HCD-C700/C900
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
< FILTER >
FL801 1-518-767-21 INDICATOR TUBE, FLUORESCENT
< IC >
IC801 8-759-366-45 IC NJU3713G(TE2)
IC802 6-700-112-01 IC MSM9202-05GS-KDR1
< COIL >
L900 1-410-387-11 INDUCTOR CHIP 33uH
L901 1-410-387-11 INDUCTOR CHIP 33uH
L902 1-412-002-31 INDUCTOR 4.7uH
L903 1-412-002-31 INDUCTOR 4.7uH
< TRANSISTOR >
Q801 8-729-602-36 TRANSISTOR 2SA1602TP-1EF
< RESISTOR >
R805 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R810 1-216-809-11 METAL CHIP 100 5% 1/16W
R811 1-216-809-11 METAL CHIP 100 5% 1/16W
R812 1-216-809-11 METAL CHIP 100 5% 1/16W
R813 1-216-809-11 METAL CHIP 100 5% 1/16W
R814 1-216-841-11 METAL CHIP 47K 5% 1/16W
R839 1-216-864-11 METAL CHIP 0 5% 1/16W
R840 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R841 1-216-809-11 METAL CHIP 100 5% 1/16W
R842 1-216-809-11 METAL CHIP 100 5% 1/16W
R843 1-216-809-11 METAL CHIP 100 5% 1/16W
************************************************************
1-681-999-11 FU-1098 BOARD
*************
< CAPACITOR >
C800 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C801 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C808 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C809 1-126-153-11 ELECT 22uF 20% 6.3V
(US, CND)
C809 1-126-514-11 ELECT 22uF 20.00% 6.3V
(EXCEPT US, CND)
< IC >
IC800 8-759-827-70 IC NJL64H400A-1 ( ) (US, CND)
IC800 8-759-459-86 IC NJL64H400A ( ) (EXCEPT US, CND)
< RESISTOR >
R809 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R815 1-216-805-11 METAL CHIP 47 5% 1/16W
R837 1-216-821-11 METAL CHIP 1K 5% 1/16W
R838 1-216-805-11 METAL CHIP 47 5% 1/16W
R844 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R849 1-216-824-11 METAL CHIP 1.8K 5% 1/16W
R860 1-216-826-11 METAL CHIP 2.7K 5% 1/16W
R873 1-216-809-11 METAL CHIP 100 5% 1/16W
< SWITCH >
S800 1-418-632-11 ENCODER, ROTARY (VOLUME)
S821 1-762-875-21 SWITCH, KEYBOARD (SOUND FIELD+)
S822 1-762-875-21 SWITCH, KEYBOARD (SOUND FIELD-)
S823 1-762-875-21 SWITCH, KEYBOARD (DISPLAY)
S824 1-762-875-21 SWITCH, KEYBOARD (BAND)
S825 1-762-875-21 SWITCH, KEYBOARD (FUNCTION)
************************************************************
1-682-003-11 HP-1089 BOARD
*************
< CAPACITOR >
C900 1-124-234-00 ELECT 22uF 20% 16V
C901 1-124-234-00 ELECT 22uF 20% 16V
C902 1-163-011-11 CERAMIC CHIP 0.0015uF 10% 50V
C903 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V
C904 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V
< FERRITE BEAD >
FB803 1-469-144-21 FERRITE 0uH
FB804 1-469-144-21 FERRITE 0uH
FB805 1-469-144-21 FERRITE 0uH
< JACK >
J900 1-566-891-21 JACK (PHONES)
< TRANSISTOR >
Q900 8-729-046-97 TRANSISTOR 2SD1938(F)-T(TX).SO
Q901 8-729-046-97 TRANSISTOR 2SD1938(F)-T(TX).SO
< RESISTOR >
R900 1-216-833-11 METAL CHIP 10K 5% 1/16W
R901 1-216-821-11 METAL CHIP 1K 5% 1/16W
R902 1-216-833-11 METAL CHIP 10K 5% 1/16W
R903 1-216-821-11 METAL CHIP 1K 5% 1/16W
R905 1-216-821-11 METAL CHIP 1K 5% 1/16W
R906 1-216-821-11 METAL CHIP 1K 5% 1/16W
************************************************************
1-675-724-21 INIT/COUNT SW BOARD
*******************
< SWITCH >
S705 1-771-264-11 SWITCH, PUSH(DETECTION)(1 KEY) (INIT)
S706 1-771-264-11 SWITCH, PUSH(DETECTION)(1 KEY) (COUNT)
************************************************************
1-675-723-21 IN SW BOARD
***********
< CONNECTOR >
* CN710 1-568-941-11 PIN, CONNECTOR 3P
< SWITCH >
S703 1-771-218-11 SWITCH, MICRO (MID IN)
S704 1-771-218-11 SWITCH, MICRO (IN)
************************************************************
FP-1089 FU-1098 HP-1089 INIT/COUNT SW IN SW
