82
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-DP1000D
MAIN
R482 1-216-809-11 METAL CHIP 100 5% 1/16W
R483 1-216-809-11 METAL CHIP 100 5% 1/16W
R484 1-216-809-11 METAL CHIP 100 5% 1/16W
R485 1-216-809-11 METAL CHIP 100 5% 1/16W
R486 1-216-809-11 METAL CHIP 100 5% 1/16W
R487 1-216-833-11 METAL CHIP 10K 5% 1/16W
R488 1-216-833-11 METAL CHIP 10K 5% 1/16W
R489 1-216-833-11 METAL CHIP 10K 5% 1/16W
R490 1-216-833-11 METAL CHIP 10K 5% 1/16W
R491 1-216-833-11 METAL CHIP 10K 5% 1/16W
R492 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R493 1-216-864-11 METAL CHIP 0 5% 1/16W
(AEP,UK)
R493 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
(EA)
R493 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
(US,CND)
R493 1-216-821-11 METAL CHIP 1K 5% 1/16W
(E,MX)
R495 1-216-809-11 METAL CHIP 100 5% 1/16W
R496 1-216-833-11 METAL CHIP 10K 5% 1/16W
R497 1-216-833-11 METAL CHIP 10K 5% 1/16W
R498 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R499 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
(US,CND,E,MX)
R499 1-216-821-11 METAL CHIP 1K 5% 1/16W
(EA)
R499 1-216-864-11 METAL CHIP 0 5% 1/16W
(AUS,E91,SP,MY,TH)
R501 1-216-821-11 METAL CHIP 1K 5% 1/16W
R502 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R503 1-216-841-11 METAL CHIP 47K 5% 1/16W
R504 1-216-841-11 METAL CHIP 47K 5% 1/16W
R505 1-216-833-11 METAL CHIP 10K 5% 1/16W
R506 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R507 1-216-845-11 METAL CHIP 100K 5% 1/16W
R508 1-216-837-11 METAL CHIP 22K 5% 1/16W
R509 1-216-821-11 METAL CHIP 1K 5% 1/16W
R510 1-216-841-11 METAL CHIP 47K 5% 1/16W
R511 1-216-833-11 METAL CHIP 10K 5% 1/16W
R512 1-216-821-11 METAL CHIP 1K 5% 1/16W
R514 1-216-821-11 METAL CHIP 1K 5% 1/16W
R546 1-216-833-11 METAL CHIP 10K 5% 1/16W
R547 1-216-833-11 METAL CHIP 10K 5% 1/16W
R961 1-216-837-11 METAL CHIP 22K 5% 1/16W
R962 1-216-837-11 METAL CHIP 22K 5% 1/16W
R963 1-216-831-11 METAL CHIP 6.8K 5% 1/16W
< COMPOSITION CIRCUIT BLOCK >
RB41 1-234-575-11 ENCAPSULATED COMPONENT
< VARIABLE RESISTOR >
RV11 1-241-765-11 RES, ADJ, CARBON 22K (FM TUNED LEVEL)
RV301 1-241-764-11 RES, ADJ, CARBON 10K
(REC LEVEL (L) DECK (B))
RV302 1-241-762-11 RES, ADJ, CARBON 2.2K
(PB LEVEL (L) DECK (A))
RV303 1-241-762-11 RES, ADJ, CARBON 2.2K
(PB LEVEL (L) DECK (B))
RV304 1-241-768-11 RES, ADJ, CARBON 220K (REC BIAS (L))
RV351 1-241-764-11 RES, ADJ, CARBON 10K
(REC LEVEL (R) DECK (B))
RV354 1-241-768-11 RES, ADJ, CARBON 220K (REC BIAS (R))
< TRANSFORMER >
T11 1-435-792-11 TRANSFORMER, DISCRIMINATOR
T301 1-423-980-11 TRANSFORMER, BIAS OSCILLATION
< TERMINAL >
TM1 1-694-556-22 TERMINAL BOARD (ANT.PAL) (AEP,UK)
TM1 1-694-555-22 TERMINAL BOARD (4P) (EXCEPT AEP,UK)
< VIBRATOR >
X51 1-760-549-31 VIBRATOR, CRYSTAL (4.5MHz)
X81 1-579-900-21 VIBRATOR, CRYSTAL (4.332MHz) (AEP,UK)
X401 1-567-098-41 VIBRATOR, CRYSTAL (32.768kHz)
X402 1-781-107-21 VIBRATOR, SERAMIC (16MHz)
**************************************************************
A-4727-088-A MB BOARD, COMPLETE (TH)
A-4727-126-A MB BOARD, COMPLETE (US,CND)
A-4727-147-A MB BOARD, COMPLETE (AEP,UK)
A-4727-152-A MB BOARD, COMPLETE (EA)
A-4727-167-A MB BOARD, COMPLETE (SP,MY)
A-4727-172-A MB BOARD, COMPLETE (AUS)
A-4727-203-A MB BOARD, COMPLETE (E,MX)
A-4727-272-A MB BOARD, COMPLETE (E91)
**************************
< CAPACITOR >
C004 1-126-204-11 ELECT CHIP 47uF 20% 16V
C005 1-126-246-11 ELECT CHIP 220uF 20% 4V
C006 1-126-204-11 ELECT CHIP 47uF 20% 16V
C007 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C018 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C019 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C103 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C104 1-126-209-11 ELECT CHIP 100uF 20% 4V
C105 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C106 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C107 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C108 1-162-917-11 CERAMIC CHIP 15PF 5% 50V
C109 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C110 1-126-209-11 ELECT CHIP 100uF 20% 4V
C111 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C112 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C113 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C114 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C116 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C119 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C124 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C202 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C203 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C204 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C205 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C206 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C207 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C301 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C304 1-126-246-11 ELECT CHIP 220uF 20% 4V
C305 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C306 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C307 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C309 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C310 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C311 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
