68
HCD-DZ500F
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R3607 1-216-864-11 SHORT CHIP 0
R3609 1-216-864-11 SHORT CHIP 0
R3611 1-216-809-11 METAL CHIP 100 5% 1/10W
R3621 1-216-809-11 METAL CHIP 100 5% 1/10W
R4501 1-216-864-11 SHORT CHIP 0
R4502 1-216-864-11 SHORT CHIP 0
R4510 1-216-805-11 METAL CHIP 47 5% 1/10W
R4511 1-216-809-11 METAL CHIP 100 5% 1/10W
R4512 1-400-244-11 BEAD, FERRITE (CHIP) (1608)
R4513 1-216-864-11 SHORT CHIP 0
R4514 1-216-864-11 SHORT CHIP 0
R4515 1-216-864-11 SHORT CHIP 0
R4516 1-216-864-11 SHORT CHIP 0
R4518 1-216-864-11 SHORT CHIP 0
R4520 1-216-864-11 SHORT CHIP 0
R4701 1-216-864-11 SHORT CHIP 0
R4702 1-216-864-11 SHORT CHIP 0
R4703 1-216-864-11 SHORT CHIP 0
R4704 1-216-864-11 SHORT CHIP 0
R4705 1-216-864-11 SHORT CHIP 0
R4706 1-216-864-11 SHORT CHIP 0
< COMPOSITION CIRCUIT BLOCK >
RB103 1-234-795-21 RES, NETWORK 0X4 (2010)
RB104 1-234-795-21 RES, NETWORK 0X4 (2010)
RB105 1-234-371-21 RES, NETWORK 47 (1005X4)
RB106 1-234-371-21 RES, NETWORK 47 (1005X4)
RB107 1-234-370-21 RES, NETWORK 22 (1005X4)
RB108 1-234-370-21 RES, NETWORK 22 (1005X4)
RB111 1-234-795-21 RES, NETWORK 0X4 (2010)
RB112 1-234-370-21 RES, NETWORK 22 (1005X4)
RB113 1-234-370-21 RES, NETWORK 22 (1005X4)
< VIBRATOR >
X101 1-781-867-21 VIBRATOR, CRYSTAL (27MHz)
************************************************************
A-1088-414-A FL BOARD, COMPLETE
******************
< CAPACITOR >
C800 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C801 1-163-037-11 CERAMIC CHIP 0.022uF 10% 50V
C802 1-119-943-91 ELECT 47uF 20% 50V
C803 1-124-584-00 ELECT 100uF 20% 10V
C804 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C805 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C806 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C807 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C808 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C809 1-126-795-11 ELECT 10uF 20% 50V
C810 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C811 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C812 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C813 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C814 1-126-795-11 ELECT 10uF 20% 50V
C815 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C816 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C817 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C818 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C819 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C820 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C821 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C822 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C823 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C824 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C825 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C826 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
< CONNECTOR >
CN801 1-779-556-21 CONNECTOR, FFC (LIF (NON-ZIF)) 19P
* CN805 1-568-942-11 PIN, CONNECTOR 4P
< DIODE >
D801 8-719-988-61 DIODE 1SS355TE-17
D802 8-719-988-61 DIODE 1SS355TE-17
D803 8-719-069-56 DIODE UDZSTE-176.2B
D804 8-719-988-61 DIODE 1SS355TE-17
D805 8-719-988-61 DIODE 1SS355TE-17
< FERRITE BEAD >
FB806 1-414-813-11 FERRITE, EMI (SMD) (2012)
< FLUORESCENT INDICATOR >
FL801 1-519-792-11 INDICATOR TUBE, FLUORESCENT
< IC >
IC801 6-600-349-21 IC NJL23H400A ( )
IC802 8-759-643-83 IC uPD16315GB-3BS
< COIL >
L801 1-410-671-31 INDUCTOR 47uH
L802 1-410-671-31 INDUCTOR 47uH
< TRANSISTOR >
Q801 6-550-065-01 TRANSISTOR CPH5504-TL-E
Q802 8-729-120-28 TRANSISTOR 2SC1623-L5L6
< RESISTOR >
R800 1-216-821-11 METAL CHIP 1K 5% 1/10W
R801 1-216-839-11 METAL CHIP 33K 5% 1/10W
R802 1-216-809-11 METAL CHIP 100 5% 1/10W
R804 1-216-828-11 METAL CHIP 3.9K 5% 1/10W
R805 1-216-295-91 SHORT CHIP 0
R810 1-216-864-11 SHORT CHIP 0
R811 1-216-844-11 METAL CHIP 82K 5% 1/10W
R812 1-216-845-11 METAL CHIP 100K 5% 1/10W
R813 1-216-845-11 METAL CHIP 100K 5% 1/10W
R814 1-216-809-11 METAL CHIP 100 5% 1/10W
R815 1-216-809-11 METAL CHIP 100 5% 1/10W
R816 1-216-809-11 METAL CHIP 100 5% 1/10W
R817 1-216-821-11 METAL CHIP 1K 5% 1/10W
R819 1-216-805-11 METAL CHIP 47 5% 1/10W
R820 1-216-845-11 METAL CHIP 100K 5% 1/10W
DMB10 FL
