Sony HCD-DR7AV - Page 87

– 129 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
PANEL VR
R628 1-249-429-11 CARBON 10K 5% 1/4W
R629 1-247-807-31 CARBON 100 5% 1/4W
R630 1-249-429-11 CARBON 10K 5% 1/4W
R631 1-249-410-11 CARBON 270 5% 1/4W F
R632 1-249-411-11 CARBON 330 5% 1/4W
R633 1-249-413-11 CARBON 470 5% 1/4W F
R634 1-249-414-11 CARBON 560 5% 1/4W F
R635 1-249-415-11 CARBON 680 5% 1/4W F
R636 1-249-417-11 CARBON 1K 5% 1/4W F
R637 1-249-418-11 CARBON 1.2K 5% 1/4W F
R638 1-249-420-11 CARBON 1.8K 5% 1/4W F
R639 1-249-422-11 CARBON 2.7K 5% 1/4W F
R640 1-247-843-11 CARBON 3.3K 5% 1/4W
R641 1-249-425-11 CARBON 4.7K 5% 1/4W F
R642 1-249-427-11 CARBON 6.8K 5% 1/4W F
R643 1-249-429-11 CARBON 10K 5% 1/4W
R644 1-249-431-11 CARBON 15K 5% 1/4W
R645 1-249-434-11 CARBON 27K 5% 1/4W
R647 1-249-410-11 CARBON 270 5% 1/4W F
R648 1-249-411-11 CARBON 330 5% 1/4W
R649 1-249-413-11 CARBON 470 5% 1/4W F
R650 1-249-414-11 CARBON 560 5% 1/4W F
R651 1-249-415-11 CARBON 680 5% 1/4W F
R652 1-249-437-11 CARBON 47K 5% 1/4W
R653 1-249-417-11 CARBON 1K 5% 1/4W F
R654 1-249-437-11 CARBON 47K 5% 1/4W
R655 1-249-417-11 CARBON 1K 5% 1/4W F
R656 1-249-438-11 CARBON 56K 5% 1/4W
R659 1-249-411-11 CARBON 330 5% 1/4W
R660 1-249-411-11 CARBON 330 5% 1/4W
R661 1-249-412-11 CARBON 390 5% 1/4W F
R662 1-249-407-11 CARBON 150 5% 1/4W F
R663 1-247-804-11 CARBON 75 5% 1/4W
R664 1-249-407-11 CARBON 150 5% 1/4W F
R665 1-249-441-11 CARBON 100K 5% 1/4W
R666 1-249-441-11 CARBON 100K 5% 1/4W
R667 1-249-441-11 CARBON 100K 5% 1/4W
R668 1-249-429-11 CARBON 10K 5% 1/4W
R669 1-249-393-11 CARBON 10 5% 1/4W F
R670 1-249-393-11 CARBON 10 5% 1/4W F
R671 1-249-393-11 CARBON 10 5% 1/4W F
R672 1-249-393-11 CARBON 10 5% 1/4W F
R673 1-249-393-11 CARBON 10 5% 1/4W F
R674 1-249-393-11 CARBON 10 5% 1/4W F
R675 1-249-393-11 CARBON 10 5% 1/4W F
R676 1-249-393-11 CARBON 10 5% 1/4W F
R677 1-249-393-11 CARBON 10 5% 1/4W F
R678 1-249-393-11 CARBON 10 5% 1/4W F
R679 1-249-393-11 CARBON 10 5% 1/4W F
R680 1-249-420-11 CARBON 1.8K 5% 1/4W F
R681 1-249-440-11 CARBON 82K 5% 1/4W
R682 1-249-420-11 CARBON 1.8K 5% 1/4W F
R683 1-249-437-11 CARBON 47K 5% 1/4W
R684 1-249-440-11 CARBON 82K 5% 1/4W
R685 1-249-429-11 CARBON 10K 5% 1/4W
< SWITCH >
S601 1-554-303-21 SWITCH, TACTILE
(POWER SAVE/DEMO (STANDBY))
S602 1-554-303-21 SWITCH, TACTILE (ECO)
S603 1-554-303-21 SWITCH, TACTILE (DISPLAY)
S604 1-554-303-21 SWITCH, TACTILE (SPECTRUM ANALYZER)
S605 1-554-303-21 SWITCH, TACTILE (PTY)(XB800AV)
S606 1-554-303-21 SWITCH, TACTILE (TUNING/MODE)
S607 1-554-303-21 SWITCH, TACTILE (STEREO/MONO)
S608 1-554-303-21 SWITCH, TACTILE (ENTER/NEXT)
S609 1-554-303-21 SWITCH, TACTILE (TUNING/BAND)
S610 1-554-303-21 SWITCH, TACTILE (TUNING +)
S611 1-554-303-21 SWITCH, TACTILE (TUNING -)
S612 1-554-303-21 SWITCH, TACTILE (FUNCTION)
S613 1-554-303-21 SWITCH, TACTILE (TUNER MEMORY)
S614 1-554-303-21 SWITCH, TACTILE (SYNC EQ)
S615 1-554-303-21 SWITCH, TACTILE (SYNC BASS)
S617 1-554-303-21 SWITCH, TACTILE (DAILY)
S618 1-554-303-21 SWITCH, TACTILE (REC)
S619 1-554-303-21 SWITCH, TACTILE (SLEEP)
S620 1-554-303-21 SWITCH, TACTILE (t/CLOCK SET)
< VIBRATOR >
X601 1-781-312-11 VIBRATOR, CERAMIC (12.5MHz)
**************************************************************
* A-4417-502-A PANEL VR BOARD, COMPLETE
************************
< CAPACITOR >
C610 1-162-306-11 CERAMIC 0.01uF 20% 16V
C611 1-162-306-11 CERAMIC 0.01uF 20% 16V
C612 1-164-159-21 CERAMIC 0.1uF 50V
< CONNECTOR >
CN701 1-784-776-11 CONNECTOR, FFC 15P
< DIODE >
D611 8-719-058-04 DIODE SEL5223S-TP15 (GROOVE)
D612 8-719-058-04 DIODE SEL5223S-TP15 (SUPER WOOFER)
D613 8-719-057-97 DIODE SEL5923A-TP15 (PRO LOGIC)
D616 8-719-058-04 DIODE SEL5223S-TP15 (ENTER)
D617 8-719-058-04 DIODE SEL5223S-TP15 (DSP)
D618 8-719-058-04 DIODE SEL5223S-TP15 (EFFECT)
D619 8-719-075-54 DIODE SLR-325YCT31-NP (MENU2)
D620 8-719-075-54 DIODE SLR-325YCT31-NP (MENU1)
D621 8-719-075-54 DIODE SLR-325YCT31-NP (P.FILE)
D623 8-719-075-54 DIODE SLR-325YCT31-NP (FILE5)
D624 8-719-075-54 DIODE SLR-325YCT31-NP (FILE4)
D625 8-719-075-54 DIODE SLR-325YCT31-NP (FILE3)
D626 8-719-075-54 DIODE SLR-325YCT31-NP (FILE2)
D627 8-719-075-54 DIODE SLR-325YCT31-NP (FILE1)
< RESISTOR >
R761 1-249-410-11 CARBON 270 5% 1/4W F
R762 1-249-411-11 CARBON 330 5% 1/4W
PANEL FL
