R1721 1-216-073-00 METAL CHIP 10K 5% 1/10W
(EE,CIS)
< VARIABLE RESISTOR >
RV41 1-238-600-11 ADJ, CARBON 10K (EXCEPT AEP,UK,EE,CIS)
RV41 1-238-601-11 ADJ, CARBON 22K (AEP,UK,EE,CIS)
RV42 1-238-600-11 ADJ, CARBON 10K (AEP,UK,EE,CIS)
RV42 1-238-601-11 ADJ, CARBON 22K (EXCEPT AEP,UK,EE,CIS)
RV1701 1-238-600-11 ADJ, CARBON 10K (EE,CIS)
RV1702 1-238-599-11 ADJ, CARBON 4.7K (EE,CIS)
< TERMINAL >
TM1 1-537-238-21 TERMINAL BOARD (ANTENNA)
(EXCEPT AEP,UK,EE,CIS)
TM1 1-537-488-11 TERMINAL BOARD (ANT)(ANTENNA)
(AEP,UK,EE,CIS)
< VIBRATOR >
X21 1-760-549-11 VIBRATOR, CRYSTAL (4.5MHz)
X41 1-577-075-11 OSCILLATOR, CERAMIC (456KHz)
(EXCEPT AEP,UK,EE,CIS)
X41 1-760-220-11 FILTER, CERAMIC (AEP,UK,EE,CIS)
X42 1-527-981-00 FILTER, CERAMIC (AEP,UK,EE,CIS)
X42 1-760-220-11 FILTER, CERAMIC (EXCEPT AEP,UK,EE,CIS)
X43 1-527-981-00 FILTER, CERAMIC (EXCEPT AEP,UK,EE,CIS)
X43 1-577-075-11 OSCILLATOR, CERAMIC (456KHz)
(EXCEPT AEP,UK,EE,CIS)
************************************************************
* 1-664-014-11 TRANS BOARD
***********
1-533-399-31 HOLDER, FUSE
< CONNECTOR >
* CN901 1-564-522-11 PLUG, CONNECTOR 7P
* CN902 1-564-518-11 PLUG, CONNECTOR 3P
CN903 1-774-108-11 PIN, CONNECTOR (PC BOARD)
< CONNECTOR >
! CNP901 1-558-943-41 CORD,POWER (E,MX)
! CNP901 1-575-042-21 CORD,POWER (US,CND)
! CNP901 1-575-651-21 CORD,POWER (AEP,EE,CIS,AR)
! CNP901 1-696-845-11 CORD,POWER (AUS)
! CNP901 1-751-529-11 CORD,POWER (UK)
< FUSE >
! F901 1-532-388-31 FUSE,TIME-LAG (2A,250V)
(EXCEPT US,CND,MX)
! F902 1-532-504-31 FUSE,TIME-LAG (4A,250V) (E,AR.MX)
! F902 1-533-310-11 FUSE,GLASS TUBE (6.3A,125V) (US)
! F902 1-533-420-11 FUSE,GLASS CYLINDRICAL
(DIA.5) (5A,125V) (CND)
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
< RESISTOR >
! R901 1-219-119-81 FUSIBLE 0.1 5% 1/4W F
(EXCEPT E,AR,MX,AUS)
! R901 1-219-124-11 FUSIBLE 0.68 5% 1/4W F
(E,AR,MX,AUS)
! R902 1-219-119-81 FUSIBLE 0.1 5% 1/4W F
(EXCEPT E,AR,MX,AUS)
! R902 1-219-124-11 FUSIBLE 0.68 5% 1/4W F
(E,AR,MX,AUS)
! R903 1-219-119-81 FUSIBLE 0.1 5% 1/4W F
(EXCEPT AEP,UK,EE,CIS)
! R903 1-219-120-11 FUSIBLE 0.15 5% 1/4W F
(AEP,UK,EE,CIS)
! R904 1-219-119-81 FUSIBLE 0.1 5% 1/4W F
(EXCEPT AEP,UK,EE,CIS)
! R904 1-219-120-11 FUSIBLE 0.15 5% 1/4W F
(AEP,UK,EE,CIS)
R907 1-202-725-00 SOLID 3.3M 10% 1/2W
(US,CND)
< SWITCH >
! S901 1-762-753-11 SWITCH, VOLTAGE SELECTION
(VOLTAGE SELECTOR) (E,AR)
< TRANSFORMER >
! T901 1-431-050-11 TRANSFORMER, POWER (US)
! T901 1-431-051-11 TRANSFORMER, POWER (AEP,UK,EE,CIS)
! T901 1-431-052-11 TRANSFORMER, POWER (E,AR,MX,AUS)
! T901 1-431-294-11 TRANSFORMER, POWER (CND)
************************************************************
MISCELLANEOUS
*************
11 1-769-974-11 WIRE (FLAT TYPE) (13 CORE)
11 1-773-006-11 WIRE (FLAT TYPE) (15 CORE)
58 1-773-161-11 WIRE (FLAT TYPE) (21 CORE)
59 1-769-949-11 WIRE (FLAT TYPE) (11 CORE)
120 1-773-051-11 WIRE (FLAT TYPE) (17 CORE)
156 1-777-868-11 WIRE (FLAT TYPE) (19 CORE)
! 158 1-569-008-11 ADAPTOR, CONVERSION 2P
357 1-452-538-11 MAGNET
! 401 8-820-020-01 OPTICAL PICK-UP KSS-213D/Q-NP
402 1-769-069-11 WIRE (FLAT TYPE) (16 CORE)
! CNP901 1-558-943-41 CORD, POWER (E,MX)
! CNP901 1-575-042-21 CORD, POWER (US,CND)
! CNP901 1-575-651-21 CORD, POWER (AEP,EE,CIS,AR)
! CNP901 1-696-845-11 CORD, POWER (AUS)
! CNP901 1-751-529-11 CORD, POWER (UK)
HP101 1-500-093-11 HEAD, MAGNETIC (PLAYBACK)
HRPE1011-500-094-11 HEAD, MAGNETIC (REC/PB/ERASE)
M1 X-3371-223-1 MOTOR ASSY,CAPSTAN
M2 A-2004-410-A MOTOR ASSY, DC (TRIGGER)
M201 A-4660-977-A MOTOR ASSY (TABLE)
M101 X-4917-504-1 MOTOR ASSY (SPINDLE)
M102 X-4917-523-4 MOTOR ASSY (SLED)
! T901 1-431-050-11 TRANSFORMER, POWER (US)
TRANS
The components identified by
mark ! or dotted line with
mark ! are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le neméro spécifié.
