Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-DZ370/DZ560/DZ570/DZ660/DZ777
8787
D107 6-501-817-01 DIODE MA2J1110GLS0
D108 6-501-579-01 DIODE MC2837
D109 6-501-579-01 DIODE MC2837
< FERRITE BEAD >
FB102 1-500-236-22 BEAD, FERRITE (CHIP) (1608)
(EXCEPT E12,E32,MX,PX)
FB103 1-500-236-22 BEAD, FERRITE (CHIP) (1608)
(EXCEPT E12,E32,MX,PX)
FB104 1-500-236-22 BEAD, FERRITE (CHIP) (1608)
(EXCEPT E12,E32,MX,PX)
FB105 1-500-236-22 BEAD, FERRITE (CHIP) (1608)
(EXCEPT E12,E32,MX,PX)
FB106 1-500-236-22 BEAD, FERRITE (CHIP) (1608)
(EXCEPT E12,E32,MX,PX)
< IC >
IC102 6-705-312-01 IC S-T111B33MC-OGSTFG
IC103
8-759-100-96 IC uPC4558G2
IC104 8-759-100-96 IC uPC4558G2
< JACK >
J100
1-819-878-51 JACK (AUDIO IN/A.CAL MIC)
J101 1-819-878-51 JACK (PHONES)
< JUMPER RESISTOR >
JR101 1-216-864-11 SHORT CHIP 0
JR102 1-216-864-11 SHORT CHIP 0
JR103 1-216-864-11 SHORT CHIP 0
< TRANSISTOR >
Q101 8-729-038-28 TRANSISTOR RT1N441C-TP-1
Q102 8-729-038-28 TRANSISTOR RT1N441C-TP-1
Q103 8-729-038-11 TRANSISTOR RT1P140C-TP-1
Q104 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q105 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q106 6-550-889-01 TRANSISTOR 2SC5938-T112-1B
Q107 6-550-889-01 TRANSISTOR 2SC5938-T112-1B
Q108 6-550-889-01 TRANSISTOR 2SC5938-T112-1B
Q109 6-550-889-01 TRANSISTOR 2SC5938-T112-1B
< RESISTOR >
R109 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R110 1-216-833-11 METAL CHIP 10K 5% 1/10W
R111 1-216-809-11 METAL CHIP 100 5% 1/10W
R112 1-216-809-11 METAL CHIP 100 5% 1/10W
R113 1-216-815-11 METAL CHIP 330 5% 1/10W
R114 1-216-815-11 METAL CHIP 330 5% 1/10W
R115 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R117 1-216-834-11 METAL CHIP 12K 5% 1/10W
R118 1-216-835-11 METAL CHIP 15K 5% 1/10W
R121 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R122 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R123 1-216-821-11 METAL CHIP 1K 5% 1/10W
R126 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R128 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R129 1-216-801-11 METAL CHIP 22 5% 1/10W
R130 1-216-821-11 METAL CHIP 1K 5% 1/10W
R131 1-216-821-11 METAL CHIP 1K 5% 1/10W
R132 1-216-809-11 METAL CHIP 100 5% 1/10W
R133 1-216-819-11 METAL CHIP 680 5% 1/10W
R134 1-216-835-11 METAL CHIP 15K 5% 1/10W
R135 1-216-833-11 METAL CHIP 10K 5% 1/10W
R136 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R137 1-216-837-11 METAL CHIP 22K 5% 1/10W
R138 1-216-845-11 METAL CHIP 100K 5% 1/10W
R139 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R140 1-216-805-11 METAL CHIP 47 5% 1/10W
R141 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R143 1-216-817-11 METAL CHIP 470 5% 1/10W
R144 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R145 1-216-845-11 METAL CHIP 100K 5% 1/10W
R146 1-216-817-11 METAL CHIP 470 5% 1/10W
R147 1-216-845-11 METAL CHIP 100K 5% 1/10W
R148 1-216-837-11 METAL CHIP 22K 5% 1/10W
R149 1-216-821-11 METAL CHIP 1K 5% 1/10W
R150 1-216-821-11 METAL CHIP 1K 5% 1/10W
R151 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R152 1-216-864-11 SHORT CHIP 0
R153 1-216-857-11 METAL CHIP 1M 5% 1/10W
R154 1-216-837-11 METAL CHIP 22K 5% 1/10W
R155 1-216-864-11 SHORT CHIP 0
R160 1-216-864-11 SHORT CHIP 0
R162 1-216-864-11 SHORT CHIP 0
R165 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R166 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R167 1-216-801-11 METAL CHIP 22 5% 1/10W
R168 1-216-801-11 METAL CHIP 22 5% 1/10W
R169 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R170 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R171 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R172 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R173 1-216-805-11 METAL CHIP 47 5% 1/10W
R174 1-216-805-11 METAL CHIP 47 5% 1/10W
R179 1-216-864-11 SHORT CHIP 0 (E12,E32,MX,PX)
R180 1-216-864-11 SHORT CHIP 0 (E12,E32,MX,PX)
R181 1-216-864-11 SHORT CHIP 0 (E12,E32,MX,PX)
R182 1-216-864-11 SHORT CHIP 0 (E12,E32,MX,PX)
R183 1-216-864-11 SHORT CHIP 0 (E12,E32,MX,PX)
R184 1-216-821-11 METAL CHIP 1K 5% 1/10W
R185 1-216-864-11 SHORT CHIP 0
R186 1-216-821-11 METAL CHIP 1K 5% 1/10W
R187 1-216-821-11 METAL CHIP 1K 5% 1/10W
< SWITCH >
S100 1-762-875-21 SWITCH, KEYBOARD (A)
S101 1-762-875-21 SWITCH, KEYBOARD (H)
S102 1-762-875-21 SWITCH, KEYBOARD (>)
S103 1-762-875-21 SWITCH, KEYBOARD (x)
S104 1-762-875-21 SWITCH, KEYBOARD (X)
S105 1-762-875-21 SWITCH, KEYBOARD (.)
S106 1-762-875-21 SWITCH, KEYBOARD (FUNCTION)
S107 1-480-136-11 ENCODER, ROTARY (12 TYPE) (VOLUME)
*************************************************************
JACK
Ver. 1.1
