Sony HCD-EC59 - Page 40

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-EC59
40
R692 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R693 1-216-821-11 METAL CHIP 1K 5% 1/10W
R697 1-216-864-11 SHORT CHIP 0
R698 1-216-837-11 METAL CHIP 22K 5% 1/10W
R700 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R701 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R702 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R704 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R705 1-216-837-11 METAL CHIP 22K 5% 1/10W
R706 1-216-813-11 METAL CHIP 220 5% 1/10W
R707 1-216-813-11 METAL CHIP 220 5% 1/10W
R709 1-216-864-11 SHORT CHIP 0
R715 1-216-809-11 METAL CHIP 100 5% 1/10W
R723 1-216-789-11 METAL CHIP 2.2 5% 1/10W
R727 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R728 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R731 1-249-395-11 CARBON 15 5% 1/4W
R732 1-249-395-11 CARBON 15 5% 1/4W
R733 1-249-395-11 CARBON 15 5% 1/4W
R734 1-216-841-11 METAL CHIP 47K 5% 1/10W
R735 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R736 1-216-833-11 METAL CHIP 10K 5% 1/10W
R737 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R738 1-216-817-11 METAL CHIP 470 5% 1/10W
R741 1-216-789-11 METAL CHIP 2.2 5% 1/10W
R742 1-216-789-11 METAL CHIP 2.2 5% 1/10W
R749 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R750 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R751 1-216-830-11 METAL CHIP 5.6K 5% 1/10W
R752 1-216-830-11 METAL CHIP 5.6K 5% 1/10W
R753 1-216-830-11 METAL CHIP 5.6K 5% 1/10W
R754 1-216-830-11 METAL CHIP 5.6K 5% 1/10W
R760 1-216-789-11 METAL CHIP 2.2 5% 1/10W
R761 1-216-817-11 METAL CHIP 470 5% 1/10W
R762 1-216-817-11 METAL CHIP 470 5% 1/10W
R763 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R764 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R765 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R767 1-216-791-11 METAL CHIP 3.3 5% 1/10W
R768 1-216-833-11 METAL CHIP 10K 5% 1/10W
R770 1-216-845-11 METAL CHIP 100K 5% 1/10W
R771 1-216-801-11 METAL CHIP 22 5% 1/10W
R772 1-216-834-11 METAL CHIP 12K 5% 1/10W
R773 1-216-849-11 METAL CHIP 220K 5% 1/10W
R774 1-216-833-11 METAL CHIP 10K 5% 1/10W
R775 1-216-849-11 METAL CHIP 220K 5% 1/10W
R776 1-216-841-11 METAL CHIP 47K 5% 1/10W
R781 1-216-845-11 METAL CHIP 100K 5% 1/10W
R782 1-216-833-11 METAL CHIP 10K 5% 1/10W
R787 1-216-835-11 METAL CHIP 15K 5% 1/10W
R788 1-216-835-11 METAL CHIP 15K 5% 1/10W
R791 1-216-845-11 METAL CHIP 100K 5% 1/10W
R792 1-216-849-11 METAL CHIP 220K 5% 1/10W
R793 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R794 1-216-833-11 METAL CHIP 10K 5% 1/10W
R795 1-216-848-11 METAL CHIP 180K 5% 1/10W
R796 1-216-851-11 METAL CHIP 330K 5% 1/10W
R797 1-216-841-11 METAL CHIP 47K 5% 1/10W
R798 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R799 1-216-818-11 METAL CHIP 560 5% 1/10W
R801 1-216-821-11 METAL CHIP 1K 5% 1/10W
R802 1-216-821-11 METAL CHIP 1K 5% 1/10W
R803 1-216-821-11 METAL CHIP 1K 5% 1/10W
R804 1-216-821-11 METAL CHIP 1K 5% 1/10W
R805 1-216-809-11 METAL CHIP 100 5% 1/10W
R806 1-216-833-11 METAL CHIP 10K 5% 1/10W
R807 1-216-848-11 METAL CHIP 180K 5% 1/10W
R808 1-216-864-11 SHORT CHIP 0
R809 1-216-837-11 METAL CHIP 22K 5% 1/10W
R810 1-216-797-11 METAL CHIP 10 5% 1/10W
R811 1-216-839-11 METAL CHIP 33K 5% 1/10W
R879 1-216-809-11 METAL CHIP 100 5% 1/10W
R880 1-216-809-11 METAL CHIP 100 5% 1/10W
R881 1-216-809-11 METAL CHIP 100 5% 1/10W
R882 1-216-801-11 METAL CHIP 22 5% 1/10W
< RELAY >
RY602 1-755-421-11 RELAY
< TERMINAL >
TB602 1-780-314-11 TERMINAL BOARD
(SPEAKERS IMPEDANS: USE 6 Ω)
< VIBRATOR >
X801 1-814-067-11 OSCILLATOR, CRYSTAL (32.768kHz)
*************************************************************
PANEL BOARD
************
2-649-178-01 PLATE, LIGHT GUIDE
2-649-179-01 SHEET (LCD)
2-665-175-01 SHEET (REFLECTOR)
< CAPACITOR >
C301 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C302 1-104-658-91 ELECT 100uF 20% 10V
C303 1-126-964-11 ELECT 10uF 20% 50V
C304 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C305 1-126-964-11 ELECT 10uF 20% 50V
C306 1-104-655-91 ELECT 470uF 20% 6.3V
C317 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C319 1-162-918-11 CERAMIC CHIP 18PF 5% 50V
C320 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C321 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C330 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C332 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C336 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C338 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C340 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C341 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C342 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C450 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C451 1-126-923-91 ELECT 220uF 20% 10V
C452 1-126-925-91 ELECT 470uF 20% 10V
C453 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C454 1-126-925-91 ELECT 470uF 20% 10V
C497 1-164-156-11 CERAMIC CHIP 0.1uF 25V
MAIN PANEL
