101
HCD-C700/C900
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
< JACK >
J600 1-816-039-11 JACK, PIN 3P
(VIDEO1 VIDEO OUT/AUDIO OUT L R)
J601 1-816-039-11 JACK, PIN 3P (VIDEO1 VIDEO IN/AUDIO IN L R)
J602 1-816-039-11 JACK, PIN 3P (VIDEO2 VIDEO IN/AUDIO IN L R)
J700 1-815-748-11 JACK, PIN 2P (MONITOR OUT VIDEO/S VIDEO)
< COIL >
L600 1-216-295-00 SHORT 0
L601 1-469-525-91 INDUCTOR 10uH
L700 1-412-953-11 INDUCTOR 15uH (US, CND)
L700 1-412-939-11 INDUCTOR 1uH (EXCEPT US, CND)
L702 1-469-525-91 INDUCTOR 10uH
L703 1-412-953-11 INDUCTOR 15uH (US, CND)
L703 1-412-939-11 INDUCTOR 1uH (EXCEPT US, CND)
L705 1-412-953-11 INDUCTOR 15uH (US, CND)
L705 1-412-939-11 INDUCTOR 1uH (EXCEPT US, CND)
L707 1-469-525-91 INDUCTOR 10uH
L708 1-412-953-11 INDUCTOR 15uH
L710 1-412-953-11 INDUCTOR 15uH
< TRANSISTOR >
Q600 8-729-801-93 TRANSISTOR 2SD1387-34-TP
Q601 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q602 8-729-901-00 TRANSISTOR DTC124EKA-T146
Q603 8-729-901-00 TRANSISTOR DTC124EKA-T146
Q604 8-729-901-00 TRANSISTOR DTC124EKA-T146
Q605 8-729-046-97 TRANSISTOR 2SD1938(F)-T(TX).SO
Q606 8-729-046-97 TRANSISTOR 2SD1938(F)-T(TX).SO
Q607 8-729-120-28 TRANSISTOR 2SC2412K-T-146-QR
(AEP, UK)
Q700 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R
Q701 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q702 8-729-024-91 TRANSISTOR 2SC2712-GL-TE85L
Q703 8-729-024-91 TRANSISTOR 2SC2712-GL-TE85L
Q704 1-801-806-11 TRANSISTOR DTC144EKA-T146
< RESISTOR >
R600 1-216-033-00 METAL CHIP 220 5% 1/10W
(EXCEPT US)
R600 1-216-813-11 METAL CHIP 220 5% 1/16W
(US)
R601 1-216-033-00 METAL CHIP 220 5% 1/10W
(EXCEPT US)
R601 1-216-813-11 METAL CHIP 220 5% 1/16W
(US)
R602 1-216-033-00 METAL CHIP 220 5% 1/10W
(EXCEPT US)
R602 1-216-813-11 METAL CHIP 220 5% 1/16W
(US)
R603 1-216-033-00 METAL CHIP 220 5% 1/10W
(EXCEPT US)
R603 1-216-813-11 METAL CHIP 220 5% 1/16W
(US)
R604 1-216-033-00 METAL CHIP 220 5% 1/10W
(EXCEPT US)
R604 1-216-813-11 METAL CHIP 220 5% 1/16W
(US)
R605 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
(EXCEPT US)
R605 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
(US)
R606 1-216-066-00 METAL CHIP 5.1K 5% 1/10W
(EXCEPT US)
R606 1-218-272-11 RES-CHIP 5.1K 5% 1/16W
(US)
R607 1-216-066-00 METAL CHIP 5.1K 5% 1/10W
(EXCEPT US)
R607 1-218-272-11 RES-CHIP 5.1K 5% 1/16W
(US)
R608 1-216-295-00 SHORT 0 (EXCEPT US)
R608 1-216-864-11 METAL CHIP 0 5% 1/16W
(US)
R609 1-216-073-00 RES-CHIP 10K 5% 1/10W
(EXCEPT US)
R609 1-216-833-11 METAL CHIP 10K 5% 1/16W
(US)
R610 1-216-073-00 RES-CHIP 10K 5% 1/10W
(EXCEPT US)
R610 1-216-833-11 METAL CHIP 10K 5% 1/16W
(US)
R611 1-216-025-11 RES-CHIP 100 5% 1/10W
(EXCEPT US)
R611 1-216-809-11 METAL CHIP 100 5% 1/16W
(US)
R612 1-216-073-00 RES-CHIP 10K 5% 1/10W
(EXCEPT US)
R612 1-216-833-11 METAL CHIP 10K 5% 1/16W
(US)
R613 1-216-073-00 RES-CHIP 10K 5% 1/10W
(EXCEPT US)
R613 1-216-833-11 METAL CHIP 10K 5% 1/16W
(US)
R614 1-216-025-11 RES-CHIP 100 5% 1/10W
(EXCEPT US)
R614 1-216-809-11 METAL CHIP 100 5% 1/16W
(US)
R615 1-216-097-11 RES-CHIP 100K 5% 1/10W
(EXCEPT AEP, UK)
R615 1-216-845-11 METAL CHIP 100K 5% 1/16W
(AEP,UK)
R616 1-216-097-11 RES-CHIP 100K 5% 1/10W
(EXCEPT AEP, UK)
R616 1-216-845-11 METAL CHIP 100K 5% 1/16W
(AEP,UK)
R617 1-216-073-00 RES-CHIP 10K 5% 1/10W
(EXCEPT US)
R617 1-216-833-11 METAL CHIP 10K 5% 1/16W
(US)
R618 1-216-073-00 RES-CHIP 10K 5% 1/10W
(EXCEPT US)
R618 1-216-833-11 METAL CHIP 10K 5% 1/16W
(US)
R619 1-216-049-11 RES-CHIP 1K 5% 1/10W
(EXCEPT US)
R619 1-216-821-11 METAL CHIP 1K 5% 1/16W
(US)
I/O
