Sony HCD-EC59 - Page 37

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-EC59
3737
C122 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C123 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C124 1-128-995-21 ELECT CHIP 100uF 20% 10V
C125 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C126 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C127 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C128 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C129 1-128-995-21 ELECT CHIP 100uF 20% 10V
C130 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C131 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C132 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C133 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C201 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C203 1-137-710-91 CERAMIC CHIP 10uF 20% 6.3V
C205 1-137-710-91 CERAMIC CHIP 10uF 20% 6.3V
C206 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C207 1-128-995-21 ELECT CHIP 100uF 20% 10V
C208 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C209 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C301 1-128-394-11 ELECT CHIP 220uF 20% 10V
C302 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C303 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C304 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C401 1-128-995-21 ELECT CHIP 100uF 20% 10V
C402 1-128-995-21 ELECT CHIP 100uF 20% 10V
C403 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C404 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C406 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C407 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C413 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C414 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C418 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
< CONNECTOR >
CN201 1-770-425-51 CONNECTOR, FFC/FPC 16P
CN403 1-784-875-51 CONNECTOR, FFC (LIF (NON-ZIF)) 25P
< IC >
IC101 6-713-623-01 IC LC786950T-US-H
IC301 6-710-637-01 IC BA5826HFP-E2
< TRANSISTOR
>
Q201 6-551-120-01 TRANSISTOR 2SA2119K
< RESISTOR >
R101 1-216-815-11 METAL CHIP 330 5% 1/10W
R102 1-216-833-11 METAL CHIP 10K 5% 1/10W
R103 1-216-864-11 SHORT CHIP 0
R104 1-216-864-11 SHORT CHIP 0
R105 1-216-864-11 SHORT CHIP 0
R106 1-216-864-11 SHORT CHIP 0
R107 1-216-843-11 METAL CHIP 68K 5% 1/10W
R108 1-216-821-11 METAL CHIP 1K 5% 1/10W
R109 1-216-821-11 METAL CHIP 1K 5% 1/10W
R111 1-216-837-11 METAL CHIP 22K 5% 1/10W
R112 1-216-864-11 SHORT CHIP 0
R113 1-216-819-11 METAL CHIP 680 5% 1/10W
R114 1-216-819-11 METAL CHIP 680 5% 1/10W
R116 1-216-843-11 METAL CHIP 68K 5% 1/10W
R117 1-216-833-11 METAL CHIP 10K 5% 1/10W
JACK
R118 1-216-809-11 METAL CHIP 100 5% 1/10W
R120 1-216-833-11 METAL CHIP 10K 5% 1/10W
R121 1-216-833-11 METAL CHIP 10K 5% 1/10W
R122 1-216-833-11 METAL CHIP 10K 5% 1/10W
R123 1-216-833-11 METAL CHIP 10K 5% 1/10W
R124 1-216-833-11 METAL CHIP 10K 5% 1/10W
R126 1-216-864-11 SHORT CHIP 0
R129 1-216-809-11 METAL CHIP 100 5% 1/10W
R131 1-216-295-00 SHORT CHIP 0
R201 1-218-446-11 METAL CHIP 1 5% 1/10W
R202 1-216-789-11 METAL CHIP 2.2 5% 1/10W
R203 1-216-864-11 SHORT CHIP 0
R301 1-216-830-11 METAL CHIP 5.6K 5% 1/10W
R302 1-216-839-11 METAL CHIP 33K 5% 1/10W
R303 1-216-834-11 METAL CHIP 12K 5% 1/10W
R304 1-216-833-11 METAL CHIP 10K 5% 1/10W
R305 1-216-832-11 METAL CHIP 8.2K 5% 1/10W
R401 1-216-295-00 SHORT CHIP 0
R402 1-216-295-00 SHORT CHIP 0
R403 1-216-809-11 METAL CHIP 100 5% 1/10W
R404 1-216-809-11 METAL CHIP 100 5% 1/10W
R405 1-216-809-11 METAL CHIP 100 5% 1/10W
R406 1-216-809-11 METAL CHIP 100 5% 1/10W
R407 1-216-809-11 METAL CHIP 100 5% 1/10W
R408 1-216-809-11 METAL CHIP 100 5% 1/10W
R409 1-216-809-11 METAL CHIP 100 5% 1/10W
R411 1-216-809-11 METAL CHIP 100 5% 1/10W
R412 1-216-809-11 METAL CHIP 100 5% 1/10W
R413 1-216-809-11 METAL CHIP 100 5% 1/10W
R414 1-216-809-11 METAL CHIP 100 5% 1/10W
R415 1-216-809-11 METAL CHIP 100 5% 1/10W
R416 1-216-809-11 METAL CHIP 100 5% 1/10W
R417 1-216-295-00 SHORT CHIP 0
< VIBRATOR >
X101 1-795-101-21 VIBRATOR, CERAMIC (16.934MHz)
*************************************************************
JACK BOARD
***********
< CAPACITOR >
C491 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C495 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C496 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
< CONNECTOR >
CN496 1-784-770-11 CONNECTOR, FFC 9P
< JACK >
J491 1-566-822-51 JACK (PC IN)
J492 1-815-629-11 JACK (PHONES)
< RESISTOR >
R477 1-216-837-11 METAL CHIP 22K 5% 1/10W
R478 1-216-837-11 METAL CHIP 22K 5% 1/10W
*************************************************************
BD74UR
