– 131 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
R102 1-249-437-11 CARBON 47K 5% 1/4W
R103 1-249-413-11 CARBON 470 5% 1/4W F
! R107 1-212-881-11 FUSIBLE 100 5% 1/4W F
! R108 1-220-755-11 METAL 0.22 10% 2W
R109 1-260-076-11 CARBON 10 5% 1/2W
R110 1-249-437-11 CARBON 47K 5% 1/4W
R111 1-249-417-11 CARBON 1K 5% 1/4W F
R112 1-249-431-11 CARBON 15K 5% 1/4W
R113 1-249-441-11 CARBON 100K 5% 1/4W
R114 1-249-421-11 CARBON 2.2K 5% 1/4W F
R115 1-247-863-91 CARBON 22K 5% 1/4W
R116 1-249-429-11 CARBON 10K 5% 1/4W
R117 1-249-421-11 CARBON 2.2K 5% 1/4W F
R119 1-249-439-11 CARBON 68K 5% 1/4W
! R120 1-217-637-00 FUSIBLE 1 5% 1/4W F
R121 1-247-863-91 CARBON 22K 5% 1/4W
R130 1-249-435-11 CARBON 33K 5% 1/4W
R151 1-249-417-11 CARBON 1K 5% 1/4W F
R152 1-249-437-11 CARBON 47K 5% 1/4W
R153 1-249-413-11 CARBON 470 5% 1/4W F
! R157 1-212-881-11 FUSIBLE 100 5% 1/4W F
! R158 1-220-755-11 METAL 0.22 10% 2W
R159 1-260-076-11 CARBON 10 5% 1/2W
R160 1-249-437-11 CARBON 47K 5% 1/4W
R161 1-249-417-11 CARBON 1K 5% 1/4W F
R162 1-249-431-11 CARBON 15K 5% 1/4W
R163 1-249-441-11 CARBON 100K 5% 1/4W
**************************************************************
* 1-659-058-13 TABLE SENSOR BOARD
******************
< IC >
IC202 8-749-924-18 IC PHOTO INTERRUPTER RPI-1391
< RESISTOR >
R207 1-249-416-11 CARBON 820 5% 1/4W F
**************************************************************
* 1-672-193-11 TC-A BOARD
**********
< DIODE >
D631 8-719-058-03 DIODE SEL5423E-TP15 (·)(A DECK)
D632 8-719-058-03 DIODE SEL5423E-TP15 (ª)(A DECK)
< RESISTOR >
R701 1-249-417-11 CARBON 1K 5% 1/4W F
R702 1-249-418-11 CARBON 1.2K 5% 1/4W F
R703 1-249-420-11 CARBON 1.8K 5% 1/4W F
R704 1-249-422-11 CARBON 2.7K 5% 1/4W F
R705 1-247-843-11 CARBON 3.3K 5% 1/4W
R706 1-249-425-11 CARBON 4.7K 5% 1/4W F
R707 1-247-804-11 CARBON 75 5% 1/4W
R708 1-247-804-11 CARBON 75 5% 1/4W
< SWITCH >
S641 1-554-303-21 SWITCH, TACTILE (·)
S642 1-554-303-21 SWITCH, TACTILE (ª)
S643 1-554-303-21 SWITCH, TACTILE (π)
S644 1-554-303-21 SWITCH, TACTILE (º)
S645 1-554-303-21 SWITCH, TACTILE (‚)
S646 1-554-303-21 SWITCH, TACTILE (DOLBY ON)
S647 1-554-303-21 SWITCH, TACTILE (DIRECTION)
**************************************************************
* 1-672-194-11 TC-B BOARD
**********
< DIODE >
D635 8-719-058-03 DIODE SEL5423E-TP15 (ª)(B DECK)
D636 8-719-058-03 DIODE SEL5423E-TP15 (·)(B DECK)
D637 8-719-057-97 DIODE SEL5923A-TP15 (P)
D638 8-719-058-04 DIODE SEL5223S-TP15 (r REC)
< RESISTOR >
R711 1-249-410-11 CARBON 270 5% 1/4W F
R712 1-249-411-11 CARBON 330 5% 1/4W
R713 1-249-413-11 CARBON 470 5% 1/4W F
R714 1-249-414-11 CARBON 560 5% 1/4W F
R715 1-249-415-11 CARBON 680 5% 1/4W F
R716 1-249-417-11 CARBON 1K 5% 1/4W F
R717 1-249-418-11 CARBON 1.2K 5% 1/4W F
R718 1-249-420-11 CARBON 1.8K 5% 1/4W F
R719 1-249-422-11 CARBON 2.7K 5% 1/4W F
R720 1-247-804-11 CARBON 75 5% 1/4W
R721 1-247-804-11 CARBON 75 5% 1/4W
R722 1-247-807-31 CARBON 100 5% 1/4W
R723 1-249-407-11 CARBON 150 5% 1/4W F
< SWITCH >
S651 1-554-303-21 SWITCH, TACTILE (·)
S652 1-554-303-21 SWITCH, TACTILE (ª)
S653 1-554-303-21 SWITCH, TACTILE (π)
S654 1-554-303-21 SWITCH, TACTILE (º)
S655 1-554-303-21 SWITCH, TACTILE (‚)
S656 1-554-303-21 SWITCH, TACTILE (P)
S657 1-554-303-21 SWITCH, TACTILE (r REC)
S658 1-554-303-21 SWITCH, TACTILE (HI-SPEED DUB)
S659 1-554-303-21 SWITCH, TACTILE (CD SYNCHRO)
**************************************************************
* 1-672-431-11 TRANS BOARD (XB800AV)
************
1-673-110-11 TRANS BOARD (DR7AV)
************
< CAPACITOR >
C843 1-130-777-00 FILM 0.1uF 10% 100V
C893 1-130-777-00 FILM 0.1uF 10% 100V
C961 1-162-306-11 CERAMIC 0.01uF 20% 16V
C963 1-162-306-11 CERAMIC 0.01uF 20% 16V
The components identified by mark ! or dotted
line with mark ! are critical for safety.
Replace only with part number specified.
TC-A TC-B
TABLE SENSOR
TRANSSURROUND AMP
