HCD-DZ370/DZ560/DZ570/DZ660/DZ777
25
3-3. FRONT PANEL SECTION
3-4. BACK PANEL SECTION
two screws
(+BV3 (3-CR))
five screws
(+BV3 (3-CR))
RT front panel section
RB claw
RB claw
loading panel
CN412 (4P)
CN2101 (5P)
CN3001 (4P)
wire (flat type)(19 core)
(CN502)
label
tray
CN3000 (2P)
CN110 (4P)
wire (flat type) (11 core) (CN414)
(DZ560/DZ660)
wire (flat type) (9 core) (CN419)
(DZ370/DZ570/DZ777)
wire (flat type) (17 core)
(CN651)
three screws
(+BVTP 3 × 8)
RB back panel section
two screws
(+BVTP 3 × 8)
three screws
(+BVTP 3 × 8)
screw
(+BVTP 3 × 8)
screw
(+BVTP 3 × 8)
screw
(+B 3 × 6)
