– 116 –
< CAPACITOR >
C101 1-162-288-31 CERAMIC 330PF 10% 50V
(AEP,UK,EE,CIS)
C102 1-162-282-31 CERAMIC 100PF 10% 50V
C103 1-162-282-31 CERAMIC 100PF 10% 50V
C104 1-126-962-11 ELECT 3.3uF 20% 50V
C105 1-162-600-11 CERAMIC 0.0047uF 30% 16V
C106 1-162-301-11 CERAMIC 0.0015uF 30% 16V
C107 1-126-956-91 ELECT 0.1uF 20% 50V
C108 1-126-967-11 ELECT 47uF 20% 10V
(AEP,UK,EE,CIS)
C109 1-164-159-21 CERAMIC 0.1uF 50V
(AEP,UK,EE,CIS)
C121 1-162-286-21 CERAMIC 220PF 10% 50V
C123 1-162-306-11 CERAMIC 0.01uF 20% 16V
C131 1-136-495-11 FILM 0.068uF 5% 50V
(AEP,UK,EE,CIS)
C132 1-136-495-11 FILM 0.068uF 5% 50V
(AEP,UK,EE,CIS)
C133 1-162-294-31 CERAMIC 0.001uF 10% 50V
(AEP,UK,EE,CIS)
C134 1-164-159-21 CERAMIC 0.1uF 50V
(AEP,UK,EE,CIS)
C151 1-162-288-31 CERAMIC 330PF 10% 50V
(AEP,UK,EE,CIS)
C152 1-162-282-31 CERAMIC 100PF 10% 50V
C153 1-162-282-31 CERAMIC 100PF 10% 50V
C154 1-126-962-11 ELECT 3.3uF 20% 50V
C155 1-162-600-11 CERAMIC 0.0047uF 30% 16V
C156 1-162-301-11 CERAMIC 0.0015uF 30% 16V
C157 1-126-956-91 ELECT 0.1uF 20% 50V
C158 1-126-967-11 ELECT 47uF 20% 10V
(AEP,UK,EE,CIS)
C171 1-162-286-21 CERAMIC 220PF 10% 50V
C173 1-162-306-11 CERAMIC 0.01uF 20% 16V
C181 1-136-495-11 FILM 0.068uF 5% 50V
(AEP,UK,EE,CIS)
C182 1-136-495-11 FILM 0.068uF 5% 50V
(AEP,UK,EE,CIS)
C183 1-162-294-31 CERAMIC 0.001uF 10% 50V
(AEP,UK,EE,CIS)
C184 1-164-159-21 CERAMIC 0.1uF 50V
(AEP,UK,EE,CIS)
C201 1-136-167-00 FILM 0.15uF 5% 50V
C202 1-136-167-00 FILM 0.15uF 5% 50V
C203 1-130-493-00 MYLAR 0.068uF 5% 50V
C204 1-130-493-00 MYLAR 0.068uF 5% 50V
C205 1-130-486-00 MYLAR 0.018uF 10% 50V
C206 1-130-486-00 MYLAR 0.018uF 10% 50V
C207 1-130-480-00 MYLAR 0.0056uF 5% 50V
C208 1-130-479-00 MYLAR 0.0047uF 5% 50V
C209 1-130-474-00 MYLAR 0.0018uF 5% 50V
C210 1-126-964-11 ELECT 10uF 20% 50V
C211 1-126-964-11 ELECT 10uF 20% 50V
C212 1-130-483-00 MYLAR 0.01uF 5% 50V
C213 1-136-171-00 FILM 0.33uF 5% 50V
C214 1-136-171-00 FILM 0.33uF 5% 50V
C215 1-162-294-31 CERAMIC 0.001uF 10% 50V
C216 1-136-167-00 FILM 0.15uF 5% 50V
C221 1-126-967-11 ELECT 47uF 20% 10V
R769 1-247-885-00 CARBON 180K 5% 1/4W
R770 1-247-807-31 CARBON 100 5% 1/4W
< VARIABLE RESISTOR >
RV760 1-225-366-11 RES, VAR, CARBON 50K (MIC LEVEL)
************************************************************
* 1-650-669-11 LEAF SWITCH BOARD
*****************
< CONNECTOR >
* CN1001 1-568-854-11 SOCKET, CONNECTOR 11P
< TRANSISTOR >
Q1001 8-749-010-90 TRANSISTOR PHOTO REFLECTOR
NJL5165KA-H
Q1002 8-749-010-90 TRANSISTOR PHOTO REFLECTOR
NJL5165KA-H
< RESISTOR >
R1001 1-247-818-11 CARBON 300 5% 1/4W
R1002 1-247-820-11 CARBON 360 5% 1/4W
R1003 1-249-414-11 CARBON 560 5% 1/4W
R1004 1-247-834-11 CARBON 1.3K 5% 1/4W
R1005 1-247-818-11 CARBON 300 5% 1/4W
< SWITCH >
S1001 1-692-832-11 SWITCH, PUSH (1 KEY) (A PLAY)
S1002 1-692-832-11 SWITCH, PUSH (1 KEY) (B PLAY)
S1003 1-572-248-11 SWITCH, LEAF (A HALF)
S1004 1-571-281-21 SWITCH, LEAF (A CrO2)
S1005 1-571-281-21 SWITCH, LEAF (REC A)
S1006 1-572-248-11 SWITCH, LEAF (B HALF)
S1008 1-571-281-21 SWITCH, LEAF (B CrO2)
S1009 1-571-281-21 SWITCH, LEAF (REC B)
************************************************************
* 1-664-017-11 LED BOARD
*********
< CONNECTOR >
CN671 1-506-481-11 PIN, CONNECTOR 2P
< DIODE >
D671 8-719-058-03 DIODE SEL5423E-TP15
D672 8-719-058-03 DIODE SEL5423E-TP15
D673 8-719-058-03 DIODE SEL5423E-TP15
D674 8-719-058-03 DIODE SEL5423E-TP15
< RESISTOR >
R791 1-249-412-11 CARBON 390 5% 1/4W
************************************************************
* A-4392-407-A MAIN BOARD, COMPLETE (US,CND)
* A-4392-430-A MAIN BOARD, COMPLETE (AEP,UK)
* A-4392-433-A MAIN BOARD, COMPLETE (E,AR,MX)
* A-4392-742-A MAIN BOARD, COMPLETE (AUS)
* A-4398-674-A MAIN BOARD, COMPLETE (EE,CIS)
***************************
* 4-870-539-11 PLATE, GROUND
7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
