Sony HCD-GR3 - 3-3. TC Mechanism Deck Removal; 3-4. CD SW and Panel Board Removal

— 8 —
3-4. CD SW BOARD AND PANEL BOARD
3-3. TC MECHANISM DECK
1 Push the EJECT button.
3 Six screws
(BVTP2.6x8)
2 Two cassette lid
4 TC Mechanism deck
1 Knob (VOL)
2 Nut
3 Six screws
(BVTP2.6x8)
4 Four screws
(BVTP2.6x8)
5 Five screws
(BVTP2.6x8)
6 Two screws
(BVTP2.6x8)
7 HP board
8 claw
9 CD SW board
0 Two claws
!¡ Two claws
!™ Claw
!£ Panel board
