HCD-EH10
7
3-3. FRONT CABINET SECTION, TOP CABINET SECTION AND MAIN BOARD
3-4. MECHANICAL DECK (H-21SB)
8
two screws
(B2.6)
9
top cabinet section
q;
MAIN board
4
claw
slide switch (REC/PB) (SW501)
REC lever
Note: Adjust so that the space of slide switch (REC/PB) (SW501)
REC lever becames 2.3
±
0.4mm.
4
claw
claw
claw
5
front cabinet section
6
flexible flat (23 core) cable (FFC151)
(CNS104)
1
flexible flat (25 core) cable (FFC701)
(US, Canadian, Singapore, Taiwan, Korean
and Australian models) (CNS111),
flexible flat (27 core) cable (FFC702)
(AEP, UK, East European and Russian models) (CNS112
3
lead wire (PIN101)
7
lead wire (PIN102)
2
connector
(SW750)
2
two connectors
(CNP501, CNP502)
2.3
±
0.4mm
3
two screws
(BVTP2.6
×
8)
5
two screws
(BVTP2.6
×
8)
8
cable holder
6
7
two screws
9
mechanical deck
(H-21SB)
5
screw
(BVTP2.6
×
8)
1
screw
2
REC lever
4
PWB holder
To Next Page
