95
HCD-FLX5D/FLX7D
Pin No. Pin Name I/O Description
81 to 84 MD16 to MD19 I/O Two-way data bus with the SD-RAM
85 GND25 — Ground terminal
86 MDQM2 O Write mask signal output to the SD-RAM
87 VDD25 — Power supply terminal (+3.3V)
88 to 95 MD20 to MD27 I/O Two-way data bus with the SD-RAM
96 GND25 — Ground terminal
97 MDQM3 O Write mask signal output to the SD-RAM
98 VDD25 — Power supply terminal (+3.3V)
99 to 102 MD28 to MD31 I/O Two-way data bus with the SD-RAM
103 GND25 — Ground terminal
104 VDD25 — Power supply terminal (+3.3V)
105 VCLK O Not used
106 I2C_CTRL O Not used
107 VS O Wide control signal output terminal
108 I/P SW O Interlace/progressive selection signal output terminal Not used
109 GPIO1 (5) O Not used
110 GPIO1 (4) O Not used
111 VDDP — Power supply terminal (+3.3V)
112 GNDP — Ground terminal
113 GPIO1 (3) O Not used
114 GPIO1 (2) O Not used
115 GPIO1 (1) O Not used
116 HIRQ2 I Busy signal input from the EEPROM
117 VDAC_4B — Ground terminal
118 VDAC_VDD4 — Power supply terminal (+3.3V)
119 VDAC_4 O Component video signal output to the video amplifier
120 VDAC_3B — Ground terminal
121 VDAC_VDD3 — Power supply terminal (+3.3V)
122 VDAC_3 O Component video signal output to the video amplifier
123 VDAC_2B — Ground terminal
124 VDAC_VDD2 — Power supply terminal (+3.3V)
125 VDAC_2 O Y (luminance) video signal output to the video amplifier
126 VDAC_1B — Ground terminal
127 VDAC_VDD1 — Power supply terminal (+3.3V)
128 VDAC_1 O C (chroma) video signal output to the video amplifier
129 VDAC_0B — Ground terminal
130 VDAC_VDD0 — Power supply terminal (+3.3V)
131 VDAC_0 O Video signal output to the video amplifier
132 VDAC_DVSS — Ground terminal
133 VDAC_DVDD — Power supply terminal (+3.3V)
134 VDAC_REFVDD — Power supply terminal
135 VDAC_REF I Power supply terminal (+3.3V)
136 VDAC_REFVSS — Ground terminal
137 XVSS — Ground terminal
138 XOUT O Clock signal output terminal Not used
