Sony HCD-DZ500F - 5-3. PRINTED WIRING BOARD - DMB10 SECTION (SIDE B) -

2828
HCD-DZ500F
HCD-DZ500F
5-3. PRINTED WIRING BOARD – DMB10 SECTION (SIDE B) –
• See page 21 for Circuit Boards Location.
• Semiconductor
Location
Ref. No. Location
D3601 B-2
D3602 B-2
IC105 D-5
IC107 B-5
IC3601 B-2
IC4501 C-2
IC4502 C-2
Q101 C-5
Q102 C-5
IC3601
IC4501
IC4502
IC107
IC105
10
1
11
20
1
3
5
4
1
3
5
4
S
S
E
E
1
3
4
5
R1555
R308
12
A
B
C
D
E
3456
R236
R238
R239
R2505
R237
R222
:Uses unleaded solder.
