– 130 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
< DIODE >
D901 8-719-991-33 DIODE 1SS133T-77
< RELAY >
! RY901 1-755-276-11 RELAY, POWER
< TRANSFORMER >
! T901 1-433-619-11 TRANSFORMER, POWER
**************************************************************
* A-4417-501-A SURROUND AMP BOARD, COMPLETE
****************************
< CAPACITOR >
C101 1-128-582-11 ELECT 10uF 20% 100V
C102 1-162-286-21 CERAMIC 220PF 10% 50V
C103 1-162-282-31 CERAMIC 100PF 10% 50V
C104 1-126-967-11 ELECT 47uF 20% 50V
C105 1-136-165-00 FILM 0.1uF 5% 50V
C106 1-136-165-00 FILM 0.1uF 5% 50V
C107 1-128-560-11 ELECT 22uF 20% 100V
C108 1-136-495-11 FILM 0.068uF 5% 50V
C109 1-136-495-11 FILM 0.068uF 5% 50V
C111 1-128-562-11 ELECT 47uF 20% 100V
C113 1-161-494-00 CERAMIC 0.022uF 25V
C114 1-162-294-31 CERAMIC 0.001uF 10% 50V
C151 1-128-582-11 ELECT 10uF 20% 100V
C152 1-162-286-21 CERAMIC 220PF 10% 50V
C153 1-162-282-31 CERAMIC 100PF 10% 50V
C154 1-126-967-11 ELECT 47uF 20% 50V
C157 1-128-560-11 ELECT 22uF 20% 100V
C158 1-136-495-11 FILM 0.068uF 5% 50V
C159 1-136-495-11 FILM 0.068uF 5% 50V
< CONNECTOR >
CN101 1-691-771-11 PLUG (MICRO CONNECTOR) 9P
CN102 1-691-766-11 PLUG (MICRO CONNECTOR) 4P
< DIODE >
D101 8-719-991-33 DIODE 1SS133T-77
D151 8-719-991-33 DIODE 1SS133T-77
< IC >
IC101 8-749-015-42 IC STK407-040E
< TRANSISTOR >
Q101 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q103 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q104 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q131 8-729-029-86 TRANSISTOR DTC124ESA
Q132 8-729-620-05 TRANSISTOR 2SC2603-EF
Q151 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
< RESISTOR >
R101 1-249-417-11 CARBON 1K 5% 1/4W F
R763 1-249-413-11 CARBON 470 5% 1/4W F
R764 1-249-414-11 CARBON 560 5% 1/4W F
R765 1-249-415-11 CARBON 680 5% 1/4W F
R766 1-249-417-11 CARBON 1K 5% 1/4W F
R767 1-249-418-11 CARBON 1.2K 5% 1/4W F
R768 1-249-420-11 CARBON 1.8K 5% 1/4W F
R769 1-249-422-11 CARBON 2.7K 5% 1/4W F
R770 1-247-843-11 CARBON 3.3K 5% 1/4W
R771 1-249-425-11 CARBON 4.7K 5% 1/4W F
R772 1-249-427-11 CARBON 6.8K 5% 1/4W F
R773 1-249-429-11 CARBON 10K 5% 1/4W
R774 1-249-431-11 CARBON 15K 5% 1/4W
R775 1-249-434-11 CARBON 27K 5% 1/4W
R776 1-249-438-11 CARBON 56K 5% 1/4W
R777 1-247-818-91 CARBON 300 5% 1/4W
R778 1-249-407-11 CARBON 150 5% 1/4W F
R779 1-249-403-11 CARBON 68 5% 1/4W F
R782 1-249-407-11 CARBON 150 5% 1/4W F
R783 1-249-407-11 CARBON 150 5% 1/4W F
R784 1-249-407-11 CARBON 150 5% 1/4W F
R785 1-249-407-11 CARBON 150 5% 1/4W F
R786 1-249-407-11 CARBON 150 5% 1/4W F
R787 1-249-407-11 CARBON 150 5% 1/4W F
R789 1-249-407-11 CARBON 150 5% 1/4W F
R790 1-249-407-11 CARBON 150 5% 1/4W F
R791 1-249-407-11 CARBON 150 5% 1/4W F
R792 1-249-407-11 CARBON 150 5% 1/4W F
R793 1-249-407-11 CARBON 150 5% 1/4W F
R794 1-249-417-11 CARBON 1K 5% 1/4W F
R795 1-249-417-11 CARBON 1K 5% 1/4W F
< SWITCH >
S625 1-771-215-11 SWITCH, TACTILE (GEQ ¿ ˘ ˘ ÷)
S626 1-554-303-21 SWITCH, TACTILE (GROOVE)
S627 1-554-303-21 SWITCH, TACTILE (SUPER WOOFER)
S628 1-554-303-21 SWITCH, TACTILE (MODE)
S629 1-554-303-21 SWITCH, TACTILE (PRO LOGIC)
S632 1-554-303-21 SWITCH, TACTILE (KARAOKE PON/MPX)
S633 1-554-303-21 SWITCH, TACTILE (ENTER)
S634 1-554-303-21 SWITCH, TACTILE (GEQ CONTROL)
S635 1-554-303-21 SWITCH, TACTILE (DSP)
S636 1-554-303-21 SWITCH, TACTILE (EFFECT)
S637 1-554-303-21 SWITCH, TACTILE (P.FILE MEMORY)
S701 1-473-392-11 ENCODER, ROTARY (VOLUME)
**************************************************************
* 1-672-432-11 SUB TRANS BOARD (XB800AV)
***************
< CAPACITOR >
!C901 1-113-925-11 CERAMIC 0.01uF 20% 250V
< CONNECTOR >
* CN901 1-580-230-11 PIN, CONNECTOR (PC BOARD) 2P
CN902 1-564-321-00 PIN, CONNECTOR 2P
SUB TRANS
SURROUND AMP
The components identified by mark ! or dotted
line with mark ! are critical for safety.
Replace only with part number specified.
PANEL VR
