Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
R804 1-216-089-91 RES,CHIP 47K 5% 1/10W
R805 1-216-089-91 RES,CHIP 47K 5% 1/10W
R806 1-216-073-00 METAL CHIP 10K 5% 1/10W
R807 1-216-073-00 METAL CHIP 10K 5% 1/10W
R808 1-216-049-91 RES,CHIP 1K 5% 1/10W
R809 1-216-097-91 RES,CHIP 100K 5% 1/10W
R810 1-216-033-00 METAL CHIP 220 5% 1/10W
R811 1-216-097-91 RES,CHIP 100K 5% 1/10W
R901 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R902 1-216-081-00 METAL CHIP 22K 5% 1/10W
R903 1-216-049-91 RES,CHIP 1K 5% 1/10W
R961 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
(DR7AV)
R962 1-216-079-00 RES,CHIP 18K 5% 1/10W
(DR7AV)
R963 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
(DR7AV)
< VARIABLE RESISTOR >
RV301 1-238-600-11 RES, ADJ, CARBON 10K
RV351 1-238-600-11 RES, ADJ, CARBON 10K
< VIBRATOR >
X501 1-567-098-41 VIBRATOR, CRYSTAL (32.768kHz)
X502 1-781-107-21 VIBRATOR, SERAMIC (16MHz)
**************************************************************
* A-4417-477-A PA BOARD, COMPLETE (XB800AV)
******************
* A-4417-479-A PA BOARD, COMPLETE (DR7AV)
******************
< CAPACITOR >
C401 1-126-963-11 ELECT 4.7uF 20% 50V
C402 1-164-159-11 CERAMIC 0.1uF 50V
(XB800AV)
C403 1-164-159-11 CERAMIC 0.1uF 50V
(XB800AV)
C404 1-164-159-11 CERAMIC 0.1uF 50V
(XB800AV)
C405 1-164-159-11 CERAMIC 0.1uF 50V
(XB800AV)
C406 1-164-159-11 CERAMIC 0.1uF 50V
(XB800AV)
C407 1-164-159-11 CERAMIC 0.1uF 50V
(XB800AV)
C410 1-164-159-11 CERAMIC 0.1uF 50V
(XB800AV)
C411 1-164-159-11 CERAMIC 0.1uF 50V
(XB800AV)
C412 1-161-494-00 CERAMIC 0.022uF 25V
C413 1-161-494-00 CERAMIC 0.022uF 25V
C414 1-161-494-00 CERAMIC 0.022uF 25V
C415 1-161-494-00 CERAMIC 0.022uF 25V
C416 1-161-494-00 CERAMIC 0.022uF 25V
C432 1-104-665-11 ELECT 100uF 20% 10V
C433 1-126-961-11 ELECT 2.2uF 20% 50V
(XB800AV)
PAMAIN
C433 1-126-962-11 ELECT 3.3uF 20% 50V
(DR7AV)
C801 1-128-582-11 ELECT 10uF 20% 100V
C802 1-162-292-31 CERAMIC 680PF 10% 50V
C803 1-162-286-31 CERAMIC 220PF 10% 50V
C804 1-126-967-11 ELECT 47uF 20% 50V
C807 1-128-560-11 ELECT 22uF 20% 100V
C808 1-130-777-00 FILM 0.1uF 10% 100V
C809 1-130-777-00 FILM 0.1uF 10% 100V
C810 1-128-562-11 ELECT 47uF 20% 100V
(DR7AV)
C810 1-128-578-11 ELECT 1uF 20% 100V
(XB800AV)
C811 1-130-493-00 MYLAR 0.068uF 5% 50V
C812 1-130-493-00 MYLAR 0.068uF 5% 50V
C813 1-161-494-00 CERAMIC 0.022uF 25V
C814 1-162-294-31 CERAMIC 0.001uF 10% 50V
C815 1-128-562-11 ELECT 47uF 20% 100V
C830 1-107-714-11 ELECT 10uF 20% 50V
C831 1-126-964-11 ELECT 10uF 20% 50V
C832 1-126-967-11 ELECT 47uF 20% 50V
C841 1-127-751-11 ELECT 3300uF 20% 50V
(XB800AV)
C842 1-127-752-11 ELECT 3300uF 20% 63V
(XB800AV)
C844 1-130-777-00 FILM 0.1uF 10% 100V
C845 1-126-943-11 ELECT 2200uF 20% 25V
C847 1-164-159-11 CERAMIC 0.1uF 50V
C848 1-164-159-11 CERAMIC 0.1uF 50V
C849 1-164-159-11 CERAMIC 0.1uF 50V
C850 1-107-721-11 ELECT 10uF 20% 100V
C851 1-128-582-11 ELECT 10uF 20% 100V
C852 1-162-292-31 CERAMIC 680PF 10% 50V
C853 1-162-286-31 CERAMIC 220PF 10% 50V
C854 1-126-967-11 ELECT 47uF 20% 50V
C857 1-128-560-11 ELECT 22uF 20% 100V
C858 1-164-159-11 CERAMIC 0.1uF 50V
C859 1-164-159-11 CERAMIC 0.1uF 50V
C861 1-130-493-00 MYLAR 0.068uF 5% 50V
C862 1-130-493-00 MYLAR 0.068uF 5% 50V
C863 1-126-961-11 ELECT 2.2uF 20% 50V
(XB800AV)
C891 1-127-751-11 ELECT 3300uF 20% 50V
(XB800AV)
C892 1-127-752-11 ELECT 3300uF 20% 63V
(XB800AV)
C895 1-107-721-11 ELECT 10uF 20% 100V
C902 1-164-159-11 CERAMIC 0.1uF 50V
(XB800AV)
C903 1-126-933-11 ELECT 100uF 20% 16V
(XB800AV)
C904 1-126-964-11 ELECT 10uF 20% 50V
C905 1-126-948-11 ELECT 100uF 20% 35V
C906 1-126-768-11 ELECT 2200uF 20% 16V
(XB800AV)
C908 1-164-159-11 CERAMIC 0.1uF 50V
(XB800AV)
C909 1-164-159-11 CERAMIC 0.1uF 50V
(XB800AV)
