66
HCD-DZ500F
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
C212 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C213 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C214 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C215 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C217 1-126-204-11 ELECT CHIP 47uF 20% 16V
C218 1-124-779-00 ELECT CHIP 10uF 20% 16V
C219 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C220 1-124-779-00 ELECT CHIP 10uF 20% 16V
C221 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C222 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C223 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C224 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C225 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C226 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C233 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C402 1-126-204-11 ELECT CHIP 47uF 20% 16V
C403 1-126-205-11 ELECT CHIP 47uF 20% 6.3V
C3601 1-117-370-11 CERAMIC CHIP 10uF 10V
C3602 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3603 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3605 1-126-205-11 ELECT CHIP 47uF 20% 6.3V
C3606 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3607 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3608 1-124-779-00 ELECT CHIP 10uF 20% 16V
C3609 1-124-779-00 ELECT CHIP 10uF 20% 16V
C3610 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3611 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C3621 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C4501 1-117-370-11 CERAMIC CHIP 10uF 10V
C4502 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C4504 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
< CONNECTOR >
CN101 1-815-763-11 CONNECTOR, FFC/FPC 24P
* CN105 1-770-470-21 PIN, CONNECTOR (PC BOARD) 6P
CN106 1-784-370-21 CONNECTOR, FFC/FPC 11P
* CN201 1-770-470-21 PIN, CONNECTOR (PC BOARD) 6P
CN202 1-784-365-21 CONNECTOR, FFC/FPC 5P
CN301 1-793-989-21 FFC/CONNECTOR, FPC (LIF (NON-ZIF)) 13P
CN302 1-784-366-21 CONNECTOR, FFC/FPC 7P
CN401 1-779-993-11 PIN, CONNECTOR (PWB) 5P
CN4501 1-784-370-21 CONNECTOR, FFC/FPC 11P
< DIODE >
D1001 8-719-058-24 DIODE RB501V-40TE-17
D3501 8-719-988-61 DIODE 1SS355TE-17
D3502 8-719-988-61 DIODE 1SS355TE-17
D3601 8-719-988-61 DIODE 1SS355TE-17
D3602 8-719-988-61 DIODE 1SS355TE-17
< FERRITE BEAD >
FB111 1-414-226-21 INDUCTOR, FERRITE BEAD
FB112 1-414-226-21 INDUCTOR, FERRITE BEAD
FB113 1-414-226-21 INDUCTOR, FERRITE BEAD
FB114 1-414-226-21 INDUCTOR, FERRITE BEAD
FB115 1-414-226-21 INDUCTOR, FERRITE BEAD
FB401 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB402 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB403 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB404 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB405 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB406 1-469-324-21 FERRITE, EMI (SMD) (2012)
< FILTER >
FL101 1-234-494-21 FILTER, EMI REMOVAL (SMD)
FL104 1-234-494-21 FILTER, EMI REMOVAL (SMD)
FL105 1-234-494-21 FILTER, EMI REMOVAL (SMD)
FL106 1-234-494-21 FILTER, EMI REMOVAL (SMD)
FL107 1-234-494-21 FILTER, EMI REMOVAL (SMD)
FL108 1-234-494-21 FILTER, EMI REMOVAL (SMD)
FL401 1-234-494-21 FILTER, EMI REMOVAL (SMD)
FL402 1-233-893-21 FILTER, CHIP EMI
FL403 1-234-494-21 FILTER, EMI REMOVAL (SMD)
FL4501 1-234-494-21 FILTER, EMI REMOVAL (SMD)
< IC >
IC101 6-805-567-01 IC MBM29DL32TF70-OBA1-0502CE
IC102 6-706-727-01 IC CXD9804R
✩ IC103 (Not supplied) IC BR24L64F-WE2
IC104 6-706-390-11 IC HY57V641620HGTP-HDR
IC105 6-702-302-01 IC TK11133CSCL-G
IC106 8-759-667-18 IC PQ018EZ01ZPH
IC107 6-702-302-01 IC TK11133CSCL-G
IC201 6-704-524-01 IC FAN8036L
IC3601 6-707-608-01 IC PCM1803DBR
IC4501 8-759-573-97 IC SN74LVC541APWR
IC4502 6-703-589-01 IC SN74LVC1G125DCKR
< COIL >
L3601 1-469-555-21 INDUCTOR 10uH
L3602 1-469-555-21 INDUCTOR 10uH
< TRANSISTOR >
Q101 6-550-008-01 TRANSISTOR UM6K1N-TN
Q102 6-550-653-01 TRANSISTOR QST8TR
Q103 8-729-027-52 TRANSISTOR DTC124EKA-T146
< RESISTOR >
R101 1-216-809-11 METAL CHIP 100 5% 1/10W
R104 1-216-864-11 SHORT CHIP 0
R105 1-216-833-11 METAL CHIP 10K 5% 1/10W
R106 1-216-833-11 METAL CHIP 10K 5% 1/10W
R107 1-216-833-11 METAL CHIP 10K 5% 1/10W
R108 1-216-857-11 METAL CHIP 1M 5% 1/10W
R109 1-216-864-11 SHORT CHIP 0
R110 1-216-841-11 METAL CHIP 47K 5% 1/10W
R111 1-216-809-11 METAL CHIP 100 5% 1/10W
R112 1-211-977-11 METAL CHIP 22 0.5% 1/10W
R113 1-211-977-11 METAL CHIP 22 0.5% 1/10W
R114 1-216-845-11 METAL CHIP 100K 5% 1/10W
R115 1-211-977-11 METAL CHIP 22 0.5% 1/10W
R116 1-216-821-11 METAL CHIP 1K 5% 1/10W
R117 1-216-841-11 METAL CHIP 47K 5% 1/10W
R118 1-216-801-11 METAL CHIP 22 5% 1/10W
R120 1-216-801-11 METAL CHIP 22 5% 1/10W
DMB10
✩ New part of EEP ROM (IC103) on the DMB10 board cannot be used.
Therefore, if the mounted DMB10 board (A-1108-644-A) is replaced,
exchange new EEP ROM (IC103) with that used before the replacement.
