HCD-DZ500F
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
C622 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C625 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C626 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C629 1-126-960-11 ELECT 1uF 20% 50V
C630 1-126-960-11 ELECT 1uF 20% 50V
C632 1-104-662-91 ELECT 22uF 20% 25V
C633 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C634 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
< CONNECTOR >
CN101 1-568-828-11 CONNECTOR, FFC 9P (RU)
CN101 1-816-955-11 CONNECTOR, FFC/FPC 11P (EXCEPT RU)
CN201 1-779-281-11 CONNECTOR, FFC (LIF (NON-ZIF)) 13P
CN601 1-779-291-11 CONNECTOR, FFC (LIF (NON-ZIF)) 23P
* CN602 1-568-942-11 PIN, CONNECTOR 4P
< DIODE >
D201 8-719-988-61 DIODE 1SS355TE-17
D202 8-719-988-61 DIODE 1SS355TE-17
D203 8-719-988-61 DIODE 1SS355TE-17
D206 8-719-988-61 DIODE 1SS355TE-17
< IC >
IC201 6-707-489-01 IC BH7868FS-E2
IC202 6-707-489-01 IC BH7868FS-E2
IC203 8-759-696-10 IC NJM2235V (TE2)
IC602 8-759-385-76 IC MC14052 BDR2
IC603 8-759-649-89 IC MC4558CD
< JACK >
J202 1-815-911-11 CONNECTOR, SQUARE TYPE 21P (EURO AV)
J203 1-819-063-11 JACK, PIN (6P) (SAT/COMPONENT VIDEO OUT)
< COIL >
L101 1-469-525-91 INDUCTOR 10uH
L201 1-469-525-91 INDUCTOR 10uH
L202 1-469-525-91 INDUCTOR 10uH
L203 1-469-525-91 INDUCTOR 10uH
L602 1-469-525-91 INDUCTOR 10uH
< TRANSISTOR >
Q201 1-801-806-11 TRANSISTOR DTC144EKA
Q202 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q203 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q204 1-801-806-11 TRANSISTOR DTC144EKA
Q205 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q206 1-801-806-11 TRANSISTOR DTC144EKA
Q207 8-729-027-52 TRANSISTOR DTC124EKA-T146
Q208 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q209 1-801-806-11 TRANSISTOR DTC144EKA
Q601 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q602 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q603 8-729-027-52 TRANSISTOR DTC124EKA-T146
Q604 8-729-027-52 TRANSISTOR DTC124EKA-T146
Q605 8-729-027-23 TRANSISTOR DTA114EKA-T146
< RESISTOR >
R102 1-216-864-11 SHORT CHIP 0
R105 1-216-833-11 METAL CHIP 10K 5% 1/10W
(EXCEPT RU)
R105 1-216-845-11 METAL CHIP 100K 5% 1/10W
(RU)
R109 1-216-864-11 SHORT CHIP 0
R114 1-216-864-11 SHORT CHIP 0
R115 1-216-833-11 METAL CHIP 10K 5% 1/10W
(EXCEPT RU)
R115 1-216-845-11 METAL CHIP 100K 5% 1/10W
(RU)
R116 1-216-833-11 METAL CHIP 10K 5% 1/10W
(EXCEPT RU)
R116 1-216-845-11 METAL CHIP 100K 5% 1/10W
(RU)
R117 1-216-833-11 METAL CHIP 10K 5% 1/10W
(EXCEPT RU)
R117 1-216-845-11 METAL CHIP 100K 5% 1/10W
(RU)
R201 1-216-821-11 METAL CHIP 1K 5% 1/10W
R202 1-216-821-11 METAL CHIP 1K 5% 1/10W
R203 1-216-864-11 SHORT CHIP 0
R204 1-216-821-11 METAL CHIP 1K 5% 1/10W
R205 1-216-864-11 SHORT CHIP 0
R206 1-216-864-11 SHORT CHIP 0
R208 1-216-841-11 METAL CHIP 47K 5% 1/10W
R210 1-216-849-11 METAL CHIP 220K 5% 1/10W
R211 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R212 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R213 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R214 1-216-821-11 METAL CHIP 1K 5% 1/10W
R215 1-216-837-11 METAL CHIP 22K 5% 1/10W
R216 1-216-815-11 METAL CHIP 330 5% 1/10W
R217 1-216-815-11 METAL CHIP 330 5% 1/10W
R218 1-216-815-11 METAL CHIP 330 5% 1/10W
R219 1-216-815-11 METAL CHIP 330 5% 1/10W
R220 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R221 1-218-285-11 METAL CHIP 75 5% 1/10W
R225 1-216-864-11 SHORT CHIP 0
R226 1-216-864-11 SHORT CHIP 0
R230 1-218-285-11 METAL CHIP 75 5% 1/10W
R231 1-218-285-11 METAL CHIP 75 5% 1/10W
R232 1-218-285-11 METAL CHIP 75 5% 1/10W
R233 1-218-285-11 METAL CHIP 75 5% 1/10W
R234 1-218-285-11 METAL CHIP 75 5% 1/10W
R235 1-218-285-11 METAL CHIP 75 5% 1/10W
R236 1-218-285-11 METAL CHIP 75 5% 1/10W
R237 1-216-864-11 SHORT CHIP 0
R238 1-216-864-11 SHORT CHIP 0
R239 1-216-864-11 SHORT CHIP 0
R240 1-216-864-11 SHORT CHIP 0
R243 1-216-864-11 SHORT CHIP 0
R244 1-216-864-11 SHORT CHIP 0
R245 1-216-864-11 SHORT CHIP 0
R603 1-216-821-11 METAL CHIP 1K 5% 1/10W
R606 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R609 1-216-817-11 METAL CHIP 470 5% 1/10W
R610 1-216-817-11 METAL CHIP 470 5% 1/10W
R611 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R612 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
I/O
