* A-4392-412-A PANEL BOARD, COMPLETE
**********************
* 4-986-870-11 HOLDER, FL TUBE
< CAPACITOR
C601 1-126-967-11 ELECT 47uF 20% 50V
C602 1-162-306-11 CERAMIC 0.01uF 20% 16V
C603 1-126-963-11 ELECT 4.7uF 20% 50V
C604 1-126-960-11 ELECT 1uF 20% 50V
C606 1-126-960-11 ELECT 1uF 20% 50V
C608 1-124-584-00 ELECT 100uF 20% 10V
C610 1-162-306-11 CERAMIC 0.01uF 20% 16V
C611 1-162-306-11 CERAMIC 0.01uF 20% 16V
C612 1-126-967-11 ELECT 47uF 20% 50V
C613 1-164-159-21 CERAMIC 0.1uF 50V
C621 1-126-960-11 ELECT 1uF 20% 50V
C622 1-136-161-00 FILM 0.047uF 5% 50V
C623 1-126-957-11 ELECT 0.22uF 20% 50V
C624 1-126-957-11 ELECT 0.22uF 20% 50V
C625 1-162-306-11 CERAMIC 0.01uF 20% 16V
C626 1-126-957-11 ELECT 0.22uF 20% 50V
C627 1-136-159-00 FILM 0.033uF 5% 50V
C628 1-162-302-11 CERAMIC 0.0022uF 30% 16V
C629 1-126-957-11 ELECT 0.22uF 20% 50V
C630 1-162-293-31 CERAMIC 820PF 10% 50V
C631 1-126-957-11 ELECT 0.22uF 20% 50V
C632 1-126-957-11 ELECT 0.22uF 20% 50V
C641 1-162-286-21 CERAMIC 220PF 10% 50V
C642 1-162-286-21 CERAMIC 220PF 10% 50V
C643 1-162-286-21 CERAMIC 220PF 10% 50V
C644 1-162-286-21 CERAMIC 220PF 10% 50V
C645 1-162-286-21 CERAMIC 220PF 10% 50V
C646 1-162-286-21 CERAMIC 220PF 10% 50V
C647 1-162-286-21 CERAMIC 220PF 10% 50V
C648 1-162-286-21 CERAMIC 220PF 10% 50V
C649 1-162-286-21 CERAMIC 220PF 10% 50V
C650 1-162-286-21 CERAMIC 220PF 10% 50V
C651 1-162-286-21 CERAMIC 220PF 10% 50V
C652 1-162-286-21 CERAMIC 220PF 10% 50V
C653 1-162-286-21 CERAMIC 220PF 10% 50V
C654 1-162-286-21 CERAMIC 220PF 10% 50V
C655 1-162-286-21 CERAMIC 220PF 10% 50V
C656 1-162-286-21 CERAMIC 220PF 10% 50V
C695 1-164-159-21 CERAMIC 0.1uF 50V
C696 1-164-159-21 CERAMIC 0.1uF 50V
C697 1-162-294-31 CERAMIC 0.001uF 10% 50V
< CONNECTOR >
* CN601 1-568-836-11 SOCKET, CONNECTOR 17P
* CN602 1-568-947-11 PIN, CONNECTOR 9P
CN603 1-506-486-11 PIN, CONNECTOR 7P
* CN604 1-568-947-11 PIN, CONNECTOR 9P
< DIODE >
D601 8-719-987-63 DIODE 1N4148M
D602 8-719-987-63 DIODE 1N4148M
D603 8-719-987-63 DIODE 1N4148M
D604 8-719-987-63 DIODE 1N4148M
D605 8-719-987-63 DIODE 1N4148M
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R917 1-247-815-91 CARBON 220 5% 1/4W
R918 1-249-425-11 CARBON 4.7K 5% 1/4W
R920 1-249-417-11 CARBON 1K 5% 1/4W
R921 1-247-895-91 CARBON 470K 5% 1/4W
R951 1-249-425-11 CARBON 4.7K 5% 1/4W
R952 1-249-425-11 CARBON 4.7K 5% 1/4W
R1501 1-249-435-11 CARBON 33K 5% 1/4W
R1502 1-249-417-11 CARBON 1K 5% 1/4W
R1503 1-249-426-11 CARBON 5.6K 5% 1/4W
R1504 1-247-840-00 CARBON 2.4K 5% 1/4W
R1505 1-247-863-91 CARBON 22K 5% 1/4W
R1506 1-249-421-11 CARBON 2.2K 5% 1/4W
R1507 1-249-428-11 CARBON 8.2K 5% 1/4W
R1521 1-249-430-11 CARBON 12K 5% 1/4W
R1522 1-249-426-11 CARBON 5.6K 5% 1/4W
R1524 1-249-429-11 CARBON 10K 5% 1/4W
R1525 1-249-432-11 CARBON 18K 5% 1/4W
R1526 1-249-429-11 CARBON 10K 5% 1/4W
R1527 1-249-429-11 CARBON 10K 5% 1/4W
R1531 1-247-843-11 CARBON 3.3K 5% 1/4W
R1532 1-249-411-11 CARBON 330 5% 1/4W
R1533 1-249-427-11 CARBON 6.8K 5% 1/4W
R1534 1-249-429-11 CARBON 10K 5% 1/4W
R1535 1-249-425-11 CARBON 4.7K 5% 1/4W
R1536 1-249-425-11 CARBON 4.7K 5% 1/4W
R1541 1-249-425-11 CARBON 4.7K 5% 1/4W
R1542 1-249-425-11 CARBON 4.7K 5% 1/4W
R1543 1-249-425-11 CARBON 4.7K 5% 1/4W
R1544 1-249-417-11 CARBON 1K 5% 1/4W
R1545 1-249-437-11 CARBON 47K 5% 1/4W
R1546 1-249-437-11 CARBON 47K 5% 1/4W
R1547 1-249-437-11 CARBON 47K 5% 1/4W
R1548 1-249-437-11 CARBON 47K 5% 1/4W
R1551 1-247-863-91 CARBON 22K 5% 1/4W
R1552 1-249-417-11 CARBON 1K 5% 1/4W
R1553 1-249-426-11 CARBON 5.6K 5% 1/4W
R1554 1-247-840-00 CARBON 2.4K 5% 1/4W
R1555 1-247-863-91 CARBON 22K 5% 1/4W
R1556 1-249-421-11 CARBON 2.2K 5% 1/4W
R1557 1-249-428-11 CARBON 8.2K 5% 1/4W
< VARIABLE RESISTOR >
RV1501 1-238-598-11 RES, ADJ, CARBON 2.2K
RV1551 1-238-598-11 RES, ADJ, CARBON 2.2K
< RELAY >
RY141 1-755-141-11 RELAY
< TERMINAL >
TM131 1-537-240-31 TERMINAL BOARD (CHECKER PIN)
(SPEAKER)
TM132 1-537-240-31 TERMINAL BOARD (CHECKER PIN)
(SURROUND)
< VIBRATOR >
X301 1-760-489-11 VIBRATOR, CERAMIC (5MHz)
X302 1-567-098-41 VIBRATOR, CRYSTAL (32.768KHz)
************************************************************
