13
HCD-DP1000D
2-12. RF-240 BOARD, OPTICAL PICK-UP (KHM-240AAA)
3
two
screws (+BVTP 2.6
×
8)
qd
screw (+PTPWH 2.6
×
8)
qf
tray
1
screw (+BVTP 2.6
×
8)
qa
screw (+BVTP 2.6
×
8)
qs
BRCKET (SENSOR)
qg
screw (+BVTP 2.6
×
8)
9
screw (+BVTP 2.6
×
8)
0
DIODE board
6
flat type wire (CN721)
5
MOTOR board
qh
SENSOR board
7
connector(CN722)
8
connector(CN723)
2
DRIVER board
4
remove the two solderings of motor.
2-13. DRIVER BOARD, MOTOR BOARD, DIODE BOARD, TRAY, SENSOR BOARD
9
step screw (10)
1
two screws (+PTP 2.6X12)
3
floating screw (+PTPWHM2.6)
2
RF-240 board
qs
insulator
4
holder (DVD) assy
qa
insulator
0
insulator
8
step screw (10)
7
step screw (L)
qd
optical pick-up (KHM-240AAA)
6
flat type wire (9 core)
5
flat type wire (26 core
