Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
39
HCD-EH10
CD
< RESISTOR/FERRITE BEAD >
R101 1-216-809-11 METAL CHIP 100 5% 1/10W
R102 1-216-809-11 METAL CHIP 100 5% 1/10W
R103 1-216-809-11 METAL CHIP 100 5% 1/10W
R104 1-216-809-11 METAL CHIP 100 5% 1/10W
R105 1-216-809-11 METAL CHIP 100 5% 1/10W
R107 1-216-809-11 METAL CHIP 100 5% 1/10W
R108 1-216-809-11 METAL CHIP 100 5% 1/10W
R109 1-216-809-11 METAL CHIP 100 5% 1/10W
R110 1-216-809-11 METAL CHIP 100 5% 1/10W
R111 1-216-809-11 METAL CHIP 100 5% 1/10W
R112 1-216-809-11 METAL CHIP 100 5% 1/10W
R113 1-216-809-11 METAL CHIP 100 5% 1/10W
R201 1-216-295-00 SHORT CHIP 0
R202 1-216-295-00 SHORT CHIP 0
R203 1-500-445-21 FERRITE, EMI (SMD) (2012)
R207 1-216-295-00 SHORT CHIP 0
R250 1-216-857-11 METAL CHIP 1M 5% 1/10W
R252 1-216-833-11 METAL CHIP 10K 5% 1/10W
R253 1-216-821-11 METAL CHIP 1K 5% 1/10W
R254 1-216-833-11 METAL CHIP 10K 5% 1/10W
R255 1-216-821-11 METAL CHIP 1K 5% 1/10W
R256 1-216-837-11 METAL CHIP 22K 5% 1/10W
R257 1-216-845-11 METAL CHIP 100K 5% 1/10W
R258 1-216-849-11 METAL CHIP 220K 5% 1/10W
R260 1-216-864-11 SHORT CHIP 0
R265 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R266 1-216-821-11 METAL CHIP 1K 5% 1/10W
R267 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R268 1-216-833-11 METAL CHIP 10K 5% 1/10W
R270 1-216-821-11 METAL CHIP 1K 5% 1/10W
R271 1-216-857-11 METAL CHIP 1M 5% 1/10W
R275 1-216-809-11 METAL CHIP 100 5% 1/10W
R276 1-216-841-11 METAL CHIP 47K 5% 1/10W
R277 1-216-809-11 METAL CHIP 100 5% 1/10W
R278 1-216-809-11 METAL CHIP 100 5% 1/10W
R280 1-216-864-11 SHORT CHIP 0
R291 1-216-809-11 METAL CHIP 100 5% 1/10W
R292 1-216-809-11 METAL CHIP 100 5% 1/10W
R321 1-216-789-11 METAL CHIP 2.2 5% 1/10W
R322 1-216-789-11 METAL CHIP 2.2 5% 1/10W
R323 1-216-864-11 SHORT CHIP 0
R324 1-216-845-11 METAL CHIP 100K 5% 1/10W
R401 1-216-295-00 SHORT CHIP 0
R421 1-216-864-11 SHORT CHIP 0
R423 1-216-833-11 METAL CHIP 10K 5% 1/10W
R451 1-216-837-11 METAL CHIP 22K 5% 1/10W
R452 1-216-833-11 METAL CHIP 10K 5% 1/10W
< VIBRATOR >
X201 1-795-101-21 VIBRATOR, CERAMIC (16.9344MHz)
************************************************************
A-1138-536-A MAIN BOARD, COMPLETE
********************
3-254-142-01 SCREW (B3), (+) BV TAPPING
< BAND PASS FILTER >
BPF801 1-236-711-41 FILTER, BAND PASS
< CAPACITOR >
C101 1-126-944-11 ELECT 3300uF 20% 25V
C105 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C109 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C110 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C111 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C112 1-126-943-11 ELECT 2200uF 20% 25V
C114 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C115 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C118 1-126-933-11 ELECT 100uF 20% 16V
C121 1-117-863-11 CERAMIC CHIP 0.47uF 10% 6.3V
C122 1-126-934-11 ELECT 220uF 20% 16V
C141 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C142 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C155 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C156 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C181 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C182 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C183 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C184 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C191 1-126-934-11 ELECT 220uF 20% 16V
C192 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C193 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C194 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C196 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C301 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C302 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C303 1-126-963-11 ELECT 4.7uF 20% 50V
C304 1-126-933-11 ELECT 100uF 20% 16V
C305 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C306 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C307 1-126-767-11 ELECT 1000uF 20% 16V
C308 1-126-767-11 ELECT 1000uF 20% 16V
C309 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C310 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C311 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C312 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C315 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C371 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C381 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C382 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C401 1-126-956-11 ELECT 0.1uF 20% 50V
C402 1-126-933-11 ELECT 100uF 20% 16V
C403 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C404 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C405 1-126-956-11 ELECT 0.1uF 20% 50V
C406 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C407 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C408 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C409 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C410 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C412 1-126-933-11 ELECT 100uF 20% 16V
C413 1-126-933-11 ELECT 100uF 20% 16V
MAIN
Ver. 1.3
Refer to the SUPPLEMENT-1 for the MAIN board of the except
AEP, UK, East European and Russian models.
