– 40 –
• Waveforms
— BD Section—
1 IC101 #£ pin (PLAY MODE)
5 IC103 ^º pin (XPCK)
2 IC101 2 pin (FEI) (PLAY MODE)
3 IC101 $¶ pin (TEI) (PLAY MODE)
6 IC103 ^™ pin (RFCK)
7 IC103 &¢ pin (WFCK)
!¡ IC301 !£ pin (XT2)
— TUNER Section—
!™ IC1 @¢ pin (XOUT) (EXCEPT AEP, UK,EE,
CIS)
IC21 @¢ pin (X OUT) (AEP, UK,EE, CIS)
4 IC103 @¶ pin (MDP)
8 IC103 *ª pin (XTAI)
Approx. 1.3 Vp-p
5.6 V
135.5
µ
sec
4.6 Vp-p
31.3
µ
sec
Approx. 0.1
V
7
V
230 nsec
Approx. 0.2
V
10
V
59.8 nsec
9 IC601 !¤ pin (X-OUT)
4.3
125 nsec
5.7
V
200 nsec
— PANEL Section—
0 IC301 0 pin (X2)
— MAIN Section—
!£ IC2 @£ pin (VCO) (EXCEPT AEP, UK,EE,
CIS)
IC41 @£ pin (VCO) (AEP, UK,EE, CIS)
• Abbreviation
EE : East European model
4.8 Vp-p
2.2 nsec
4.8 Vp-p
222 nsec
5.6 V
135.5
µ
sec
2.4
V
7.8
µ
sec
