Sony HCD-GNX700 - Component Lists for SENSOR and SURROUND Boards

83
HCD-GNX700/GNX800
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
1-687-132-12 SENSOR BOARD
*************
< CONNECTOR >
CN731 1-785-329-21 PIN, CONNECTOR (LIGHT ANGLE) 3P
< IC >
IC731 6-600-022-01 IC RPI-576
************************************************************
A-1156-249-A SURROUND BOARD, COMPLETE (GNX800)
A-1156-252-A SURROUND BOARD, COMPLETE (GNX700)
**************************
< CAPACITOR >
C800 1-126-963-11 ELECT 4.7uF 20% 50V
C801 1-100-717-91 CERAMIC CHIP 1uF 16V
C802 1-104-658-91 ELECT 100uF 20% 10V
C803 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C804 1-131-992-91 CERAMIC CHIP 100000PF 35V
C805 1-131-992-91 CERAMIC CHIP 100000PF 35V
C806 1-126-961-11 ELECT 2.2uF 20% 50V
C807 1-100-717-91 CERAMIC CHIP 1uF 16V
C808 1-131-749-11 CERAMIC CHIP 8.2PF 50V
(GNX700)
C820 1-126-964-11 ELECT 10uF 20% 50V
C825 1-126-968-11 ELECT 100uF 20% 50V
C826 1-126-968-11 ELECT 100uF 20% 50V
C838 1-136-495-11 FILM 0.068uF 5% 50V
C839 1-136-495-11 FILM 0.068uF 5% 50V
C843 1-126-963-11 ELECT 4.7uF 20% 50V
C850 1-126-963-11 ELECT 4.7uF 20% 50V
C851 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C852 1-104-658-91 ELECT 100uF 20% 10V
C853 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C858 1-131-749-11 CERAMIC CHIP 8.2PF 50V
(GNX700)
C888 1-136-495-11 FILM 0.068uF 5% 50V
C889 1-136-495-11 FILM 0.068uF 5% 50V
< CONNECTOR >
CN700 1-784-041-41 CONNECTOR, BOARD TO BOARD 9P
< DIODE >
D800 6-501-193-01 DIODE 1SS355WTE-17
D810 6-501-193-01 DIODE 1SS355WTE-17
D811 6-501-193-01 DIODE 1SS355WTE-17
D812 6-501-193-01 DIODE 1SS355WTE-17
D850 6-501-193-01 DIODE 1SS355WTE-17
< IC >
IC800 6-705-845-01 IC STK403-090 (GNX700)
IC800 6-705-853-01 IC STK403-120 (GNX800)
< TRANSISTOR >
Q800 8-729-924-99 TRANSISTOR 2SC3722K-E
Q810 8-729-023-22 TRANSISTOR 2SD2114K
Q812 8-729-924-99 TRANSISTOR 2SC3722K-E
Q814 8-729-230-49 TRANSISTOR 2SC2712-YG
Q815 8-729-230-49 TRANSISTOR 2SC2712-YG
Q850 8-729-924-99 TRANSISTOR 2SC3722K-E
< RESISTOR >
R800 1-216-821-11 METAL CHIP 1K 5% 1/10W
R801 1-216-841-11 METAL CHIP 47K 5% 1/10W
R802 1-216-820-11 METAL CHIP 820 5% 1/10W
(GNX700)
R802 1-218-457-11 METAL CHIP 910 5% 1/10W
(GNX800)
R803 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
0 R804 1-217-637-00 FUSIBLE 1 5% 1/4W
0 R805 1-217-637-00 FUSIBLE 1 5% 1/4W
R806 1-216-821-11 METAL CHIP 1K 5% 1/10W
R807 1-216-841-11 METAL CHIP 47K 5% 1/10W
R808 1-216-841-11 METAL CHIP 47K 5% 1/10W
R812 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R814 1-216-833-11 METAL CHIP 10K 5% 1/10W
R817 1-216-833-11 METAL CHIP 10K 5% 1/10W
0 R827 1-245-605-51 FUSIBLE 100 5% 1/4W
0 R828 1-245-605-51 FUSIBLE 100 5% 1/4W
0 R838 1-220-893-11 METAL 0.22 10% 5W
R839 1-216-821-11 METAL CHIP 1K 5% 1/10W
R840 1-216-837-11 METAL CHIP 22K 5% 1/10W
R841 1-216-845-11 METAL CHIP 100K 5% 1/10W
R842 1-245-711-31 CARBON 10 5% 1/2W
R843 1-216-841-11 METAL CHIP 47K 5% 1/10W
R850 1-216-821-11 METAL CHIP 1K 5% 1/10W
R851 1-216-841-11 METAL CHIP 47K 5% 1/10W
R852 1-216-820-11 METAL CHIP 820 5% 1/10W
(GNX700)
R852 1-218-457-11 METAL CHIP 910 5% 1/10W
(GNX800)
R858 1-216-841-11 METAL CHIP 47K 5% 1/10W
R860 1-216-842-11 METAL CHIP 56K 5% 1/10W
R861 1-216-841-11 METAL CHIP 47K 5% 1/10W
0 R862 1-260-086-31 CARBON 82 5% 1/2W
R863 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R864 1-216-837-11 METAL CHIP 22K 5% 1/10W
R865 1-216-821-11 METAL CHIP 1K 5% 1/10W
R866 1-216-837-11 METAL CHIP 22K 5% 1/10W
0 R888 1-220-893-11 METAL 0.22 10% 5W
R889 1-216-821-11 METAL CHIP 1K 5% 1/10W
R890 1-216-837-11 METAL CHIP 22K 5% 1/10W
R891 1-216-845-11 METAL CHIP 100K 5% 1/10W
R892 1-245-711-31 CARBON 10 5% 1/2W
< RELAY >
RY862 1-755-500-11 RELAY
************************************************************
SURROUNDSENSOR
