68
HCD-FR1/FR8/FR9
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
RF
C755 1-164-159-21 CERAMIC 0.1uF 50V
C756 1-164-159-21 CERAMIC 0.1uF 50V
C758 1-164-159-21 CERAMIC 0.1uF 50V
C761 1-162-306-11 CERAMIC 0.01uF 30% 16V
C762 1-164-159-21 CERAMIC 0.1uF 50V
C763 1-164-159-21 CERAMIC 0.1uF 50V
C764 1-164-159-21 CERAMIC 0.1uF 50V
C765 1-164-159-21 CERAMIC 0.1uF 50V
C766 1-164-159-21 CERAMIC 0.1uF 50V
C767 1-164-159-21 CERAMIC 0.1uF 50V
C768 1-164-159-21 CERAMIC 0.1uF 50V
C769 1-164-159-21 CERAMIC 0.1uF 50V
C771 1-162-306-11 CERAMIC 0.01uF 30% 16V
C781 1-162-306-11 CERAMIC 0.01uF 30% 16V
< CONNECTOR >
CN701 1-779-565-21 CONNECTOR, FFC (LIF (NON-ZIF)) 28P
CN702 1-785-329-11 PIN, CONNECTOR (LIGHT ANGLE) 3P
CN703 1-785-328-11 PIN, CONNECTOR (LIGHT ANGLE) 2P
CN704 1-785-328-21 PIN, CONNECTOR (LIGHT ANGLE) 2P
CN710 1-568-945-11 PIN, CONNECTOR 7P
< DIODE >
D701 8-719-921-40 DIODE MTZJ-T-77-4.7B
D711 8-719-921-42 DIODE MTZJ-T-77-5.1A
D721 8-719-982-03 DIODE MTZJ-T-77-3.6A
< IC >
IC701 8-759-598-69 IC BA6956AN
IC711 8-759-598-69 IC BA6956AN
IC721 8-759-598-69 IC BA6956AN
< TRANSISTOR >
Q731 8-729-029-66 TRANSISTOR RT1N141S-TP
< RESISTOR >
R701 1-249-415-11 CARBON 680 5% 1/4W
R702 1-247-807-31 CARBON 100 5% 1/4W
R711 1-249-415-11 CARBON 680 5% 1/4W
R712 1-247-807-31 CARBON 100 5% 1/4W
R721 1-249-415-11 CARBON 680 5% 1/4W
R722 1-247-807-31 CARBON 100 5% 1/4W
R731 1-249-407-11 CARBON 150 5% 1/4W
R732 1-249-417-11 CARBON 1K 5% 1/4W
R733 1-249-429-11 CARBON 10K 5% 1/4W
R734 1-249-431-11 CARBON 15K 5% 1/4W
************************************************************
A-4728-690-A RF BOARD, COMPLETE
*******************
< CAPACITOR >
C001 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C002 1-124-779-00 ELECT CHIP 10uF 20% 16V
C003 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C004 1-124-779-00 ELECT CHIP 10uF 20% 16V
C005 1-128-993-21 ELECT CHIP 22uF 20% 10V
C006 1-128-993-21 ELECT CHIP 22uF 20% 10V
C008 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C009 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C010 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
C011 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
C012 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C013 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C014 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C015 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C016 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C017 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C018 1-164-172-11 CERAMIC CHIP 0.0056uF 10% 25V
C019 1-164-172-11 CERAMIC CHIP 0.0056uF 10% 25V
C020 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C021 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C022 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C023 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C024 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C025 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C026 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C027 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C028 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C029 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C030 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C031 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
C032 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C033 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C034 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C035 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C036 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C037 1-162-959-11 CERAMIC CHIP 330PF 5% 50V
C038 1-164-677-11 CERAMIC CHIP 0.033uF 10% 16V
C039 1-164-677-11 CERAMIC CHIP 0.033uF 10% 16V
C040 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C041 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C042 1-164-218-11 CERAMIC CHIP 180PF 0.25PF 50V
C049 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C050 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C051 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C052 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
< CONNECTOR >
CN001 1-815-031-11 CONNECTOR, FFC/FPC (ZIF) 24P
CN002 1-784-836-21 CONNECTOR, FFC (LIF (NON-ZIF)) 29P
CN003 1-784-861-21 CONNECTOR, FFC (LIF (NON-ZIF)) 9P
< DIODE >
D001 8-719-988-61 DIODE 1SS355TE-17
D002 8-719-988-61 DIODE 1SS355TE-17
< IC >
IC001 6-703-922-01 IC SP3723CAF0PM
IC003 6-703-921-01 IC TL343IDBVR
< COIL >
L001 1-412-031-11 INDUCTOR CHIP 47uH
L002 1-412-031-11 INDUCTOR CHIP 47uH
RELAY
Ver. 1.4
