97
HCD-FX888K
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R965 1-216-864-11 SHORT CHIP 0
< COMPOSITION CIRCUIT BLOCK >
RB501 1-233-576-11 RES, CHIP NETWORK 100 (3216)
RB502 1-233-576-11 RES, CHIP NETWORK 100 (3216)
RB503 1-233-576-11 RES, CHIP NETWORK 100 (3216)
RB504 1-233-576-11 RES, CHIP NETWORK 100 (3216)
RB505 1-233-576-11 RES, CHIP NETWORK 100 (3216)
RB506 1-233-576-11 RES, CHIP NETWORK 100 (3216)
RB507 1-233-576-11 RES, CHIP NETWORK 100 (3216)
RB901 1-236-908-11 RES, CHIP NETWORK 10K (3216)
RB902 1-236-908-11 RES, CHIP NETWORK 10K (3216)
RB903 1-236-908-11 RES, CHIP NETWORK 10K (3216)
RB904 1-236-908-11 RES, CHIP NETWORK 10K (3216)
RB905 1-233-411-11 RES, CHIP NETWORK 220 (3216)
RB906 1-233-411-11 RES, CHIP NETWORK 220 (3216)
RB907 1-233-411-11 RES, CHIP NETWORK 220 (3216)
RB908 1-233-411-11 RES, CHIP NETWORK 220 (3216)
< TRANSFORMER >
0 T901 1-443-651-11 TRANSFORMER, CONVERTER
0 T902 1-443-650-11 TRANSFORMER, CONVERTER
< THERMISTOR >
0 TH901 1-805-841-21 THERMISTOR, NTC 3.0 (E32)
0 TH901 1-805-842-21 THERMISTOR, NTC 6.0 (E3, SP, AUS)
< VARISTOR >
0 VDR901 1-805-482-11 VARISTOR
< VIBRATOR >
X450 1-795-660-21 QUARTZ CRYSTAL UNIT (49.152MHz)
X500 1-795-843-11 VIBRATOR, CRYSTAL (12.288MHz)
X501 1-813-325-11 VIBRATOR, CRYSTAL (13.90MHz)
X502 1-795-058-21 VIBRATOR, CERAMIC (5MHz)
************************************************************
MIC BOARD
*********
< CAPACITOR >
C601 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C602 1-126-933-11 ELECT 100uF 20% 16V
C603 1-126-933-11 ELECT 100uF 20% 16V
C604 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C620 1-124-464-11 ELECT 0.22uF 20% 50V
C651 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C652 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C659 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C660 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C671 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C672 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C673 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C862 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C863 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C866 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C870 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
< CONNECTOR >
CN602 1-564-722-11 PIN, CONNECTOR (SMALL TYPE) 6P
< DIODE >
D611 8-719-988-61 DIODE 1SS355TE-17
D612 8-719-988-61 DIODE 1SS355TE-17
D821 8-719-988-61 DIODE 1SS355TE-17
D822 8-719-988-61 DIODE 1SS355TE-17
< EARTH TERMINAL >
EP601 1-537-770-21 TERMINAL BOARD, GROUND
EP801 1-537-770-21 TERMINAL BOARD, GROUND
< FERRITE BEAD >
FB601 1-469-144-21 FERRITE, EMI (SMD) (2012)
FB811 1-469-144-21 FERRITE, EMI (SMD) (2012)
FB812 1-469-144-21 FERRITE, EMI (SMD) (2012)
FB813 1-469-144-21 FERRITE, EMI (SMD) (2012)
FB814 1-216-295-91 SHORT CHIP 0
< IC >
IC604 8-759-710-97 IC NJM4565M-D
< JACK >
J603 1-770-226-11 JACK (LARGE TYPE) (MIC)
J801 1-566-891-21 JACK (PHONES)
< COIL >
L811 1-216-864-11 SHORT CHIP 0
L812 1-469-144-21 FERRITE, EMI (SMD) (2012)
L813 1-216-864-11 SHORT CHIP 0
L814 1-469-144-21 FERRITE, EMI (SMD) (2012)
< TRANSISTOR >
Q806 6-550-889-01 TRANSISTOR 2SC5938-T112-1B
Q807 6-550-889-01 TRANSISTOR 2SC5938-T112-1B
Q808 6-550-889-01 TRANSISTOR 2SC5938-T112-1B
Q809 6-550-889-01 TRANSISTOR 2SC5938-T112-1B
< RESISTOR >
R632 1-216-833-11 METAL CHIP 10K 5% 1/10W
R639 1-216-845-11 METAL CHIP 100K 5% 1/10W
R640 1-216-821-11 METAL CHIP 1K 5% 1/10W
R642 1-216-864-11 SHORT CHIP 0
R644 1-216-833-11 METAL CHIP 10K 5% 1/10W
R645 1-216-835-11 METAL CHIP 15K 5% 1/10W
R647 1-216-833-11 METAL CHIP 10K 5% 1/10W
R657 1-216-821-11 METAL CHIP 1K 5% 1/10W
R861 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R862 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R863 1-216-801-11 METAL CHIP 22 5% 1/10W
R864 1-216-801-11 METAL CHIP 22 5% 1/10W
R865 1-216-805-11 METAL CHIP 47 5% 1/10W
R866 1-216-805-11 METAL CHIP 47 5% 1/10W
R867 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R868 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R869 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
MAIN MIC
