— 73 —
MAIN
Ref. No. Part No. Description Remark
CN303 1-564-505-11 PLUG, CONNECTOR 2P
* CN304 1-564-706-11 PIN, CONNECTOR (SMALL TYPE) 4P
* CN305 1-564-708-11 PIN, CONNECTOR (SMALL TYPE) 6P
* CN306 1-564-710-11 PIN, CONNECTOR (SMALL TYPE) 8P
* CN307 1-568-449-11 HOUSING, CONNECTOR (PC BOARD) 3P
* CN308 1-568-449-11 HOUSING, CONNECTOR (PC BOARD) 3P
* CN701 1-568-834-11 SOCKET, CONNECTOR 15P
< DIODE >
D201 8-719-987-63 DIODE 1N4148M
D202 8-719-987-63 DIODE 1N4148M
D381 8-719-024-99 DIODE 11ES2-NTA2B
D382 8-719-024-99 DIODE 11ES2-NTA2B
D383 8-719-024-99 DIODE 11ES2-NTA2B
D384 8-719-987-63 DIODE 1N4148M
D385 8-719-987-63 DIODE 1N4148M
D386 8-719-024-99 DIODE 11ES2-NTA2B
D387 8-719-024-99 DIODE 11ES2-NTA2B
D450 8-719-987-63 DIODE 1N4148M
D451 8-719-987-63 DIODE 1N4148M
D452 8-719-987-63 DIODE 1N4148M
D453 8-719-987-63 DIODE 1N4148M
D701 8-719-987-63 DIODE 1N4148M
D702 8-719-987-63 DIODE 1N4148M
D703 8-719-987-63 DIODE 1N4148M
D704 8-719-987-63 DIODE 1N4148M
D705 8-719-987-63 DIODE 1N4148M
D706 8-719-024-99 DIODE 11ES2-NTA2B
D707 8-719-987-63 DIODE 1N4148M
D708 8-719-987-63 DIODE 1N4148M
D901 8-719-987-63 DIODE 1N4148M
D939 8-719-987-63 DIODE 1N4148M
D940 8-719-987-63 DIODE 1N4148M
D1001 8-719-024-99 DIODE 11ES2-NTA2B
D1003 8-719-028-23 DIODE D3SBA20-4101
D1007 8-719-987-63 DIODE 1N4148M
D1008 8-719-001-42 DIODE UZL-11M1
D1009 8-719-987-63 DIODE 1N4148M
D1010 8-719-987-63 DIODE 1N4148M
D1013 8-719-024-99 DIODE 11ES2-NTA2B
D1014 8-719-024-99 DIODE 11ES2-NTA2B
D1017 8-719-024-99 DIODE 11ES2-NTA2B
D1023 8-719-934-18 DIODE HZS27-2L
D1024 8-719-024-99 DIODE 11ES2-NTA2B
D1025 8-719-024-99 DIODE 11ES2-NTA2B
D1026 8-719-024-99 DIODE 11ES2-NTA2B
D1027 8-719-024-99 DIODE 11ES2-NTA2B
D1059 8-719-987-63 DIODE 1N4148M
D1069 8-719-987-63 DIODE 1N4148M
D1201 8-719-987-63 DIODE 1N4148M
D1202 8-719-987-63 DIODE 1N4148M
D1204 8-719-987-63 DIODE 1N4148M
D1205 8-719-987-63 DIODE 1N4148M
D1251 8-719-987-63 DIODE 1N4148M
D1309 8-719-987-63 DIODE 1N4148M
D1310 8-719-987-63 DIODE 1N4148M
Ref. No. Part No. Description Remark
< IC >
IC301 8-759-710-59 IC NJM4580D-D
IC302 8-759-710-59 IC NJM4580D-D
IC303 8-759-289-38 IC HA12195NT
IC304 8-759-143-54 IC uPC1330HA
IC701 8-759-459-27 IC TMP87CS64YF-6536
IC702 8-759-165-80 IC PST600C-T
IC802 8-759-000-48 IC MC14052BCP
IC901 8-759-331-39 IC M62427FP
IC1001 8-759-231-53 IC TA7805S
IC1002 8-759-604-86 IC M5F7807L
IC1003 8-759-604-86 IC M5F7807L
IC1004 8-759-604-90 IC M5F7907L
IC1201 8-749-920-09 IC STK-4152MK2K (GR3/RX30:AEP,UK,G,EE)
IC1201 8-749-900-24 IC STK-4162MK2 (RX30:US,CND)
IC1202 8-759-111-68 IC uPC1237HA
< JACK >
J801 1-774-725-11 JACK, PIN 2P (VIDEO IN)
J802 1-774-785-11 JACK, PIN 1P (SUPER WOOFER)
(GR3/RX30:US,CND)
< COIL >
L301 1-410-780-11 INDUCTOR 27mH
L351 1-414-223-11 INDUCTOR 470uH
L401 1-410-780-11 INDUCTOR 27mH
L1201 1-420-872-00 COIL, AIR-CORE (RX30:AEP,UK,G,EE)
L1251 1-420-872-00 COIL, AIR-CORE (RX30:AEP,UK,G,EE)
< TRANSISTOR >
Q301 8-729-119-79 TRANSISTOR 2SC2785-FEK
Q351 8-729-194-57 TRANSISTOR 2SC945-P
Q352 8-729-194-57 TRANSISTOR 2SC945-P
Q353 8-729-119-77 TRANSISTOR 2SA1175-FEK
Q354 8-729-119-79 TRANSISTOR 2SC2785-FEK
Q380 8-729-900-89 TRANSISTOR DTC144ES
Q381 8-729-900-65 TRANSISTOR DTA144ES
Q382 8-729-900-89 TRANSISTOR DTC144ES
Q401 8-729-119-79 TRANSISTOR 2SC2785-FEK
Q450 8-729-900-65 TRANSISTOR DTA144ES
Q451 8-729-900-89 TRANSISTOR DTC144ES
Q701 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q820 8-729-422-57 TRANSISTOR UN4111
Q901 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q902 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q951 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q952 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q953 8-729-141-26 TRANSISTOR 2SC3622A-LK
Q954 8-729-141-26 TRANSISTOR 2SC3622A-LK
Q1001 8-729-118-01 TRANSISTOR 2SB1116-K
Q1002 8-729-900-36 TRANSISTOR DTC124ES
Q1006 8-729-141-83 TRANSISTOR 2SB1094-LK
Q1011 8-729-021-82 TRANSISTOR 2SD2396K
Q1201 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q1202 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q1203 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q1204 8-729-900-63 TRANSISTOR DTA124ES
Q1205 8-729-900-36 TRANSISTOR DTC124ES
