HCD-C700/C900
US Model
Canadian Model
HCD-C700/C900
AEP Model
UK Model
E Model
Australian Model
HCD-C700
SERVICE MANUAL
COMPACT AV SYSTEM
HCD-C700/C900 are the amplifier, DVD/CD and
tuner section in DAV-C700/C900.
SPECIFICATIONS
Ver. 1.5 2005.10
Model Name Using Similar Mechanism NEW
Mechanism Type CDM53K-DVBU7
Base Unit Name DVBU7
Optical Pick-up Name KHM-240AAA
AUDIO POWER SPECIFICATIONS
POWER OUTPUT AND TOTAL HARMONIC DISTORTION:
With 6 ohm loads, both channels driven, from 120 – 10,000 Hz; rated
50 watts per channel minimum RMS power, with no more than 10 %
total harmonic distortion from 250 milliwatts to rated output.
Amplifier section
Stereo mode 50 W + 50 W (6 ohms at 1 kHz, THD 10 %)
Surround mode Front: 50 W + 50 W
Center*: 50 W
Rear*: 50 W + 50 W (6 ohms at 1 kHz, THD 10 %)
Subwoofer*: 100 W (3 ohms at 100 Hz, THD 10 %)
* Depending on the sound field settings and the source, there may be no sound output.
Inputs (Analog) VIDEO 1, 2:
Sensitivity: 150 mV
Impedance: 50 kilohms
Inputs (Digital) VIDEO 2 (optical):
Sensitivity: –
Outputs (Analog) VIDEO 1 (AUDIO OUT):
Voltage: 2 V
Impedance: 1 kilohms
PHONES:
Accepts low- and high-impedance headphones
Outputs (Digital) DIGITAL OUT (CD)
Sensitivity: –
SACD/DVD system
Laser Semiconductor laser
Signal format system NTSC or NTSC/PAL
Frequency response (at 2 CH STEREO mode)
DVD (PCM): 2 Hz to 22 kHz (±1.0 dB)
CD: 2 Hz to 20 kHz (±1.0 dB)
Signal-to-noise ratio More than 80 dB (VIDEO 1 (AUDIO) connectors only)
Harmonic distortion Less than 0.03 %
FM tuner section
System PLL quartz-locked digital synthesizer system
North American model: 87.5 – 108.0 MHz (100 kHz step)
Other models: 87.5 – 108.0 MHz (50 kHz step)
Antenna FM wire antenna
Antenna terminals 75 ohms, unbalanced
Intermediate frequency 10.7 MHz
AM tuner section
System Tuner section:
PLL quartz-locked digital synthesizer system
Tuning range
North American model: 530 – 1,710 kHz (with the interval set at 10 kHz)
531 – 1,710 kHz (with the interval set at 9 kHz)
European, Middle Eastern, and Philipinne models:
531 – 1,602 kHz (with the interval set at 9 kHz)
Other models: 531 – 1,602 kHz (with the interval set at 9 kHz)
530 – 1,710 kHz (with the interval set at 10 kHz)
Antenna Loop antenna
Video section
Inputs Video: 1 Vp-p 75 ohms
Outputs Video: 1 Vp-p 75 ohms
S-video:
Y: 1 Vp-p 75 ohms
C: 0.286 Vp-p 75 ohms
General
Power requirements
North American model: 120 V AC, 60 Hz
European model: 220 – 240 V AC, 50/60 Hz
Australian and Asian models: 220 – 240 V AC, 50/60 Hz
Mexican model: 120 V AC, 60 Hz
Other models: 110 – 240 V/ 220 – 240 V AC, 50/60 Hz
Power consumption 105 W (120 V AC), 105 W (230 V AC)
Dimensions (approx.) 355 100 394 mm (14 × 4 × 15
5
/
8
inches) (w/h/d) incl. projecting
parts
Mass (approx.) 5.7 kg (12 lb 10 oz)
Operating temperature 5˚C to 35˚C (41˚F to 95˚F)
Operating humidity 5 % to 90 %
Design and specifications are subject to change without notice.
C900 MODEL
C700 MODEL
Stereo mode 70 W + 70 W (4 ohms at 1 kHz, THD 10 %)
Surround mode Front: 70 W + 70 W
Center*: 70 W
Rear*: 50 W + 50 W (6 ohms at 1 kHz, THD 10 %)
Subwoofer*: 100 W (3 ohms at 100 Hz, THD 10 %)
Sony Corporation
Home Audio Division
Published by Sony Engineering Corporation
9-873-327-06
2005J16-1
© 2005.10
Photo : HCD-C700
