHIP 330 5% 1/16W
R078 1-218-959-11 RES-CHIP 3.3K 5% 1/16W
R079 1-208-643-11 RES-CHIP 22 5% 1/16W
R101 1-216-298-00 METAL CHIP 2.2 5% 1/10W
R105 1-218-965-11 RES-CHIP 10K 5% 1/16W
R106 1-218-965-11 RES-CHIP 10K 5% 1/16W
R107 1-218-990-11 SHORT 0
R109 1-208-635-11 METAL CHIP 10 0.5% 1/16W
R111 1-218-949-11 RES-CHIP 470 5% 1/16W
R112 1-218-953-11 RES-CHIP 1K 5% 1/16W
R113 1-218-965-11 RES-CHIP 10K 5% 1/16W
R114 1-208-935-11 METAL CHIP 100K 0.5% 1/16W
R116 1-218-965-11 RES-CHIP 10K 5% 1/16W
R117 1-218-953-11 RES-CHIP 1K 5% 1/16W
R118 1-218-953-11 RES-CHIP 1K 5% 1/16W
R119 1-218-965-11 RES-CHIP 10K 5% 1/16W
DVD
