Sony HCD-GNX700 - Component Lists for Main and MIC Boards

72
HCD-GNX700/GNX800
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
MAIN
< CONNECTOR >
CNS903 1-562-573-31 SOCKET, CONNECTOR 8P
< DIODE >
D919 6-500-809-01 DIODE SELU5223C-STP15 (VOL 1)
D920 6-500-809-01 DIODE SELU5223C-STP15 (VOL 2)
D921 6-500-809-01 DIODE SELU5223C-STP15 (VOL 3)
D922 6-500-809-01 DIODE SELU5223C-STP15 (VOL 4)
D923 6-500-809-01 DIODE SELU5223C-STP15 (VOL 5)
D924 6-500-809-01 DIODE SELU5223C-STP15 (VOL 6)
D925 6-500-809-01 DIODE SELU5223C-STP15 (VOL 7)
D926 6-500-809-01 DIODE SELU5223C-STP15 (VOL 8)
< JUMPER RESISTOR >
JR1 1-216-864-11 SHORT CHIP 0
JR2 1-216-864-11 SHORT CHIP 0
JR3 1-216-864-11 SHORT CHIP 0
JR4 1-216-864-11 SHORT CHIP 0
JR5 1-216-864-11 SHORT CHIP 0
JR922 1-216-864-11 SHORT CHIP 0
JR1096 1-216-864-11 SHORT CHIP 0
< TRANSISTOR >
Q911 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q912 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q913 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q915 8-729-027-43 TRANSISTOR DTC114EKA-T146
< RESISTOR >
R1040 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1144 1-216-820-11 METAL CHIP 820 5% 1/10W
R1145 1-216-820-11 METAL CHIP 820 5% 1/10W
R1146 1-216-820-11 METAL CHIP 820 5% 1/10W
R1149 1-216-820-11 METAL CHIP 820 5% 1/10W
R1150 1-216-820-11 METAL CHIP 820 5% 1/10W
R1151 1-216-820-11 METAL CHIP 820 5% 1/10W
R1153 1-216-820-11 METAL CHIP 820 5% 1/10W
R1154 1-216-820-11 METAL CHIP 820 5% 1/10W
R1155 1-216-820-11 METAL CHIP 820 5% 1/10W
R1157 1-216-820-11 METAL CHIP 820 5% 1/10W
R1158 1-216-820-11 METAL CHIP 820 5% 1/10W
R1159 1-216-820-11 METAL CHIP 820 5% 1/10W
R1161 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1162 1-216-809-11 METAL CHIP 100 5% 1/10W
R1163 1-216-809-11 METAL CHIP 100 5% 1/10W
R1164 1-216-809-11 METAL CHIP 100 5% 1/10W
R1165 1-216-809-11 METAL CHIP 100 5% 1/10W
< SWITCH >
S1161 1-479-203-11 ENCODER (ROTARY) (OPERATION DIAL)
************************************************************
A-1156-216-A MAIN BOARD, COMPLETE (GNX800: E2, E51)
A-1156-472-A MAIN BOARD, COMPLETE (GNX700: E2, E51)
A-1174-067-A MAIN BOARD, COMPLETE (GNX800: E3)
A-1174-073-A MAIN BOARD, COMPLETE (AR)
A-1178-441-A MAIN BOARD, COMPLETE (AUS)
A-1178-442-A MAIN BOARD, COMPLETE (GNX700: E3)
*********************
7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3
< CAPACITOR >
C100 1-104-658-91 ELECT 100uF 20% 10V
C102 1-126-964-11 ELECT 10uF 20% 50V
C103 1-126-964-11 ELECT 10uF 20% 50V
C104 1-126-964-11 ELECT 10uF 20% 50V
C105 1-126-964-11 ELECT 10uF 20% 50V
C106 1-130-487-00 MYLAR 0.022uF 5% 50V
C107 1-130-487-00 MYLAR 0.022uF 5% 50V
C108 1-130-489-00 MYLAR 0.033uF 5% 50V
C109 1-126-960-11 ELECT 1uF 20% 50V
C110 1-162-969-11 CERAMIC CHIP 0.0068uF 10% 25V
(GNX700)
C110 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(GNX800)
C111 1-126-964-11 ELECT 10uF 20% 50V
C112 1-137-190-91 FILM 0.22uF 5% 50V
(GNX800)
C112 1-136-170-00 FILM 0.27uF 5% 50V
(GNX700)
C113 1-136-170-00 FILM 0.27uF 5% 50V
C115 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C116 1-126-176-11 ELECT 220uF 20% 10V
C130 1-126-964-11 ELECT 10uF 20% 50V
C131 1-126-959-11 ELECT 0.47uF 20% 50V
C140 1-130-493-00 MYLAR 0.068uF 5% 50V
C149 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C150 1-126-964-11 ELECT 10uF 20% 50V
C152 1-126-964-11 ELECT 10uF 20% 50V
C153 1-126-964-11 ELECT 10uF 20% 50V
C154 1-126-964-11 ELECT 10uF 20% 50V
C155 1-126-964-11 ELECT 10uF 20% 50V
C156 1-130-487-00 MYLAR 0.022uF 5% 50V
C157 1-130-487-00 MYLAR 0.022uF 5% 50V
C158 1-130-489-00 MYLAR 0.033uF 5% 50V
C159 1-126-960-11 ELECT 1uF 20% 50V
C160 1-162-969-11 CERAMIC CHIP 0.0068uF 10% 25V
(GNX700)
C160 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(GNX800)
C161 1-126-964-11 ELECT 10uF 20% 50V
C162 1-137-190-91 FILM 0.22uF 5% 50V
(GNX800)
C162 1-136-170-00 FILM 0.27uF 5% 50V
(GNX700)
C163 1-136-170-00 FILM 0.27uF 5% 50V
C180 1-126-963-11 ELECT 4.7uF 20% 50V
C181 1-126-963-11 ELECT 4.7uF 20% 50V
C202 1-126-964-11 ELECT 10uF 20% 50V
C203 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C204 1-126-923-91 ELECT 220uF 20% 10V
C205 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C206 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C207 1-126-960-11 ELECT 1uF 20% 50V
C210 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C211 1-104-658-91 ELECT 100uF 20% 10V
C220 1-136-497-81 FILM 0.1uF 5% 50V
C221 1-136-497-81 FILM 0.1uF 5% 50V
JOG
