SERVICE MANUAL
HCD-EH10
Subject: Change of MAIN and PT-AC boards (Suffix-13)
US Model
Canadian Model
AEP Model
UK Model
E Model
Australian Model
9-879-855-81
Ver. 1.4 2006.03
1. NEW/FORMER DESCRIPTION
In this set, MAIN and PT-AC boards have been changed in the midway of
production.
Printed wiring boards and schematic diagrams of new type, and changed
parts list are described in this supplement-1.
Refer to original service manual for other information.
– MAIN Board (Component Side) – – PT-AC Board (Component Side) –
Former : 1-868-227-11, -12
New : 1-868-227-13
Former : 1-868-228-11, -12
New : 1-868-228-13
SUPPLEMENT-1
File this supplement with the service manual.
To Next Page
