Sony HCD-FR1 - Page 67

67
HCD-FR1/FR8/FR9
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
IO
R109 1-216-821-11 METAL CHIP 1K 5% 1/10W
R110 1-216-813-11 METAL CHIP 220 5% 1/10W
R111 1-216-813-11 METAL CHIP 220 5% 1/10W
R112 1-218-867-11 METAL CHIP 6.8K 5% 1/10W
R113 1-218-867-11 METAL CHIP 6.8K 5% 1/10W
R114 1-216-839-11 METAL CHIP 33K 5% 1/10W
R115 1-216-839-11 METAL CHIP 33K 5% 1/10W
R116 1-216-839-11 METAL CHIP 33K 5% 1/10W
R117 1-216-839-11 METAL CHIP 33K 5% 1/10W
R118 1-216-839-11 METAL CHIP 33K 5% 1/10W
R119 1-216-839-11 METAL CHIP 33K 5% 1/10W
R128 1-216-864-11 SHORT CHIP 0
R203 1-216-821-11 METAL CHIP 1K 5% 1/10W
R204 1-216-821-11 METAL CHIP 1K 5% 1/10W
R224 1-216-833-11 METAL CHIP 10K 5% 1/10W
R225 1-218-285-11 METAL CHIP 75 5% 1/10W
R226 1-218-285-11 METAL CHIP 75 5% 1/10W
R227 1-218-285-11 METAL CHIP 75 5% 1/10W
R228 1-218-285-11 METAL CHIP 75 5% 1/10W
R229 1-218-285-11 METAL CHIP 75 5% 1/10W
R230 1-218-285-11 METAL CHIP 75 5% 1/10W
R234 1-216-833-11 METAL CHIP 10K 5% 1/10W
R601 1-216-833-11 METAL CHIP 10K 5% 1/10W
R602 1-216-833-11 METAL CHIP 10K 5% 1/10W
R603 1-216-809-11 METAL CHIP 100 5% 1/10W
R604 1-216-809-11 METAL CHIP 100 5% 1/10W
R605 1-216-809-11 METAL CHIP 100 5% 1/10W
R607 1-216-821-11 METAL CHIP 1K 5% 1/10W
R608 1-216-821-11 METAL CHIP 1K 5% 1/10W
R609 1-216-833-11 METAL CHIP 10K 5% 1/10W
R610 1-216-833-11 METAL CHIP 10K 5% 1/10W
R621 1-216-833-11 METAL CHIP 10K 5% 1/10W
R622 1-216-833-11 METAL CHIP 10K 5% 1/10W
R623 1-216-833-11 METAL CHIP 10K 5% 1/10W
R624 1-216-833-11 METAL CHIP 10K 5% 1/10W
R625 1-216-833-11 METAL CHIP 10K 5% 1/10W
R626 1-216-833-11 METAL CHIP 10K 5% 1/10W
R627 1-216-833-11 METAL CHIP 10K 5% 1/10W
R628 1-216-833-11 METAL CHIP 10K 5% 1/10W
R629 1-216-841-11 METAL CHIP 47K 5% 1/10W
R630 1-216-841-11 METAL CHIP 47K 5% 1/10W
R631 1-216-841-11 METAL CHIP 47K 5% 1/10W
R632 1-216-841-11 METAL CHIP 47K 5% 1/10W
R633 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R634 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R635 1-218-867-11 METAL CHIP 6.8K 5% 1/10W
R636 1-218-867-11 METAL CHIP 6.8K 5% 1/10W
R645 1-216-809-11 METAL CHIP 100 5% 1/10W
R647 1-216-833-11 METAL CHIP 10K 5% 1/10W
R648 1-216-833-11 METAL CHIP 10K 5% 1/10W
R649 1-216-839-11 METAL CHIP 33K 5% 1/10W
R650 1-216-821-11 METAL CHIP 1K 5% 1/10W
R651 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R652 1-216-833-11 METAL CHIP 10K 5% 1/10W
R653 1-216-833-11 METAL CHIP 10K 5% 1/10W
R654 1-216-813-11 METAL CHIP 220 5% 1/10W
R655 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R656 1-216-841-11 METAL CHIP 47K 5% 1/10W
R657 1-216-833-11 METAL CHIP 10K 5% 1/10W
R659 1-216-821-11 METAL CHIP 1K 5% 1/10W
R661 1-216-813-11 METAL CHIP 220 5% 1/10W
R664 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
************************************************************
LF BOARD
********
< CAPACITOR >
0C903 1-117-916-51 FILM 0.22uF 10% 275V
< CONNECTOR >
CN900 1-564-321-00 PIN, CONNECTOR (3.96mm PITCH) 2P
* CN901 1-564-321-21 PIN, CONNECTOR (3.96mm PITCH) 2P
< LINE FILTER >
0LF901 1-456-081-21 COIL, LINE FILTER
************************************************************
MODE MOTOR BOARD
******************
************************************************************
PW KEY BOARD
*************
< CAPACITOR >
C811 1-164-360-11 CERAMIC CHIP 0.1uF 16V
< CONNECTOR >
* CN805 1-568-941-11 PIN, CONNECTOR 3P
< DIODE >
D802 6-500-817-01 DIODE (LED) SML-512UWT86 (?/1 )
< RESISTOR >
R809 1-216-864-11 SHORT CHIP 0
< SWITCH >
✩ S800 1-771-884-31 SWITCH, TACTILE (?/1)
************************************************************
A-4728-700-A RELAY BOARD, COMPLETE
**********************
< CAPACITOR >
C711 1-126-795-11 ELECT 10uF 20% 50V
C751 1-164-159-21 CERAMIC 0.1uF 50V
C752 1-164-159-21 CERAMIC 0.1uF 50V
C753 1-164-159-21 CERAMIC 0.1uF 50V
C754 1-164-159-21 CERAMIC 0.1uF 50V
LF MODE MOTOR PW KEY RELAY
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
✩ The Part numbers of Ref.No. S800 is changed with a suffix of the
PW KEY board. Please refer to SUPPLEMENT-3 of this manual at
the time of replacement.
Ver. 1.7
