Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-GNX60/GNX70/GX9900
DRIVER
MAINJOG
< IC >
IC701 8-759-598-69 IC BA6956AN
IC712 8-759-598-69 IC BA6956AN
< TRANSISTOR >
Q731 8-729-029-66 TRANSISTOR DTC114ESA
< RESISTOR >
R701 1-249-413-11 CARBON 470 5% 1/4W
R702 1-247-807-31 CARBON 100 5% 1/4W
R711 1-247-831-91 CARBON 1K 5% 1/4W
R712 1-247-847-91 CARBON 4.7K 5% 1/4W
R713 1-247-863-91 CARBON 22K 5% 1/4W
R721 1-247-847-91 CARBON 4.7K 5% 1/4W
R722 1-247-847-91 CARBON 4.7K 5% 1/4W
R723 1-247-847-91 CARBON 4.7K 5% 1/4W
R731 1-247-807-31 CARBON 100 5% 1/4W
R732 1-249-429-11 CARBON 10K 5% 1/4W
R733 1-247-831-91 CARBON 1K 5% 1/4W
R734 1-249-430-11 CARBON 12K 5% 1/4W
R735 1-247-807-31 CARBON 100 5% 1/4W
R751 1-247-847-91 CARBON 4.7K 5% 1/4W
*************************************************************
JOG BOARD
*********
< CAPACITOR >
C1150 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
< CONNECTOR >
* CNS903 1-562-573-11 SOCKET, CONNECTOR 8P
< DIODE >
D919 8-719-071-44 DIODE SELS5223C-TP15 (VOL 2)
D920 8-719-071-44 DIODE SELS5223C-TP15 (VOL 3)
D921 8-719-071-44 DIODE SELS5223C-TP15 (VOL 4)
D922 8-719-071-44 DIODE SELS5223C-TP15 (VOL 5)
D923 8-719-071-44 DIODE SELS5223C-TP15 (VOL 6)
D924 8-719-071-44 DIODE SELS5223C-TP15 (VOL 1)
< JUMPER RESISTOR >
JR904 1-216-296-11 SHORT CHIP 0
JR905 1-216-864-11 SHORT CHIP 0
< TRANSISTOR >
Q911 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q912 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q913 8-729-027-43 TRANSISTOR DTC114EKA-T146
< RESISTOR >
R1138 1-216-820-11 METAL CHIP 820 5% 1/10W
R1139 1-216-820-11 METAL CHIP 820 5% 1/10W
R1140 1-216-820-11 METAL CHIP 820 5% 1/10W
R1144 1-216-820-11 METAL CHIP 820 5% 1/10W
R1145 1-216-820-11 METAL CHIP 820 5% 1/10W
R1146 1-216-820-11 METAL CHIP 820 5% 1/10W
R1156 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1157 1-216-820-11 METAL CHIP 820 5% 1/10W
R1158 1-216-820-11 METAL CHIP 820 5% 1/10W
R1159 1-216-820-11 METAL CHIP 820 5% 1/10W
R1190 1-216-809-11 METAL CHIP 100 5% 1/10W
R1191 1-216-809-11 METAL CHIP 100 5% 1/10W
R1192 1-216-809-11 METAL CHIP 100 5% 1/10W
< SWITCH >
S1161 1-479-203-11 ENCODER (ROTARY) (OPERATION DIAL)
*************************************************************
A-1089-297-A MAIN BOARD, COMPLETE (GNX60: E2)
A-1089-299-A MAIN BOARD, COMPLETE (GNX70: E2)
A-1089-301-A MAIN BOARD, COMPLETE (GX9900)
A-1105-022-A MAIN BOARD, COMPLETE (GNX60: E3)
A-1105-023-A MAIN BOARD, COMPLETE (GNX60: E51)
A-1105-024-A MAIN BOARD, COMPLETE (AR)
A-1105-025-A MAIN BOARD, COMPLETE (GNX60: AUS)
A-1105-026-A MAIN BOARD, COMPLETE (GNX70: E3)
A-1105-027-A MAIN BOARD, COMPLETE (GNX70: E51)
A-1105-028-A MAIN BOARD, COMPLETE (GNX70: AUS)
*********************
7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3
< CAPACITOR >
C100 1-104-658-91 ELECT 100uF 20% 10V
C102 1-126-964-11 ELECT 10uF 20% 50V
C103 1-126-964-11 ELECT 10uF 20% 50V
C104 1-126-964-11 ELECT 10uF 20% 50V
C105 1-126-964-11 ELECT 10uF 20% 50V
C106 1-136-157-00 FILM 0.022uF 5% 50V
C107 1-136-157-00 FILM 0.022uF 5% 50V
C108 1-136-159-00 FILM 0.033uF 5% 50V
C109 1-126-960-11 ELECT 1uF 20% 50V
C110 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C111 1-126-964-11 ELECT 10uF 20% 50V
C112 1-136-170-00 FILM 0.27uF 5% 50V
C113 1-136-170-00 FILM 0.27uF 5% 50V
C114 1-126-964-11 ELECT 10uF 20% 50V
C115 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C116 1-126-923-91 ELECT 220uF 20% 10V
C121 1-162-957-11 CERAMIC CHIP 220PF 5% 50V
C122 1-162-957-11 CERAMIC CHIP 220PF 5% 50V
C130 1-126-964-11 ELECT 10uF 20% 50V
C131 1-126-959-11 ELECT 0.47uF 20% 50V
C140 1-136-495-11 FILM 0.068uF 5% 50V
C149 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C150 1-126-964-11 ELECT 10uF 20% 50V
C152 1-126-964-11 ELECT 10uF 20% 50V
C153 1-126-964-11 ELECT 10uF 20% 50V
C154 1-126-964-11 ELECT 10uF 20% 50V
C155 1-126-964-11 ELECT 10uF 20% 50V
C156 1-136-157-00 FILM 0.022uF 5% 50V
C157 1-136-157-00 FILM 0.022uF 5% 50V
C158 1-136-159-00 FILM 0.033uF 5% 50V
C159 1-126-960-11 ELECT 1uF 20% 50V
