36
HCD-EC59
SECTION 7
ELECTRICAL PARTS LIST
2CH AMP BOARD
**************
< CAPACITOR >
C101 1-126-960-11 ELECT 1uF 20% 50V
C102 1-126-960-11 ELECT 1uF 20% 50V
C103 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C104 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C105 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C106 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C107 1-162-908-11 CERAMIC CHIP 3PF 0.25PF 50V
C108 1-162-908-11 CERAMIC CHIP 3PF 0.25PF 50V
C109 1-126-947-11 ELECT 47uF 20% 35V
C110 1-126-947-11 ELECT 47uF 20% 35V
C111 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C112 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C141 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C142 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C160 1-165-621-11 CERAMIC CHIP 0.1uF 50V
C161 1-165-621-11 CERAMIC CHIP 0.1uF 50V
C162 1-126-968-11 ELECT 100uF 20% 50V
C163 1-126-968-11 ELECT 100uF 20% 50V
C164 1-165-621-11 CERAMIC CHIP 0.1uF 50V
C165 1-165-621-11 CERAMIC CHIP 0.1uF 50V
< CONNECTOR >
CN100 1-784-766-11 CONNECTOR, FFC 5P
< DIODE >
D140 6-501-817-01 DIODE MA2J1110GLS0
D141 6-500-335-01 DIODE MC2838-T112-1
< IC >
IC102 6-705-625-01 IC STK433-040
< TRANSISTOR >
Q141 6-551-270-01 TRANSISTOR 2SA2026
Q142 6-551-270-01 TRANSISTOR
2SA2026
< RESISTOR >
R103 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R104 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R105 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R106 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R107 1-216-841-11 METAL CHIP 47K 5% 1/10W
R108 1-216-841-11 METAL CHIP 47K 5% 1/10W
R109 1-216-817-11 METAL CHIP 470 5% 1/10W
R110 1-216-817-11 METAL CHIP 470 5% 1/10W
0 R111 1-216-361-31 METAL OXIDE 0.22 5% 2W F
0 R112 1-216-361-31 METAL OXIDE 0.22 5% 2W F
R113 1-216-841-11 METAL CHIP 47K 5% 1/10W
R114 1-216-841-11 METAL CHIP 47K 5% 1/10W
R115 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R116 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R119 1-216-809-11 METAL CHIP 100 5% 1/10W
R120 1-216-821-11 METAL CHIP 1K 5% 1/10W
R141 1-216-822-11 METAL CHIP 1.2K 5% 1/10W
R142 1-216-822-11 METAL CHIP 1.2K 5% 1/10W
R143 1-216-837-11 METAL CHIP 22K 5% 1/10W
R144 1-216-837-11 METAL CHIP 22K 5% 1/10W
R145 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R146 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R160 1-216-813-11 METAL CHIP 220 5% 1/10W
R161 1-216-813-11 METAL CHIP 220 5% 1/10W
R162 1-216-813-11 METAL CHIP 220 5% 1/10W
R163 1-216-813-11 METAL CHIP 220 5% 1/10W
*************************************************************
A-1748-699-A BD74UR BOARD, COMPLETE
***********************
< CAPACITOR >
C101 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C102 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C103 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C104 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C105 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C106 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C107 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C108 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C110 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V
C111 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C112 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C113 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C116 1-128-995-21 ELECT CHIP 100uF 20% 10V
C117 1-100-756-91 CERAMIC CHIP 0.047uF 10% 50V
C118 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C119 1-128-995-21 ELECT CHIP 100uF 20% 10V
C120 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C121 1-164-156-11 CERAMIC CHIP 0.1uF 25V
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
BD74UR
When indicating parts by reference num-
ber, please include the board name.
Note:
• Due to standardization, replacements in
the parts list may be different from the
parts specifi ed in the diagrams or the com-
ponents used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• Items marked “*” are not stocked since
they are seldom required for routine ser-
vice. Some delay should be anticipated
when ordering these items.
• RESISTORS
All resistors are in ohms.
METAL: Metal-fi lm resistor.
METAL OXIDE: Metal oxide-fi lm resistor.
F: nonfl ammable
• CAPACITORS
uF: μF
• COILS
uH: μH
• SEMICONDUCTORS
In each case, u: μ, for example:
uA. . : μA. . , uPA. . , μPA. . ,
uPB. . : μPB. . , uPC. . , μPC. . ,
uPD. . : μPD. .
• Abbreviation
AR : Argentina model
E2 : 120V AC area in E model
E4 : African model
E51 : Chilean and Peruvian models
MX : Mexican model
2CH AMP
The components identifi ed by mark 0
or dotted line with mark 0 are critical for
safety.
Replace only with part number specifi ed.
To Next Page
