– 126 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
PA
C962 1-128-563-11 ELECT 100uF 20% 100V
(XB800AV)
< CONNECTOR >
CN803 1-778-981-11 CONNECTOR, BOARD TO BOARD 13P
CN804 1-766-921-11 CONNECTOR, BOARD TO BOARD 10P (DR7AV)
* CN804 1-770-747-11 CONNECTOR, BOARD TO BOARD 12P (XB800AV)
< DIODE >
D401 8-719-991-33 DIODE 1SS133T-77
D402 8-719-991-33 DIODE 1SS133T-77
D403 8-719-991-33 DIODE 1SS133T-77
D405 8-719-991-33 DIODE 1SS133T-77
D406 8-719-991-33 DIODE 1SS133T-77
D407 8-719-991-33 DIODE 1SS133T-77
D408 8-719-991-33 DIODE 1SS133T-77
D410 8-719-991-33 DIODE 1SS133T-77
D801 8-719-991-33 DIODE 1SS133T-77
D802 8-719-110-06 DIODE RD8.2ESB1
D803 8-719-991-33 DIODE 1SS133T-77
D804 8-719-991-33 DIODE 1SS133T-77
D805 8-719-991-33 DIODE 1SS133T-77
D831 8-719-510-68 DIODE D5SBA20F01
D833 8-719-200-82 DIODE 11ES2
D834 8-719-200-82 DIODE 11ES2
D835 8-719-200-82 DIODE 11ES2
D836 8-719-200-82 DIODE 11ES2
D841 8-719-200-82 DIODE 11ES2 (XB800AV)
D842 8-719-200-82 DIODE 11ES2 (XB800AV)
D843 8-719-200-82 DIODE 11ES2 (XB800AV)
D844 8-719-200-82 DIODE 11ES2 (XB800AV)
D851 8-719-991-33 DIODE 1SS133T-77
D852 8-719-110-06 DIODE RD8.2ESB1
D853 8-719-991-33 DIODE 1SS133T-77 (XB800AV)
D902 8-719-210-21 DIODE 11EQS04 (XB800AV)
D903 8-719-210-21 DIODE 11EQS04 (XB800AV)
D904 8-719-210-21 DIODE 11EQS04 (XB800AV)
D905 8-719-210-21 DIODE 11EQS04 (XB800AV)
D906 8-719-991-33 DIODE 1SS133T-77 (XB800AV)
D907 8-719-200-82 DIODE 11ES2 (XB800AV)
D908 8-719-200-82 DIODE 11ES2 (XB800AV)
D909 8-719-200-82 DIODE 11ES2 (XB800AV)
D910 8-719-200-82 DIODE 11ES2 (XB800AV)
D911 8-719-934-25 DIODE HZS33-1L
D912 8-719-109-89 DIODE RD5.6ESB2
D913 8-719-991-33 DIODE 1SS133T-77 (XB800AV)
< IC >
IC801 8-749-016-11 IC STK411-230M (DR7AV)
IC801 8-749-016-10 IC STK411-220M (XB800AV)
IC901 8-759-450-47 IC BA05T (XB800AV)
< COIL >
L401 1-420-872-00 COIL, AIR-CORE (XB800AV)
L402 1-420-872-00 COIL, AIR-CORE (XB800AV)
L403 1-420-872-00 COIL, AIR-CORE (XB800AV)
L404 1-420-872-00 COIL, AIR-CORE (XB800AV)
L405 1-420-872-00 COIL, AIR-CORE (XB800AV)
< TRANSISTOR >
Q401 8-729-029-21 TRANSISTOR DTA114ESA
Q402 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q403 8-729-029-21 TRANSISTOR DTA114ESA
Q407 8-729-029-66 TRANSISTOR DTC114ESA
Q431 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q432 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q433 8-729-620-05 TRANSISTOR 2SC2603-EF
Q434 8-729-620-05 TRANSISTOR 2SC2603-EF
Q437 8-729-620-05 TRANSISTOR 2SC2603-EF
Q439 8-729-620-05 TRANSISTOR 2SC2603-EF
Q801 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q803 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q804 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q805 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q831 8-729-029-86 TRANSISTOR DTC124ESA
Q832 8-729-620-05 TRANSISTOR 2SC2603-EF
Q833 8-729-029-40 TRANSISTOR DTA124ESA
Q834 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q851 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q855 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q901 8-729-620-05 TRANSISTOR 2SC2603-EF (XB800AV)
Q902 8-729-040-19 TRANSISTOR RT1N137L-TP (XB800AV)
Q903 8-729-048-52 TRANSISTOR 2SA1932 (DR7AV)
Q903 8-729-118-01 TRANSISTOR 2SB1116-K (XB800AV)
Q904 8-729-620-05 TRANSISTOR 2SC2603-EF (DR7AV)
Q905 8-729-048-13 TRANSISTOR 2SC3616-KLM-T1 (XB800AV)
Q906 8-729-029-21 TRANSISTOR DTA114ESA-TP (XB800AV)
Q907 8-729-029-21 TRANSISTOR DTA114ESA-TP (XB800AV)
< RESISTOR >
! R401 1-216-453-11 METAL 270 1% 2W
(DR7AV)
! R401 1-215-888-11 METAL OXIDE 220 5% 2W F
(XB800AV)
! R402 1-216-453-11 METAL 270 1% 2W
(DR7AV)
! R402 1-215-888-11 METAL OXIDE 220 5% 2W F
(XB800AV)
R406 1-249-437-11 CARBON 47K 5% 1/4W
R407 1-249-437-11 CARBON 47K 5% 1/4W
R408 1-249-440-11 CARBON 82K 5% 1/4W
R409 1-249-437-11 CARBON 47K 5% 1/4W
R410 1-249-389-11 CARBON 4.7 5% 1/4W F
(XB800AV)
R411 1-249-389-11 CARBON 4.7 5% 1/4W F
(XB800AV)
R412 1-249-389-11 CARBON 4.7 5% 1/4W F
(XB800AV)
R413 1-249-389-11 CARBON 4.7 5% 1/4W F
(XB800AV)
R414 1-260-076-11 CARBON 10 5% 1/2W
(XB800AV)
R415 1-260-076-11 CARBON 10 5% 1/2W
(XB800AV)
R416 1-249-389-11 CARBON 4.7 5% 1/4W F
(XB800AV)
The components identified by mark ! or dotted
line with mark ! are critical for safety.
Replace only with part number specified.
