Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
9
HCD-EH10
MAIN
< FILTER/CAPACITOR >
CF801 1-795-426-11 FILTER, CERAMIC
CF802 1-128-821-51 SERAMIC 1000PF 5% 50V
(US, CND, SP, TW, KR, AUS)
CF802 1-579-554-21 FILTER, CERAMIC (AEP, UK, EE, RU)
CF803 1-781-962-21 FILTER, CERAMIC
< CONNECTOR >
CNP501 1-815-445-11 PIN, CONNECTOR (PWB) 4P
CNP502 1-815-444-11 PIN, CONNECTOR (PWB) 3P
* CNP802 1-506-680-11 PLUG, CONNECTOR (2.5mm) 3P
CNS104 1-779-291-11 CONNECTOR, FFC (LIF (NON-ZIF)) 23P
CNS111 1-779-293-11 CONNECTOR, FFC (LIF (NON-ZIF)) 25P
(US, CND, SP, TW, KR, AUS)
CNS112 1-779-295-11 CONNECTOR, FFC (LIF (NON-ZIF)) 27P
(AEP, UK, EE, RU)
< DIODE >
D106 6-501-172-01 DIODE UDZW-TE17-8.2B
D107 8-719-046-07 DIODE 2A02M
D108 8-719-046-07 DIODE 2A02M
D109 8-719-046-07 DIODE 2A02M
D110 8-719-046-07 DIODE 2A02M
D111 6-500-522-01 DIODE 10EDB40-TA1B2
D112 8-719-904-02 DIODE 1N4002 (SP)
D113 6-500-522-01 DIODE 10EDB40-TA1B2
D114 8-719-904-02 DIODE 1N4002 (SP)
D131 6-500-334-01 DIODE MC2836-T112-1
D191 6-500-522-01 DIODE 10EDB40-TA1B2
D192 6-500-522-01 DIODE 10EDB40-TA1B2
D193 6-501-164-01 DIODE UDZW-TE17-3.9B
D371 6-500-335-01 DIODE MC2838-T112-1
D372 6-500-335-01 DIODE MC2838-T112-1
D802 6-501-369-01 DIODE SV230-TB-E
D803 6-501-369-01 DIODE SV230-TB-E
D812 8-719-062-51 DIODE 1PS226-115
D813 8-719-062-51 DIODE 1PS226-115
D815 8-719-062-51 DIODE 1PS226-115
D851 6-501-142-01 DIODE SVC347A-TL-E
< IC >
IC301 6-706-641-01 IC LA4631-E
IC401 6-702-895-01 IC BD3881FV
IC801 6-708-840-01 IC LV23003VA
IC861 6-708-918-01 IC PT2579SN (AEP, UK, EE, RU)
< JACK >
J101 1-780-314-11 TERMINAL BOARD (SPEAKERS)
J102 1-815-629-11 JACK (PHONES)
J105 1-566-822-51 JACK (AUDIO IN)
< JUMPER RESISTOR >
JR101 1-216-864-11 SHORT CHIP 0 (KR)
JR102 1-216-864-11 SHORT CHIP 0 (TW)
JR103 1-216-864-11 SHORT CHIP 0 (AUS)
JR104 1-216-864-11 SHORT CHIP 0 (SP)
JR105 1-216-864-11 SHORT CHIP 0 (US, CND)
JR106 1-216-864-11 SHORT CHIP 0 (AEP, UK, EE, RU)
JR401 1-216-864-11 SHORT CHIP 0
JR402 1-216-864-11 SHORT CHIP 0
JR403 1-216-864-11 SHORT CHIP 0
JR404 1-216-864-11 SHORT CHIP 0
JR801 1-216-864-11 SHORT CHIP 0
JR802 1-216-864-11 SHORT CHIP 0
JR803 1-216-864-11 SHORT CHIP 0
JR861 1-216-864-11 SHORT CHIP 0 (AEP, UK, EE, RU)
< RESISTOR >
JN137 1-249-385-11 CARBON 2.2 5% 1/4W
(US,CND)
< COIL >
L103 1-469-152-11 FERRITE, EMI (SMD) (2012)
L104 1-469-152-11 FERRITE, EMI (SMD) (2012)
L501 1-456-094-11 TRANSFORMER, BIAS OSCILLATION
L803 1-433-741-11 TRANSFORMER, IF
L804 1-457-163-11 COIL, AIR-CORE
L805 1-457-162-11 COIL, AIR-CORE
L806 1-457-168-11 COIL, DET
L851 1-457-161-11 COIL, AM ANTENNA
L852 1-456-596-11 COIL, MW OSC
< CONNECTOR >
* PIN101 1-564-187-00 PIN, CONNECTOR (AEP, UK, EE, RU, KR)
* PIN102 1-564-187-00 PIN, CONNECTOR (AEP, UK, EE, RU, KR)
< TRANSISTOR >
Q101 8-729-141-83 TRANSISTOR 2SB1094-LK
Q102 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q103 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q121 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q122 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q123 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q191 8-729-036-86 TRANSISTOR KTC3203Y-AT
Q192 8-729-036-86 TRANSISTOR KTC3203Y-AT
Q193 8-729-600-22 TRANSISTOR 2SA1235-F
Q351 6-550-843-01 FET 2SJ599-Z-E2-AZ
Q352 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q371 8-729-600-22 TRANSISTOR 2SA1235-F
Q372 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q507 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q801 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q802 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q803 6-550-304-01 TRANSISTOR 2SC5477-T122-1
Q861 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q862 8-729-120-28 TRANSISTOR 2SC1623-L5L6
< RESISTOR >
R101 1-216-833-11 METAL CHIP 10K 5% 1/10W
R102 1-216-809-11 METAL CHIP 100 5% 1/10W
R103 1-216-841-11 METAL CHIP 47K 5% 1/10W
R104 1-216-845-11 METAL CHIP 100K 5% 1/10W
R105 1-216-845-11 METAL CHIP 100K 5% 1/10W
R106 1-216-837-11 METAL CHIP 22K 5% 1/10W
