86
Ref. No. Part No. Description Remarks
Ref. No. Part No. Description Remarks
HCD-DP1000D
R524 1-216-833-11 METAL CHIP 10K 5% 1/16W
R525 1-216-833-11 METAL CHIP 10K 5% 1/16W
R532 1-216-833-11 METAL CHIP 10K 5% 1/16W
R533 1-216-797-11 METAL CHIP 10 5% 1/16W
R554 1-216-797-11 METAL CHIP 10 5% 1/16W
R701 1-216-833-11 METAL CHIP 10K 5% 1/16W
R711 1-218-289-11 RES-CHIP 510 5% 1/16W
R712 1-218-289-11 RES-CHIP 510 5% 1/16W
R713 1-218-289-11 RES-CHIP 510 5% 1/16W
R717 1-218-285-11 RES-CHIP 75 5% 1/16W
R718 1-218-285-11 RES-CHIP 75 5% 1/16W
R719 1-218-285-11 RES-CHIP 75 5% 1/16W
R724 1-216-833-11 METAL CHIP 10K 5% 1/16W
R725 1-216-833-11 METAL CHIP 10K 5% 1/16W
R737 1-216-864-11 METAL CHIP 0 5% 1/16W
R738 1-216-864-11 METAL CHIP 0 5% 1/16W
< VARIABLE RESISTOR >
RV501 1-223-583-11 RES, ADJ, CARBON 1K
< VIBRATOR >
X101 1-795-174-11 VIBRATOR, CERAMIC (16.5MHz)
X102 1-767-519-11 VIBRATOR, CRYSTAL (27MHz)
******************************************************
1-682-791-11 MOTOR BOARD
***********
< CAPACITOR >
C721 1-162-306-11 CERAMIC 0.01uF 30% 16V
< CONNECTOR >
CN721 1-770-516-31 CONNECTOR, FFC 8P
CN722 1-785-330-11 PIN, CONNECTOR (LIGHT ANGLE)4P
CN723 1-785-328-11 PIN, CONNECTOR (LIGHT ANGRE)2P
< RESISTOR >
R721 1-249-415-11 CARBON 680 5% 1/4W F
< SWITCH >
S701 1-771-822-11 SWITCH, LEVER (SLIDE) (OPEN/CLOSE)
******************************************************
1-680-279-11 OPT IN BOARD
***********
< CAPACITOR >
C1195 1-126-791-11 ELECT 10uF 20% 16V
C1196 1-164-159-11 CERAMIC 0.1uF 50V
< FERRITE BEAD >
FB1195 1-412-473-21 INDUCTOR 0UH
< IC >
IC1195 8-749-018-63 IC GP1FA501RZ (DIGITAL IN (OPTICAL))
******************************************************
A-4727-117-A PANEL BOARD, COMPLETE (including CD
PANEL BOARD) (US)
A-4727-133-A PANEL BOARD, COMPLETE (including CD
PANEL BOALD) (CND)
A-4727-141-A PANEL BOARD, COMPLETE (incuding CD
PANEL BOARD) (AEP,UK)
A-4727-155-A PANEL BOARD, COMPLETE (including CD
PANEL BOARD) (AUS,E,E91,EA,MX,SP,MY)
A-4727-219-A PANEL BOARD, COMPLETE (including CD
PANEL BOARD)(TH)
**********************************
4-224-584-01 HOLDER (FL)
< CAPACITOR >
C1102 1-162-282-31 CERAMIC 100PF 10% 50V
C1103 1-162-282-31 CERAMIC 100PF 10% 50V
C1104 1-162-306-11 CERAMIC 0.01uF 30% 16V
C1105 1-162-306-11 CERAMIC 0.01uF 30% 16V
C1106 1-162-306-11 CERAMIC 0.01uF 30% 16V
C1107 1-162-306-11 CERAMIC 0.01uF 30% 16V
C1108 1-124-589-11 ELECT 47uF 20% 16V
C1109 1-162-294-31 CERAMIC 0.001uF 10% 50V
C1110 1-162-306-11 CERAMIC 0.01uF 30% 16V
C1111 1-164-159-11 CERAMIC 0.1uF 50V
C1112 1-164-159-11 CERAMIC 0.1uF 50V
C1113 1-164-159-11 CERAMIC 0.1uF 50V
C1114 1-164-159-11 CERAMIC 0.1uF 50V
C1120 1-162-282-31 CERAMIC 100PF 10% 50V
C1121 1-162-282-31 CERAMIC 100PF 10% 50V
C1122 1-162-282-31 CERAMIC 100PF 10% 50V
C1123 1-162-282-31 CERAMIC 100PF 10% 50V
C1124 1-162-282-31 CERAMIC 100PF 10% 50V
C1125 1-162-282-31 CERAMIC 100PF 10% 50V
C1126 1-162-282-31 CERAMIC 100PF 10% 50V
C1127 1-162-282-31 CERAMIC 100PF 10% 50V
C1128 1-162-282-31 CERAMIC 100PF 10% 50V
C1129 1-162-282-31 CERAMIC 100PF 10% 50V
C1130 1-162-282-31 CERAMIC 100PF 10% 50V
C1131 1-162-282-31 CERAMIC 100PF 10% 50V
C1132 1-162-282-31 CERAMIC 100PF 10% 50V
C1133 1-126-796-11 ELECT 22uF 20% 50V
C1134 1-126-796-11 ELECT 22uF 20% 50V
C1135 1-126-513-11 ELECT 47uF 20% 6.3V
C1137 1-162-294-31 CERAMIC 0.001uF 10% 50V
C1138 1-162-306-11 CERAMIC 0.01uF 30% 16V
C1139 1-126-163-11 ELECT 4.7uF 20% 50V
C1140 1-164-159-11 CERAMIC 0.1uF 50V
C1141 1-162-282-31 CERAMIC 100PF 10% 50V
C1142 1-162-282-31 CERAMIC 100PF 10% 50V
C1143 1-162-282-31 CERAMIC 100PF 10% 50V
C1203 1-162-306-11 CERAMIC 0.01uF 30% 16V
(AUS,E,E91,EA,MX,SP,MY,TH)
C1204 1-115-868-11 ELECT 0.22uF 20% 50V
(AUS,E,E91,EA,MX,SP,MY,TH)
C1205 1-162-294-31 CERAMIC 0.001uF 10% 50V
(AUS,E,E91,EA,MX,SP,MY,TH)
C1206 1-162-215-31 CERAMIC 47PF 5% 50V
(AUS,E,E91,EA,MX,SP,MY,TH)
C1207 1-162-290-31 CERAMIC 470PF 10% 50V
(AUS,E,E91,EA,MX,SP,MY,TH)
C1208 1-115-867-11 ELECT 0.1uF 20% 50V
(AUS,E,E91,EA,MX,SP,MY,TH)
C1209 1-115-872-11 ELECT 2.2uF 20% 50V
(AUS,E,E91,EA,MX,SP,MY,TH)
C1210 1-162-284-31 CERAMIC 150PF 10% 50V
(AUS,E,E91,EA,MX,SP,MY,TH)
C1211 1-115-872-11 ELECT 2.2uF 20% 50V
(AUS,E,E91,EA,MX,SP,MY,TH)
C1212 1-124-584-00 ELECT 100uF 20% 10V
(AUS,E,E91,EA,MX,SP,MY,TH)
MB
MOTOR
OPT IN PANEL
Ver 1.1 2002.03
