Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-DZ370/DZ560/DZ570/DZ660/DZ777
98
R4518 1-216-864-11 SHORT CHIP 0
R4716 1-216-864-11 SHORT CHIP 0 (DZ370/DZ570/DZ777)
R4717 1-216-864-11 SHORT CHIP 0 (DZ370/DZ570/DZ777)
R4718 1-216-864-11 SHORT CHIP 0
R4719 1-216-864-11 SHORT CHIP 0
R4721 1-216-864-11 SHORT CHIP 0
R4805 1-216-801-11 METAL CHIP 22 5% 1/10W
R9918 1-216-821-11 METAL CHIP 1K 5% 1/10W
R9920 1-216-864-11 SHORT CHIP 0
R9922 1-216-833-11 METAL CHIP 10K 5% 1/10W
R9924 1-216-821-11 METAL CHIP 1K 5% 1/10W
R9928 1-216-837-11 METAL CHIP 22K 5% 1/10W
R9929 1-216-837-11 METAL CHIP 22K 5% 1/10W
R9934 1-216-833-11 METAL CHIP 10K 5% 1/10W
R9935 1-216-864-11 SHORT CHIP 0
R9941 1-216-838-11 METAL CHIP 27K 5% 1/10W
R9945 1-216-813-11 METAL CHIP 220 5% 1/10W
< NETWORK RESISTOR >
RB1103 1-234-400-21 CONDUCTOR, NETWORK 0X4 (1005)
RB1104 1-234-400-21 CONDUCTOR, NETWORK 0X4 (1005)
RB1105 1-234-944-21 RES, NETWORK 47X4 (1005)
RB1106 1-234-944-21 RES, NETWORK 47X4 (1005)
RB1107 1-234-944-21 RES, NETWORK 47X4 (1005)
RB1108 1-234-944-21 RES, NETWORK 47X4 (1005)
RB1109 1-234-400-21 CONDUCTOR, NETWORK 0X4 (1005)
RB1110 1-234-400-21 CONDUCTOR, NETWORK 0X4 (1005)
RB1111 1-234-400-21 CONDUCTOR, NETWORK 0X4 (1005)
RB1112 1-234-400-21 CONDUCTOR, NETWORK 0X4 (1005)
RB1113 1-234-400-21 CONDUCTOR, NETWORK 0X4 (1005)
RB1114 1-234-400-21 CONDUCTOR, NETWORK 0X4 (1005)
RB1115 1-234-400-21 CONDUCTOR, NETWORK 0X4 (1005)
< TERMINAL BOARD >
TB3901 1-780-453-11 TERMINAL BOARD (SPEAKER) 2P
(SPEAKER (CENTER,SUBWOOFER))
< VIBRATOR >
X501 1-795-058-21 VIBRATOR, CERAMIC (5MHz)
X701 1-795-692-11 QUARTZ CRYSTAL UNIT (12.288MHz)
X1101 1-795-630-11 VIBRATOR, CRYSTAL (27MHz)
X3051 1-795-660-21 QUARTZ CRYSTAL UNIT (49.1MHz)
*************************************************************
MS-203 BOARD
************
< CONNECTOR >
CN001 1-815-412-11 CONNECTOR, FFC/FPC 5P
< SWITCH >
S001 1-786-693-11 SWITCH, DETECTION (CHUCK/TRAY DETECT)
*************************************************************
A-1382-402-A POWER BOARD, COMPLETE (AEP,UK)
A-1392-694-A POWER BOARD, COMPLETE
(E3,E12,E15,AUS,KR)
A-1392-696-A POWER BOARD, COMPLETE (TW)
A-1452-054-A POWER BOARD, COMPLETE (MX)
A-1452-056-A POWER BOARD, COMPLETE (E32,PX)
***********************
1-533-217-41 HOLDER, FUSE
7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3
7-685-647-79 SCREW +BVTP 3X10 TYPE2 IT-3
< CAPACITOR >
0 C901 1-165-529-11 MYLAR 0.22uF 10% 275V
0 C902 1-165-529-11 MYLAR 0.22uF 10% 275V
0 C903 1-112-330-11 ELECT(BLOCK) 1000uF 20% 200V (TW)
0 C903 1-112-331-11 ELECT(BLOCK) 1000uF 20% 250V (MX)
0 C903 1-112-333-11 ELECT(BLOCK) 330uF 20% 450V
(EXCEPT AEP,UK,MX,TW)
0 C903 1-114-346-11 ELECT(BLOCK) 330uF 20% 400V
(AEP,UK)
0 C905 1-112-334-11 FILM 0.01uF 5% 400V
(MX,TW)
0 C905 1-112-335-11 FILM 0.0033uF 5% 400V
(EXCEPT MX,TW)
0 C906 1-117-815-11 FILM 0.001uF 3% 1.5KV
(EXCEPT MX,TW)
C907 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(EXCEPT MX,TW)
C907 1-162-965-11 CERAMIC CHIP 0.0015uF 10% 50V
(MX,TW)
C908 1-104-962-11 ELECT 47uF 20% 35V
C909 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C910 1-107-906-11 ELECT 10uF 20% 50V
(MX,TW)
C910 1-107-907-11 ELECT 22uF 20% 50V
(EXCEPT E32,MX,PX,TW)
C910 1-126-967-11 ELECT 47uF 20% 50V
(E32,PX)
C911 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C912 1-126-947-11 ELECT 47uF 20% 35V
0 C913 1-112-866-51 CERAMIC 100PF 10% 250V
C916 1-100-566-11 CERAMIC CHIP 0.1uF 10% 25V
0 C918 1-112-887-51 CERAMIC 0.01uF 20% 250V
0 C920 1-112-887-51 CERAMIC 0.01uF 20% 250V
0 C921 1-117-220-81 CERAMIC 150PF 5% 2KV
C922 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C923 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
0 C924 1-112-335-11 FILM 0.0033uF 5% 400V
0 C925 1-107-974-81 CERAMIC 47PF 5% 2KV
0 C926 1-128-560-11 ELECT 22uF 20% 100V
C927 1-128-947-31 ELECT 3300uF 20% 10V
C928 1-137-947-21 ELECT 2700uF 20% 16V
C929 1-128-954-11 ELECT 1000uF 20% 25V
0 C930 1-112-866-51 CERAMIC 100PF 10% 250V
C932 1-100-924-21 ELECT 2200uF 20% 35V
C933 1-100-924-21 ELECT 2200uF 20% 35V
C934 1-112-831-11 ELECT 2200uF 20% 35V
C935 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C936 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C937 1-100-756-11 CERAMIC CHIP 0.047uF 50V
0 C938 1-112-869-51 CERAMIC 470PF 10% 250V
C939 1-136-165-00 FILM 0.1uF 5% 50V
POWERMS-203MAIN
Ver. 1.1
