8
HCD-GNX60/GNX70/GX9900
Note: Follow the disassembly procedure in the numerical order given.
3-2. SIDE PANEL, TOP CASE
3-3. LOADING PANEL ASSY
1
screw (case 3 TP2)
(3X8)
2
two screws
(case 3 TP2)
(3X12)
3
two screws
(+BVTP 3X10
4
5
PANEL (SIDE-L)
6
screw
(case 3 TP2)
(3X8)
7
two screws
(case 3 TP2)
(3X12)
8
two screws
(+BVTP 3X10)
9
0
PANEL (SIDE-R)
qa
two screws
(+BVTP 3X10)
qs
qd
CASE (TOP)
CD mechanismdeck (CDM74-F1BD81)
1
Tu rn the pulley to the arrow direction.
Front side
Pulley
2
Pull out disc tray
3
4
loading panel assy
