– 127 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
PA
R417 1-249-389-11 CARBON 4.7 5% 1/4W F
(XB800AV)
R420 1-249-389-11 CARBON 4.7 5% 1/4W F
(XB800AV)
R421 1-249-389-11 CARBON 4.7 5% 1/4W F
(XB800AV)
R422 1-260-076-11 CARBON 10 5% 1/2W
(XB800AV)
R424 1-260-076-11 CARBON 10 5% 1/2W
(XB800AV)
R425 1-249-437-11 CARBON 47K 5% 1/4W
R429 1-249-437-11 CARBON 47K 5% 1/4W
R431 1-249-438-11 CARBON 56K 5% 1/4W
R432 1-249-437-11 CARBON 47K 5% 1/4W
R434 1-247-863-91 CARBON 22K 5% 1/4W
R435 1-249-425-11 CARBON 4.7K 5% 1/4W F
R437 1-249-429-11 CARBON 10K 5% 1/4W
R439 1-249-425-11 CARBON 4.7K 5% 1/4W F
R440 1-247-863-91 CARBON 22K 5% 1/4W
(DR7AV)
R440 1-249-437-11 CARBON 47K 5% 1/4W
(XB800AV)
R441 1-249-435-11 CARBON 33K 5% 1/4W
R442 1-249-435-11 CARBON 33K 5% 1/4W
R443 1-249-434-11 CARBON 27K 5% 1/4W
R446 1-249-429-11 CARBON 10K 5% 1/4W
R447 1-249-437-11 CARBON 47K 5% 1/4W
R801 1-249-417-11 CARBON 1K 5% 1/4W F
R802 1-249-437-11 CARBON 47K 5% 1/4W
R803 1-247-827-11 CARBON 680 5% 1/4W F
R804 1-247-759-11 CARBON 3.9K 5% 1/2W
! R805 1-216-436-00 METAL OXIDE 3.9K 5% 1W
! R806 1-216-436-00 METAL OXIDE 3.9K 5% 1W
! R807 1-212-881-11 FUSIBLE 100 5% 1/4W F
R809 1-260-076-11 CARBON 10 5% 1/2W
R810 1-249-437-11 CARBON 47K 5% 1/4W
R811 1-249-417-11 CARBON 1K 5% 1/4W F
R812 1-249-431-11 CARBON 15K 5% 1/4W
R813 1-249-441-11 CARBON 100K 5% 1/4W
R814 1-249-421-11 CARBON 2.2K 5% 1/4W F
R815 1-247-863-91 CARBON 22K 5% 1/4W
R816 1-249-429-11 CARBON 10K 5% 1/4W
R817 1-249-421-11 CARBON 2.2K 5% 1/4W F
R818 1-249-417-11 CARBON 1K 5% 1/4W F
R819 1-249-439-11 CARBON 68K 5% 1/4W
! R820 1-202-972-61 FUSIBLE 1 5% 1/4W F
R821 1-249-435-11 CARBON 33K 5% 1/4W
R822 1-247-863-91 CARBON 22K 5% 1/4W
R823 1-247-863-91 CARBON 22K 5% 1/4W
R824 1-249-416-11 CARBON 820 5% 1/4W F
(XB800AV)
R824 1-249-418-11 CARBON 1.2K 5% 1/4W F
(DR7AV)
! R825 1-215-891-11 METAL OXIDE 680 5% 2W F
R827 1-249-441-11 CARBON 100K 5% 1/4W
R828 1-247-903-00 CARBON 1M 5% 1/4W
R831 1-249-441-11 CARBON 100K 5% 1/4W
R832 1-249-441-11 CARBON 100K 5% 1/4W
R833 1-249-441-11 CARBON 100K 5% 1/4W
R835 1-249-437-11 CARBON 47K 5% 1/4W
R836 1-249-417-11 CARBON 1K 5% 1/4W F
R837 1-249-435-11 CARBON 33K 5% 1/4W
R838 1-249-435-11 CARBON 33K 5% 1/4W
! R839 1-215-877-11 METAL OXIDE 22K 5% 1W F
R840 1-249-402-11 CARBON 56 5% 1/4W F
! R842 1-202-972-61 FUSIBLE 1 5% 1/4W F
R851 1-249-417-11 CARBON 1K 5% 1/4W F
R852 1-249-437-11 CARBON 47K 5% 1/4W
R853 1-247-827-11 CARBON 680 5% 1/4W F
! R855 1-215-891-11 METAL OXIDE 680 5% 2W F
! R857 1-212-881-11 FUSIBLE 100 5% 1/4W F
R859 1-260-076-11 CARBON 10 5% 1/2W
R860 1-249-437-11 CARBON 47K 5% 1/4W
R861 1-249-417-11 CARBON 1K 5% 1/4W F
R862 1-249-431-11 CARBON 15K 5% 1/4W
R863 1-249-441-11 CARBON 100K 5% 1/4W
R864 1-249-425-11 CARBON 4.7K 5% 1/4W F
(XB800AV)
R865 1-247-863-91 CARBON 22K 5% 1/4W
(XB800AV)
R868 1-249-417-11 CARBON 1K 5% 1/4W F
R880 1-249-402-11 CARBON 56 5% 1/4W F
! R889 1-215-877-11 METAL OXIDE 22K 5% 1W F
R901 1-249-429-11 CARBON 10K 5% 1/4W
(XB800AV)
! R902 1-215-916-00 METAL 680 5% 3W
(DR7AV)
R903 1-249-429-11 CARBON 10K 5% 1/4W
R904 1-249-417-11 CARBON 1K 5% 1/4W F
R905 1-249-429-11 CARBON 10K 5% 1/4W
R906 1-247-807-31 CARBON 100 5% 1/4W
R907 1-247-807-31 CARBON 100 5% 1/4W
R908 1-247-807-31 CARBON 100 5% 1/4W
(XB800AV)
R909 1-247-791-31 CARBON 22 5% 1/4W
(DR7AV)
R911 1-249-429-11 CARBON 10K 5% 1/4W
(XB800AV)
R912 1-249-429-11 CARBON 10K 5% 1/4W
(XB800AV)
< RELAY >
RY401 1-515-920-11 RELAY (24V)
RY402 1-515-920-11 RELAY (24V)
< TERMINAL >
TM401 1-537-842-11 TERMINAL BOARD (FRONT SPEAKER)
TM402 1-537-510-11 TERMINAL BOARD (SPEAKER)(6P)
(SURROUND SPEAKER)
**************************************************************
The components identified by mark ! or dotted
line with mark ! are critical for safety.
Replace only with part number specified.
