Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-DZ370/DZ560/DZ570/DZ660/DZ777
92
CN3001 1-564-706-11 PIN, CONNECTOR (SMALL TYPE) 4P
CN4301 1-820-117-41 CONNECTOR, FFC/FPC 19P (DZ560/DZ660)
CN4302 1-820-116-41 CONNECTOR, FFC/FPC 17P
(DZ370/DZ570/DZ777)
< DIODE >
D501 6-501-817-01 DIODE MA2J1110GLS0
D502 6-500-334-01 DIODE MC2836-T112-1
D505 6-500-334-01 DIODE MC2836-T112-1
D701 6-501-579-01 DIODE MC2837
D2101 6-501-749-01 DIODE MAZ8082G0LS0
D2102 6-501-740-01 DIODE MAZ8068G0LS0
D2103 6-501-740-01 DIODE MAZ8068G0LS0
D3071 6-501-817-01 DIODE MA2J1110GLS0
D3072 6-501-817-01 DIODE MA2J1110GLS0
D3073 6-501-817-01 DIODE MA2J1110GLS0
D3551 6-501-579-01 DIODE MC2837
D3552 6-501-774-01 DIODE MAZ8150G0LS0
D4111 6-501-696-01 DIODE RSA39LTE25
D4112 6-501-696-01 DIODE RSA39LTE25
D4151 6-501-696-01 DIODE RSA39LTE25
D4152 6-501-696-01 DIODE RSA39LTE25
D4201 6-501-696-01 DIODE RSA39LTE25
D4202 6-501-696-01 DIODE RSA39LTE25
D4251 6-501-696-01 DIODE RSA39LTE25
D4252 6-501-696-01 DIODE RSA39LTE25
D4301 6-501-696-01 DIODE RSA39LTE25
D4302 6-501-696-01 DIODE RSA39LTE25
D4401 6-501-696-01 DIODE RSA39LTE25
D4402 6-501-696-01 DIODE RSA39LTE25
D4501 6-501-696-01 DIODE RSA39LTE25 (DZ370/DZ777)
D4502 6-501-696-01 DIODE RSA39LTE25 (DZ370/DZ777)
D9712 6-501-817-01 DIODE MA2J1110GLS0
< FERRITE BEAD >
FB505 1-469-365-21 INDUCTOR, FERRITE BEAD FBMJ2125
FB506 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB508 1-469-365-21 INDUCTOR, FERRITE BEAD FBMJ2125
FB510 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB1106 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB1107 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB1108 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB1109 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB1111 1-469-670-21 FERRITE, EMI (SMD) (2012)
FB1112 1-469-670-21 FERRITE, EMI (SMD) (2012)
FB1113 1-469-670-21 FERRITE, EMI (SMD) (2012)
FB1115 1-469-670-21 FERRITE, EMI (SMD) (2012)
FB1116 1-469-670-21 FERRITE, EMI (SMD) (2012)
FB1117 1-469-670-21 FERRITE, EMI (SMD) (2012)
FB1118 1-469-670-21 FERRITE, EMI (SMD) (2012)
FB2101 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB2102 1-469-379-11 FERRITE, EMI (SMD) (2012)
FB2103 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB2104 1-469-379-11 FERRITE, EMI (SMD) (2012)
FB2105 1-469-379-11 FERRITE, EMI (SMD) (2012)
FB2120 1-469-118-21 FERRITE, EMI (SMD) (1608)
FB2121 1-469-118-21 FERRITE, EMI (SMD) (1608)
FB2122 1-469-118-21 FERRITE, EMI (SMD) (1608)
FB2124 1-469-118-21 FERRITE, EMI (SMD) (1608)
FB2125 1-469-118-21 FERRITE, EMI (SMD) (1608)
< FILTER >
FL4501 1-234-177-21 FILTER, CHIP EMI
< IC >
IC201 6-705-308-01 IC SI-3010KM-TL
IC202
8-759-710-97 IC NJM4565M-D
IC301 6-600-466-01 IC TORX147L(SONY)
(TV/VIDEO (DIGITAL IN OPTICAL))
(DZ370/DZ570)
IC301 6-600-466-01 IC TORX147L(SONY) (TV (DIGITAL IN OPTICAL))
(DZ560/DZ660/DZ777)
IC302 6-706-492-01 IC TC7SHU04FU(T5RSOJF)
IC501 A-1545-464-A IC R5F3640DDFAR (for SERVICE)
IC502 6-705-338-01 IC TK11250CMCL-G
IC503 6-708-922-01 IC PST3635NR
IC504 6-705-308-01 IC SI-3010KM-TL
IC505 6-705-308-01 IC SI-3010KM-TL
IC506 6-705-308-01 IC SI-3010KM-TL
IC507 6-705-337-01 IC TK11150CSCL-G
IC510 (Not supplied) IC S-24CS16A0I-J8T1G
IC702 8-759-825-15 IC LC89056W-E
IC707 6-710-554-01 IC PCM1808PWR
IC1101 6-711-522-01 IC CXD9917R
IC1102 6-808-296-01 IC MX29LV320CBTC70-OHI1-0804UC
(E32,MX,PX)
IC1102 6-808-297-01 IC MX29LV320CBTC70-OHI1-0804CE
(AEP,UK,E3,E12,E15,AUS)
IC1102 6-808-298-01 IC MX29LV320CBTC70-OHI1-0804GA (KR,TW)
IC1103 (Not supplied) IC S-24CS64A01-J8T1G
IC1104 6-707-897-01 IC EDS6416AHTA-75-E
IC1105 6-702-302-01 IC TK11133CSCL-G
IC1107 6-702-302-01 IC TK11133CSCL-G
IC1110 6-707-739-01 IC MM1661JTRE
IC1201 6-704-524-01 IC FAN8036L
IC1705 8-759-592-47 IC TC7SZ08FU(TE85R)
IC1706 8-759-592-47 IC TC7SZ08FU(TE85R)
IC1707 6-705-337-01 IC TK11150CSCL-G
IC1708 6-702-302-01 IC TK11133CSCL-G
IC2101 8-759-700-07 IC NJM2903M
IC3001 8-759-710-97 IC NJM4565M-D
IC3003 8-759-680-48 IC TC7WH157FK(TE85R)
IC3010 6-705-979-01 IC CXD9788AR
IC3020 6-705-979-01 IC CXD9788AR
IC3030 6-705-979-01 IC CXD9788AR
IC3050 6-702-300-01 IC TK11118CSCL-G
IC3051 6-709-888-01 IC TC7WHU04FK(T5RSOYF
IC3100 6-708-921-01 IC CXD9883M
IC3150 6-708-921-01 IC CXD9883M
IC3200 6-708-921-01 IC CXD9883M
IC3250 6-708-921-01 IC CXD9883M
IC3300 6-708-921-01 IC CXD9883M
IC3400 6-708-921-01 IC CXD9883M
IC3500 6-708-921-01 IC CXD9883M (DZ370/DZ777)
IC4502 6-707-853-01 IC TC74LCX541FT(EKJ)
< JACK >
J302 1-784-431-11 JACK, PIN 1P (TV/VIDEO (DIGITAL IN COAXIAL))
(DZ370/DZ570)
J302 1-784-431-11 JACK, PIN 1P (TV (DIGITAL IN COAXIAL))
(DZ560/DZ660/DZ777)
< COIL >
L200 1-469-525-91 INDUCTOR 10uH
L301 1-469-525-91 INDUCTOR 10uH
L302 1-469-525-91 INDUCTOR 10uH
MAIN
When IC510 and IC1103 on the Main board are damaged, exchange
the new Main board for the Main board which IC damaged.
Ver. 1.1
