Sony HCD-DZ370 - Waveform Examples; Signal Waveform Illustrations

HCD-DZ370/DZ560/DZ570/DZ660/DZ777
HCD-DZ370/DZ560/DZ570/DZ660/DZ777
3737
• Waveforms
– MAIN Board – – IO-SCART Board (DZ560/DZ660) – – IO-COMPONENT Board (DZ370/DZ570/DZ777) –
 IC400  (Cin)
1 V/DIV, 20 μs/DIV
 IC400  (Yin)
1 V/DIV, 20 μs/DIV
 IC400  (CVin)
1 V/DIV, 20 μs/DIV
 IC400 RT (Cbin)
500 mV/DIV, 20 μs/DIV
 IC400 RG (Crin)
500 mV/DIV, 20 μs/DIV
 IC400 XE (CVBSout)
500 mV/DIV, 20 μs/DIV
0.72Vp-p
0.72Vp-p
H
1Vp-p
H
1Vp-p
H
H
1Vp-p
H
H
1.3Vp-p
 IC1101  (DVDRFIP)
200 mV/DIV, 100 ns/DIV
 IC1101 [Y (R/Cr/Pr)
500 mV/DIV, 20 μs/DIV
 IC1101 [D (B/Cb/Pb)
500 mV/DIV, 20 μs/DIV
 IC1101 [C (Y/G)
1 V/DIV, 20 μs/DIV
 IC1101 [ (C)
1 V/DIV, 20 μs/DIV
 IC1101 [[ (Y)
1 V/DIV, 20 μs/DIV
 IC1101 YD (XTALO)
500 mV/DIV, 20 ns/DIV
 IC501 RE (Xout)
1 V/DIV, 100 ns/DIV
 IC702 XB (XOUT (O))
1 V/DIV, 20 ns/DIV
 IC3010 RG (XFSOOUT)
1 V/DIV, 10 ns/DIV
RB IC3010 SL (XFSOIN)
1 V/DIV, 10 ns/DIV
RT IC3051  (3Y)
1 V/DIV, 10 ns/DIV
0.72Vp-p
0.72Vp-p
H
1Vp-p
H
1Vp-p
H
H
1Vp-p
4.3Vp-p
49.1MHz
1.6Vp-p
27MHz
4.3Vp-p
49.1MHz
4.3Vp-p
49.1MHz
3.4Vp-p
4Vp-p
5MHz
12.288MHz
650mVp-p
H
 IC404  (Cin)
1 V/DIV, 20 μs/DIV
 IC404  (Yin)
1 V/DIV, 20 μs/DIV
 IC404  (CYin)
1 V/DIV, 20 μs/DIV
 IC404 RT (Cb in)
500 mV/DIV, 20 μs/DIV
 IC404 RG (Cr in)
500 mV/DIV, 20 μs/DIV
 IC404 X (CY OUT)
1 V/DIV, 20 μs/DIV
 IC404 RL (Cb OUT)
500 mV/DIV, 20 μs/DIV
 IC404 RI (Cr OUT)
500 mV/DIV, 20 μs/DIV
 IC404 XE (CVBS OUT)
500 mV/DIV, 20 μs/DIV
0.72Vp-p
0.72Vp-p
H
1Vp-p
H
1Vp-p
H
H
1Vp-p
H
0.72Vp-p
0.72Vp-p
H
1Vp-p
H
H
H
1.3Vp-p
